Поз.
Артикул
Описание
8
EXHAUST PIPE , Replaced By: A3574901419
8
EXHAUST PIPE LONG,AT EXHAUST MANIFOLD,076650
14
EXHAUST PIPE SHORT,AT EXHAUST MANIFOLD,076650
14
EXHAUST PIPE , Replaced By: A3574901319
20
SCREW CONNECTOR TO EXHAUST MANIFOLD
23
NUT EXHAUST PIPE TO EXHAUST MANIFOLD
26
BRACKET EXHAUST PIPE TO EXHAUST PIPE
33
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
36
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
36
SCREW SUPPORT TO CROSS MEMBER M 10X28
39
WASHER , Replaced By: N000125010532
39
WASHER RADIATOR TO RUBBER MOUNTING
41
NUT STRAP TO BRACKET
41
NUT , Replaced By: N910113010000
42
FLEXIBLE METAL TUBE CONNECTOR
47
COLLAR EXHAUST LINE FLEXIBLE METAL TUBE
49
CLAMP FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
54
SCREW , Replaced By: N304017008028
56
NUT , Replaced By: N913004008001
62
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
71
SCREW BRACKET TO SIDE MEMBER
71
SCREW , Replaced By: N304017010002
74
WASHER , Replaced By: N000125010532
74
WASHER RADIATOR TO RUBBER MOUNTING
80
NUT STRAP TO BRACKET
80
NUT , Replaced By: N910113010000
98
EXHAUST MUFFLER ,076650
110
DAMPING PAD , Replaced By: A0004920082
110
DAMPING PAD MOUNTING PARTS
110
DAMPING PAD EXHAUST MUFFLER TO SUBSTRUCTURE,047203
116
SCREW VALVE TO BRACKET
116
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
116
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
119
WASHER , Replaced By: N000125008443
119
WASHER EXHAUST MUFFLER TO STRAP
122
NUT BRACKET TO SIDE MEMBER
205
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
205
CLAMP , Replaced By: N071555094502
205
CLAMP , Replaced By: N071555104501
205
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
207
SCREW END PIECE TO EXHAUST PIPE M 10X25
210
NUT BRACKET TO SUPPORT AND TO END PIECE
210
NUT END PIECE TO EXHAUST PIPE
253
RUBBER MOUNTING AIR CLEANER TO SUBSTRUCTURE
256
WASHER RADIATOR TO RUBBER MOUNTING
256
WASHER EXHAUST MUFFLER TO STRAP
256
WASHER , Replaced By: N000125008443
263
NUT , Replaced By: N913004008001
999
END PIECE REAR EXHAUST PIPE
999
PROTECTIVE PLATE
999
END PIECE REAR EXHAUST PIPE
