Mercedes N304017006016 - Винт M 6 X 16 8.8

E 230 JAPAN 210.037 TO MODELLJAHR CODE 809

78 ELECTRIC SLIDING/LIFTING ROOF - 045 SLIDING/LIFTING ROOF FRAME IL. 2

Поз.
Артикул
Описание
134
A2103010740
BRACKET
140
A2103000928
LEVER (REVERSING LEVER), A 698508 X 012426 EXEPT FOR VEHICULES WITH CODE 808 ALSO INSTALLED IN VEHICLE TO A 698507, X 012425 WITH CODE 809
143
N006799007007
LOCK PLATE RELEASE LEVER TO SHAFT
146
A2103010011
ROLLER , NOT USED
149
N006799005009
LOCK PLATE , 656999
152
N304017006016
SCREW PUMP TO BRACKET
155
A2109930310
SPRING , NOT USED
158
N910112006001
NUT , Replaced By: N913023006001
158
N913023006001
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
