Поз.
Артикул
Описание
47
HUB POWER SAVER FAN
50
LOCK WASHERROCKINGER TYP 59 G140,59 G150
53
NUT HUB TO FAN SHAFT
53
NUT WEAR INDICATOR
56
FAN POWER SAVER FAN, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
62
GUIDE
65
SCREW
68
BALL BEARINGTO 002 205 19 06,63 06, TO BE ADAPTED DURING ASSEMBLY
68
BALL BEARING , Replaced By: A0059814825
71
LOCK AS REQUIRED 2.3 MM
71
LOCK AS REQUIRED 2.2 MM
71
LOCK AS REQUIRED 2.1 MM
71
LOCK AS REQUIRED 2.0 MM
80
GASKETTO 002 205 19 06,63 06
86
SCREW OIL PIPE TO SLEEVE VALVE
89
SCREW BRACKET TO EXHAUST PIPE BRACKET
89
SCREW , Replaced By: N304017008024
92
NUT , Replaced By: N913004008001
999
RECEPTACLE SILICONE GREASE, FILLING QUANTITY: 70 CCM,TO 002 205 65 06
999
SEPARATOR FAN SHAFT,1/97
999
STUD SUPPORT TO BASE FRAME,076193 EXCEPT:075800, 075853, 075889
