Поз.
Артикул
Описание
197
BRAKE MASTER CYLINDER , Replaced By: A0024301901
197
BRAKE MASTER CYLINDER
198
VALVE , Replaced By: A3075530107
198
VALVE CLUTCH SLAVE CYLINDER
199
PROTECTIVE CAP , Replaced By: A0004217187
199
PROTECTIVE CAP ,5 962906
199
PROTECTIVE CAP , Replaced By: A0004217187
200
COVER. THREADED UNION
201
SEAL RINGTO 002 430 41 01
202
ANSCHLUSSSTUCK. THREADED UNION
203
SEAL RING
204
DICHTSCHEIBE. SEAL RING
205
KAPPENVENTIL. VALVETO 002 430 31 01,344 430 80 01
205
BOTTOM VALVE. VALVE , Replaced By: A0015861543
206
SPRING
207
WASHER BRAKE MASTER CYLINDER
208
SPRING BRAKE MASTER CYLINDER
209
SPRING RETAINER
210
BOTTOM VALVE. VALVE , Replaced By: A0015861543
211
SEAL RING
212
SPRING
213
SPRING RETAINER
214
PISTON BRAKE MASTER CYLINDER
216
WASHERTO 002 430 41 01, NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
217
SCREW BRAKE MASTER CYLINDER, UP TO IDENT NO. 734559,FROM CHASSIS,STANDARD EQUIPMENT
218
SEAL RING SCREW PLUG
220
REPAIR KITTO 001 430 68 01,002 430 19 01
234
SCREW FITTING (AT INTAKE). FITTING , TO TANDEM BRAKE MASTER CYLINDERS 001 430 51 01 AND 001 430 68 01
235
DISTRIBUTOR , TO TANDEM BRAKE MASTER CYLINDERS 001 430 51 01 AND 001 430 68 01
236
SEAL RING FUEL LINE TO FEED PUMP
237
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
238
SCREW PLUG CONNECTION "1","2",4 478330
240
NUT BRACKET TO SUPPORT AND TO END PIECE
241
BRACKET
241
BRACKET BRAKE MASTER CYLINDER
243
RESERVOIRTO 344 430 79 01
245
FILLER CAP BUTTRESS THREAD
246
SEAL RING
246
SEAL RING42X21.5 MM
247
STRAINER , Replaced By: A0004314334
247
STRAINER
249
SEAL RING LINE CONNECTION
263
LINE FROM TEST CONNECTION TO LEFT FRONT WHEEL BRAKE HOSE 1300 MM
263
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 2600 MM
265
HOSE
267
ANGLE LINE MOUNTING
268
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
270
CLAMP , Replaced By: N916016008200
270
CLAMP ,K 147121, Replaced By: N000000000319
274
CLAMP LINE TO HOSE
279
BRACKET. LOCK , Replaced By: A6525040038
279
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
280
BRACKET
281
SCREW CLAMP TO BRACKET AND TO PIPE
284
CONNECTOR OIL DELIVERY LINE
286
LINE FROM CONNECTOR TO TEST CONNECTION 3400 MM,4 478330
322
LINE FROM TEST CONNECTION TO BRAKE POWER REGULATOR,CONNECTION "1" 750 MM,4 478330
323
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
323
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
326
BRAKE HOSE600 MM
327
BRACKET. LOCK , Replaced By: A6525040038
327
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
330
BRACKET BRAKE HOSE,REAR
335
SCREW BRACKET TO SIDE MEMBER, 815770
336
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
337
LINE FROM BRAKE POWER REGULATOR,CONNECTION "2",TO BRAKE HOSE 1150 MM
338
CLAMP BRAKE LINE MOUNTING
339
HOSE BRAKE LINE TO REAR AXLE,4 644238
340
SCREW , Replaced By: N304017008016
340
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
341
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
342
LINE FROM BRAKE POWER REGULATOR TO REAR BRAKE HOSE 500 MM
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
