Поз.
Артикул
Описание
999
SCREW PLUG , Replaced By: A0004315433
999
BLEEDER VALVE , Replaced By: A0004310265
999
PROTECTIVE CAP , Replaced By: A0004217187
999
PROTECTIVE CAP , Replaced By: A0004210887
999
PROTECTIVE CAP , Replaced By: A3454237020
999
PROTECTIVE CAP ,5 962906
999
PROTECTIVE CAPTO 003 420 80 18
999
DIAPHRAGMTO 344 429 73 44
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
DIAPHRAGM , Replaced By: A0004290745
999
DIAPHRAGM
999
ELBOW FITTING PRESSURE REGULATOR,CONNECTION "1"
999
DISTRIBUTOR ,4 342862
999
REPAIR KITTO 002 431 15 06,WABCO, 975 300 750 0,5 161700
999
REPAIR KITTO 001 431 06 06,BOSCH 0 481 039 101,5 148812
999
REPAIR KIT DIAPHRAGM PART BOSCH,209
999
PISTON REPAIR KIT TO 002 430 88 01,002 430 82 01
999
REPAIR KIT SEAL RING BOSCH,209
999
VALVE , Replaced By: A3075530107
999
FILLER RING
999
FILTER BOTTOMTO 000 431 24 14
999
SCREWTO 003 430 72 01,SCHAEFER
999
VALVE PART
999
VALVE DISC
999
METAL SPRING BELLOWS ,4 957941, Replaced By: A0004311718, +001N000961012047
999
BRAKE BOOSTER , Replaced By: A0004318914
999
METAL SPRING BELLOWS ,4 9579425 498312
999
GASKETTO 000 431 77 14,KNORR
999
VALVE DISCTO 000 431 62 14
999
GUIDE BUSHINGTO 000 431 43 12,000 431 44 12
999
CUPTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 724
999
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
VALVE104
999
BRAKE BOOSTER , Replaced By: A0004318914
999
PISTONTO 000 431 43 12,000 431 44 12
999
PROTECTIVE CAP101
999
PRESSURE SENDER UNIT , 752204
999
PISTONTO 000 431 21 14,BOSCH
999
SEAL RING
999
SEAL RINGTO 002 430 69 01
999
SEAL RINGTO 002 430 72 01,SCHAEFER
999
SEAL RINGTO 002 430 69 01
999
CUPTO 000 431 76 14
999
GASKETTO 000 429 16 30
999
INSTRUCTION PLATE IN GERMAN
999
REPAIR KIT WHEEL CYLINDER
999
REPAIR KITTO 000 429 63 44,000 429 59 44
999
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
999
REPAIR KIT , Replaced By: A0004303083
999
JOINT BEARING
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
T-FITTING , Replaced By: N074317000100
999
FITTING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
SPRINGTO 002 430 69 01
999
SPRINGTO 002 430 69 01
999
SPRING
999
SPRING , Replaced By: A0009935205
999
SCREW. UNION SCREW LINE CONNECTION
999
PLUG
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
SEAL RINGTO 000 431 77 14,KNORR,4 415092
999
CUP , Replaced By: A0014312386
999
CUPTO BOSCH-NR.0481 027 104
999
PRESSURE REGULATOR"WABCO",486597
999
CUP101
999
PRESSURE REGULATORWABCO
999
PRESSURE REGULATOR , EXHAUST STOCK OF OLD PARTS FROM CHASSIS 4 208908-5 148812, Replaced By: A0024315906
999
PRESSURE REGULATOR , Replaced By: A0024316006
999
SPRING
999
REPAIR KITTO 001 429 52 44
999
REPAIR KIT , Replaced By: A0025861443
999
REPAIR KIT , Replaced By: A0004301107
999
REPAIR KIT , Replaced By: A0004301407
999
SEAL RING BRAKE SHAFT TO BEARING BRACKET
999
FITTING , Replaced By: N915059004001
999
FITTING
999
WHEEL BRAKE CYLINDER , Replaced By: A0034208018
999
VALVE
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
BRAKE MASTER CYLINDER , UP TO IDENT NO. 734559,FROM CHASSIS,STANDARD EQUIPMENT
999
BRAKE MASTER CYLINDER , Replaced By: A0024308201
999
PRESSURE REGULATORBOSCH
999
PRESSURE REGULATOR"WESTINGHOUSE", TO 001 429 60 44
999
PRESSURE REGULATOR , Replaced By: A0024315906
999
REPAIR KIT , UP TO 625
999
REPAIR KITTO 000 431 91 06,BOSCH 0 481 039 011, UP TO BOSCH N 625
999
