Поз.
Артикул
Описание
6
OIL TANK ENGINE OIL AUTOMATIC REPLENISHMENT 16 L,076194 ALSO INSTALLED IN:075800, 075853, 075889
6
OIL TANK ENGINE OIL AUTOMATIC REPLENISHMENT 16 L,076193 EXCEPT:075800, 075853, 075889
6
OIL TANK , Replaced By: A3574801801
8
COVER
10
GASKET
10
GASKET
11
PLASTIC PIPE. HOSE FLUID LEVEL INDICATOR 170 MM, ORDER BY THE METER
12
BANJO UNION HOSE WIDTH, / I.D., 8/12 MM
13
SCREW DE-AERATION LINE TO TRANSMISSION COOLING WATER LINE
13
HOLLOW SCREW OIL DELIVERY LINE TO MANUAL PUMP A8
14
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
15
SENDER UNIT
17
GASKET
20
SEAL RING
20
SEAL WASHER , Replaced By: A0169975848
23
RUBBER BUFFER COVERING TO FRAME
23
RUBBER BUFFER SUPPORT TO BRACKET
24
SCREW , Replaced By: N304017008021
25
WASHER EXHAUST MUFFLER TO STRAP
25
WASHER EXHAUST MUFFLER TO STRAP
26
NUT , Replaced By: N913004008001
32
SCREW DE-AERATION LINE TO TRANSMISSION COOLING WATER LINE
32
HOLLOW SCREW OIL DELIVERY LINE TO MANUAL PUMP A8
35
SEAL RING LINE TO OIL TANK
38
OIL LINE FROM OIL TANK TO FILTER,080283
41
UNION NUT LINE CONNECTION
41
UNION NUT LINE CONNECTION, Replaced By: N000000006239
44
SEAL CONE LINE CONNECTION
44
GLAND , Replaced By: A0019901967
44
GLAND , Replaced By: N003861012007
47
FILTER OIL
47
FILTER , Replaced By: A0004810360
50
SEAL RING
53
FILTER ELEMENT
56
FILTER BOWL
59
FILLER NECK OIL LINE TO FILTER,080283
62
SEAL RING OIL LINE TO FILTER
65
FILLER NECK OIL LINE TO FILTER
65
BULKHEAD FITTING , Replaced By: A3574810309
68
VALVE SOLENOID
71
SEAL RINGTO 000 553 03 05,000 553 18 05,
74
FITTING ,4 412020
74
FITTING , Replaced By: A0029977472
77
SEAL RING VALVE
80
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
83
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
86
SEAL RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
87
LINE12 MM, ORDER BY THE METER4 691315
87
OIL LINE , Replaced By: A0004291001
87
OIL LINE , Replaced By: A0004291001
87
OIL LINE , Replaced By: A0004291001
88
UNION NUT , Replaced By: A0009907454
89
SEAL CONE LINE CONNECTION
89
GLAND , Replaced By: A0019901967
89
GLAND , Replaced By: N003861012007
90
HOSE FROM SOLENOID VALVE TO ENGINE OIL FILLER NECK
92
FITTING (PARTS KIT),LINE RUPTURE
92
FITTING , Replaced By: A0029906171
95
UNION NUT LINE CONNECTION
95
UNION NUT LINE CONNECTION, Replaced By: N000000006239
98
SEAL CONE LINE CONNECTION
98
GLAND , Replaced By: A0019901967
100
CLAMP , Replaced By: N916016010211
100
CLAMP , Replaced By: N000000001045
100
CLAMP CABLE HARNESS MOUNTING
100
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
101
SCREW CAB FLOOR COVERING M 6X25
102
NUT , Replaced By: N913004006001
102
NUT PUMP TO BRACKET
103
INDICATOR OIL SUPPLY
104
PULL
107
BRACKET OIL LEVEL INDICATOR
110
SHEET METAL SCREW BRACKET TO FLOOR PLATE
110
SHEET METAL SCREW BRACKET TO FLOOR PLATE, Replaced By: N000000000460
999
CAP OIL REFILLING
999
PLASTIC PIPE RISING PIPE 4X6 MM
999
OIL LINE FROM OIL TANK TO FILTER
999
OIL LINE , Replaced By: A3574800115