BRAKE MASTER CYLINDER , UP TO IDENT NO. 734559,FROM CHASSIS,STANDARD EQUIPMENT
999
BRAKE MASTER CYLINDER , Replaced By: A0024308201
999
PRESSURE REGULATORBOSCH
999
PRESSURE REGULATOR"WESTINGHOUSE", TO 001 429 60 44
999
PRESSURE REGULATOR , Replaced By: A0024315906
999
REPAIR KIT , UP TO 625
999
REPAIR KITTO 000 431 91 06,BOSCH 0 481 039 011, UP TO BOSCH N 625
999
REPAIR KIT , FROM 626
999
REPAIR KITGRAU,5 148812
999
TS DOUBLE FITTING SOLENOID VALVE
999
FITTING (PARTS KIT),LINE RUPTURE
999
VALVE (OVERFLOW VALVE)
999
FITTING AT DISTRIBUTOR,4 481289
999
FITTING , Replaced By: A0029906071
999
SEAL RINGTO 000 431 24 14
999
FITTING , Replaced By: A0029906171
999
SEAL RING , Replaced By: A0179974148
999
SEAL RINGTO 000 431 77 14,KNORR
999
SEAL RINGTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 723
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
SEAL RING101
999
BRACKET , Replaced By: A3454200086
999
BRAKE ANCHOR PLATE RIGHT
999
REPAIR KIT BRAKE READJUSTMENT
999
WASHER
999
PIN BRAKE SHAFT TO THRUST SHACKLE
999
PIN BRAKE SHAFT TO THRUST SHACKLE, 029312 UP TO CHASSIS 910369 ALSO INSTALLED ON 500001-501414,FROM CHASSIS 910370 AND 501415-599999 SEE SPARE PARTS LIST 744.3
999
BEARING
999
REPAIR KIT , Replaced By: A3024203138
999
SCREW FRONT WHEEL BRAKE TO STEERING KNUCKLE
999
SCREW FRONT WHEEL BRAKE TO STEERING KNUCKLE
999
SPRING
999
LOCK BRAKE SHAFT TO THRUST SHACKLE
999
RIVET BRAKE LINING 15 MM
999
SPACER RING , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
REPAIR KIT
999
REPAIR KIT , Replaced By: A3144200092
999
PROTECTIVE CAP , Replaced By: A0004210887
999
CONSOLE AT BRAKE CYLINDER, 674067
999
BRAKE SHOE , Replaced By: A3384200219
999
REPAIR KIT BRAKE SHOE SHACKLE SPACER PIN
999
REPAIR KIT , Replaced By: A3384200082
999
REPAIR KIT , Replaced By: A3585860242
999
PLATE ,5 317650
999
BRAKE SHOE , Replaced By: A3384200019, +002A3524230310, +016A3079900197
999
BRAKE SHOE , Replaced By: A3384200019, +002A3524230410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3534200019, +002A3534232810, +016A3079900197
999
LINE , Replaced By: A3404203829
999
BRACKET OIL LINE MOUNTING
999
ROD ,752204, 002,003,012,013,022,023, 734559, 010,011,014,015,021, Replaced By: N900331008282, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
999
BRACKET , TO 001 429 60 44
999
BRACKET METAL SPRING BELLOWS
999
ELECTRIC CABLE FROM FIRE WALL TO EMERGENCY RELEASE VALVE
999
ELBOW FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
999
BRAKE SHOE , Replaced By: A3024200019, +002A3604230010, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024200019, +002A3604230110, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024200019, +002A3604232810, +016A3079900197
999
REPAIR KIT BRAKE SHOE MOUNTING BOLT
999
REPAIR KIT , Replaced By: A3584200182
999
SHACKLE , Replaced By: A3834200389, +001A3024230974
999
REPAIR KIT BRAKE CAMSHAFT BEARING
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
BRAKE SHOE ,044379044348, Replaced By: A3454207620, +001A3024210088
999
BRAKE SHOE ,100570, Replaced By: A3604209120, +001A3024210088
999
