Поз.
Артикул
Описание
7
FAN RIGID
7
FAN RIGID
7
FAN RIGID
7
FAN RIGID
7
FAN RIGID
7
FAN RIGID
7
FAN
7
FAN RIGID
7
FAN RIGID
7
FAN RIGID
7
FAN RIGID
7
FAN RIGID
7
FAN RIGID
7
FAN RIGID
7
FAN RIGID
7
FAN , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4432000023
7
FAN , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 323458, Replaced By: A3662003023
7
FAN , ADDITIONAL PARTS ONLY IN CASE OF OM364 ENGINE, Replaced By: A3662000923, +001A3640350506
7
FAN , Replaced By: A3522004723
7
FAN , Replaced By: A3522004523
7
FAN , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 323458, Replaced By: A3662002923
13
FAN POWER SAVER
13
FAN POWER SAVER, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
13
FAN , Replaced By: A3662006223, +001A3662052408, +001A3662050163, +001A3669901501, +004N000934008013, +004N000939008109
13
FAN , Replaced By: A3662006123, +001A3662052408, +001A3662050163, +001A3669901501, +004N000934008013, +004N000939008109
13
FAN , Replaced By: A3662006023, +001A3662052908, +001A3662050163, +001A3669901501, +004N000934008013, +004N000939008109
13
FAN , Replaced By: A3662004223
13
FAN , Replaced By: A3662003623
13
FAN , Replaced By: A3662003523
13
FAN , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3522001123
13
FAN , Replaced By: A3662004023
13
FAN , Replaced By: A3662003923
13
FAN 6-BLADE,WITH FLEXIBLE FAN HUB, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
13
FAN POWER SAVER
13
FAN POWER SAVER, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
13
FAN POWER SAVER, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
13
FAN POWER SAVER, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
13
FAN POWER SAVER
13
FAN POWER SAVER
18
SPACER RING FAN
19
FAN DRIVE FAN COUPLING
19
FAN DRIVE
19
FAN DRIVEFA.EATON
20
FAN 7-BLADE
20
FAN RIGID
20
FAN RIGID
20
FANFA.BEHR
20
FAN
27
BALL BEARING , Replaced By: A0019816127
27
BALL BEARING , Replaced By: A0049810525
27
ANGULAR CONTACT BEARING , Replaced By: A0019817927
27
ANGULAR CONTACT BEARINGTO 001 205 95 06
27
ANGULAR CONTACT BEARING
27
BALL BEARING , Replaced By: A0019816027
27
BALL BEARING
27
BALL BEARING
34
SPACER RING
34
SPACER RING
36
LOCK AS REQUIRED 2.3 MM
36
LOCK AS REQUIRED 2.0 MM
36
LOCK AS REQUIRED 2.2 MM
36
LOCK
36
LOCK
36
LOCK AS REQUIRED 2.1 MM
38
GASKET
38
SEAL RING
40
GASKET
40
GASKET , Replaced By: A0002060880
40
GASKET , Replaced By: A0002060680
40
GASKET
42
SEAL RING
45
GASKET
47
SEAL RING
51
PRIMARY CUP
57
SCREW LINE MOUNTING
59
CLAMPING PIECE
69
FLANGE
73
SCREW FUSE BOX TO SIDE MEMBER,5 097182
73
SCREW
73
SCREW
75
CLAMPING PIECE (SLIDE)
80
SCREW COVER TO FAN TO 001 205 95 06
81
SCREW
90
INTERMEDIATE PIECE FAN
91
SCREW BRACKET TO THROTTLE HOUSING
92
HEXAGON HEAD BOLT. SCREW CLUTCH TO FLYWHEEL M8X16 MM
92
HEXAGON HEAD BOLT CLAMP AT SUPPORTING RAIL M 8X30
92
SCREW EXHAUST MUFFLER TO CROSS MEMBER
92
SCREW STOP TO BATTERY CASE
92
SCREW COVER PLATE TO COVER PLATE M 6 X 12
94
STUD BOLT BELL HOUSING M 10X28, INCLUDED IN RANGE OF DELIVERY OF TRANSMISSION
94
STUD BOLT FAN TO VIBRATION DAMPER M 10X120, 362 846928 366 055868
94
STUD BOLT BELL HOUSING, 760272 10/20 UP TO IDENT NO. 922885 EXCEPT FOR 921682,921950,921972,921994,922001,922008,922038,922287,922349,922387,922522,922575,922585,922608, 922638,922642,922671,922678,922686,922691,922705,922720,922723,922732,922736,922756,922768,922850, 922855. ALSO INSTALLED ON 934036,934433,934539,935068,935169,937098 50/60 UP TO IDENT NO. 922468 ON 96 KW (130 PS) 50/60 UP TO IDENT NO. 923153 ON 124 KW (168 PS)
94
STUD BOLT AIR COMPRESSOR TO SUPPORT,238225/92
94
STUD BOLT FAN TO CRANKSHAFT PULLEY M 10X105
96
SCREW BRACKET TO BEARING BRACKET, 393.311 FROM IDENT NO.: 4 450303,393.321 FROM IDENT NO.: 4 453074,395.312,322 FROM IDENT NO.: 4 426006
98
WASHER EXHAUST MUFFLER TO STRAP
102
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
102
NUT
999
RECEPTACLE , Replaced By: A0005832435
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 34CCM TO 366 200 24 23
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 26CCM
999
RECEPTACLE SILICONE GREASE
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 64 CCM,TO 002 205 01 06
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 52 CCM,TO 000 205 58 06
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 70 CCM,TO 002 205 65 06
999
COVER
999
GASKET
999
SPACER RING
999
FLANGE
999
COVER
999
FAN
999
FLANGE
