Поз.
Артикул
Описание
64
FUEL TANK LESS SENDER UNIT 190 L,093523
64
FUEL TANK LESS SENDER UNIT 393 L
64
FUEL TANK LESS SENDER UNIT 270 L,075828
64
FUEL TANK LESS SENDER UNIT 190L,093522
360
HOSE FUEL TANK
360
CAP FUEL TANK
368
CAP FUEL TANK
368
CLAMP HOSE TO RETARDER 60-80X13 MM
368
CLAMP (DRY FILTER)
424
SCREW SWITCH TO WINDOW LEVEL GIRDER
432
WASHER FILLER NECK TO BRACKET
456
HOSE LEAK LINE
464
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
472
VALVE DE-AERATION,618 115 13 091994, 618 215 11 092222
948
CABLE HARNESS ELECTRICAL COMPARTMENT
952
ELECTRIC CABLE FROM REAR END PLUG-CONNECTION TO SWITCH
956
BULB TELL-TALE LAMP 24 V/1,2 W
960
TELL-TALE LAMP TELL-TALE LAMP
964
LENS SWITCH
964
LENS
964
LENS COLORLESS
968
SWITCH PERMANENT CURRENT CUTOFF
972
RELAYA33
972
RELAY , Replaced By: A0035459605
972
RELAYA33, Replaced By: A0009822123
999
SENDER UNITTO 612 470 32 01
999
LINE FROM FUEL TANK TO FUEL TANK
999
FUEL TANK
999
FUEL TANK
999
HOSE
999
HOSE FROM FUEL TANK TO FUEL TANK
999
HOSE FROM FUEL TANK TO ADDITIONAL TANK
999
HOSE CONNECTION OF FUEL TANKS
999
BRACKET CABLE HARNESS THRU RIGHT SIDE MEMBER, FRONT, TO BE ADAPTED DURING ASSEMBLY
999
BRACKET CABLE HARNESS THRU RIGHT SIDE MEMBER, FRONT, TO BE ADAPTED DURING ASSEMBLY
999
FUEL TANK220 L,050329
999
FUEL TANK
999
FUEL TANK LESS SENDER UNIT 114 L
999
FUEL TANK
999
FUEL TANK (FUEL-OIL TANK),075828
999
FUEL TANK (FUEL-OIL TANK)
999
FUEL TANK265 L
999
FUEL TANK
999
FUEL TANK (FUEL-OIL TANK)
999
FILLER NECK
999
FUEL TANK
999
STRAP
999
FUEL TANK LESS SENDER UNIT 76 L
999
STRAP
999
INSULATION AERATION/DEAERATION
999
GASKETTO 612 470 22 01
999
GASKET EXTRACTION OPENING FOR FUEL OIL,075828