BRAKE SHOE , FROM REAR AXLE 029312-035499, FROM REAR AXLE K 000001-K 038371, Replaced By: A3024202119, +001A3024210088, +002A3604230110, +016A3079900197
999
BRAKE SHOE , FROM REAR AXLE 029312-035499, FROM REAR AXLE K 000001-K 038371, Replaced By: A3024202119, +001A3024210088, +002A3604232810, +016A3079900197
999
BRAKE SHOE ,796990, 10/20, 790758, 50/60, Replaced By: A3024202019, +002A3604212510, +002A3024210088, +016A3079900197
999
BRAKE SHOE ,796990, 10/20, 790758, 50/60, Replaced By: A3024202019, +002A3604210810, +002A3024210088, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231310, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231510, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202019, +002A3604212410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202019, +002A3604212510, +016A3079900197
999
BRAKE SHOE ,910369 EXCEPT FOR 501456-599999910370 ALSO INSTALLED ON 501456-599999, SEE SPARE PARTS LIST 731.3, Replaced By: A3024202019, +002A3604210810, +016A3079900197
999
LOCK
999
STOP WASHER BRAKE SHAFT TO BEARING BRACKET
999
BRAKE CAMSHAFT
999
BRAKE CAMSHAFT , 10/20 FROM CHASSIS 981193,50/60 FROM CHASSIS 986145
999
BRAKE LINING (PARTS KIT),REPAIR SIZE I (ASBESTOS-FREE BRAKE LINING) 16.70 MM
999
BRAKE LINING (PARTS KIT),REPAIR SIZE II (ASBESTOS-FREE BRAKE LINING) 17.70 MM
999
LEVER , Replaced By: A3604260611
999
LEVER , Replaced By: A3604260711
999
LEVER RIGHT,2 068748
999
LEVER LEFT,2 068749
999
LEVER RIGHT,2 068749
999
CONSOLE
999
ROD ,4 478504, Replaced By: N900331008426, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
999
ROD ,4 399152, 10/20, 4 416113, 50/60752205-4 478504, 002,003,012,013,022,023, 734560-4 478504, 010,011,014,015,021, Replaced By: N900331008426, +001A0004310867, +001N000934008010, +001N000934008035
999
BRACKET , 752204
999
BRACKET , UP TO CHASSIS 721608 EXCEPTO FOR:500001-599999
999
GUIDE SIGN , 752204
999
REPAIR KIT , Replaced By: A3604200241
999
T-FITTING AT DISTRIBUTOR,4 481288
999
NUT ,796991, 10/20, 790759, 50/60 360.0 UP TO IDENT NO. 4 337020, FROM IDENT NO. 4 337021,SEE MICROFICHE 103
999
CLAMP LINE MOUNTING
999
NUT FROM BRAKE SHAFT TO BRAKE LEVER
999
GROMMET LINE MOUNTING 19/13 MM
999
ADHESIVE FOIL GUIDE SIGN
999
REPAIR KIT BRAKE SHOE BEARING
999
REPAIR KIT , Replaced By: A3954200041
999
SCREW ,374026
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
SCREW PROTECTION PLATE TO BRACKET
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN VIBRATION ABSORBER TO BRACKET,5 117575
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PIN STRAP TO CONSOLE
999
COTTER PINTO 345 431 70 16, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
COTTER PINROCKINGER TYP 260 G140
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000433010510
999
WASHER VIBRATION ABSORBER TO BRACKET
999
WASHER , Replaced By: N000433013010
999
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
999
LOCK RING SHACKLE TO BEARING BRACKET,965965
999
LOCK RING
999
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
999
SCREW CONNECTOR
999
SCREW , Replaced By: N000933008134
999
SCREW BRACKET TO SIDE MEMBER
999
SCREW SUPPORT WITH EDDY CURRENT BRAKE TO SUPPORT