REPAIR KIT , FROM 626
999
REPAIR KITGRAU,5 148812
999
TS DOUBLE FITTING SOLENOID VALVE
999
FITTING (PARTS KIT),LINE RUPTURE
999
VALVE (OVERFLOW VALVE)
999
FITTING AT DISTRIBUTOR,4 481289
999
FITTING , Replaced By: A0029906071
999
SEAL RINGTO 000 431 24 14
999
FITTING , Replaced By: A0029906171
999
SEAL RING , Replaced By: A0179974148
999
SEAL RINGTO 000 431 77 14,KNORR
999
SEAL RINGTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 723
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
SEAL RING101
999
WASHER FRONT AXLE, NOT USED
999
BRACKET , Replaced By: A3454200086
999
BRAKE SHOE ,030378-035499, K 000001-038371, Replaced By: A3024202119, +001A3024210088
999
BRAKE ANCHOR PLATE RIGHT
999
BUSHING
999
WASHER
999
BEARING
999
SPRING
999
VALVE CLUTCH SLAVE CYLINDER
999
RIVET BRAKE LINING 15 MM
999
SPACER RING , 058 USED WITH HYDRAULIC BRAKE, UP TO CHASSIS 589554
999
HOSE
999
REPAIR KIT
999
REPAIR KIT , Replaced By: A3144200092
999
PROTECTIVE CAP , Replaced By: A0004210887
999
PLATE ,5 317650
999
LINE , Replaced By: A3404203829
999
BRACKET OIL LINE MOUNTING
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
999
BRACKET , TO 001 429 60 44
999
BRACKET METAL SPRING BELLOWS
999
ELECTRIC CABLE FROM FIRE WALL TO EMERGENCY RELEASE VALVE
999
ELBOW FITTING LOAD/NO-LOAD VALVE, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
999
PIN PULL ROD TO BRAKE LEVER,REAR AXLE
999
REPAIR KIT BRAKE CAMSHAFT BEARING
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
ROD FROM BRAKE SHAFT TO BRAKE LEVER
999
BRAKE SHOE WITH LINING, UP TO FRONT AXLE 1502306 AND REAR AXLE 00400
999
BRAKE SHOE , 030377, Replaced By: A3024202119, +001A3024210088, +002A3604230110, +016A3079900197
999
BRAKE SHOE , 030377, Replaced By: A3024202119, +001A3024210088, +002A3604230010, +016A3079900197
999
BRAKE SHOE ,044379044348, Replaced By: A3454207620, +001A3024210088
999
BRAKE SHOE ,100570, Replaced By: A3604209120, +001A3024210088
999
BRAKE SHOE , FROM REAR AXLE 029312-035499, FROM REAR AXLE K 000001-K 038371, Replaced By: A3024202119, +001A3024210088, +002A3604230110, +016A3079900197
999
BRAKE SHOE , FROM REAR AXLE 029312-035499, FROM REAR AXLE K 000001-K 038371, Replaced By: A3024202119, +001A3024210088, +002A3604232810, +016A3079900197
999
BRAKE SHOE ,796990, 10/20, 790758, 50/60, Replaced By: A3024202019, +002A3604212510, +002A3024210088, +016A3079900197
999
BRAKE SHOE ,796990, 10/20, 790758, 50/60, Replaced By: A3024202019, +002A3604210810, +002A3024210088, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231310, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202119, +002A3604231510, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202019, +002A3604212410, +016A3079900197
999
BRAKE SHOE , Replaced By: A3024202019, +002A3604212510, +016A3079900197
999
BRAKE SHOE ,910369 EXCEPT FOR 501456-599999910370 ALSO INSTALLED ON 501456-599999, SEE SPARE PARTS LIST 731.3, Replaced By: A3024202019, +002A3604210810, +016A3079900197
999
LOCK
999
STOP WASHER BRAKE SHAFT TO BEARING BRACKET
999
BRAKE CAMSHAFT
999
BRAKE CAMSHAFT , 10/20 FROM CHASSIS 981193,50/60 FROM CHASSIS 986145
999
BRAKE LINING (PARTS KIT),REPAIR SIZE I (ASBESTOS-FREE BRAKE LINING) 16.70 MM
999
BRAKE LINING (PARTS KIT),REPAIR SIZE II (ASBESTOS-FREE BRAKE LINING) 17.70 MM
999
LEVER , Replaced By: A3604260611
999
LEVER , Replaced By: A3604260711
999
LEVER RIGHT,2 068748
999
LEVER LEFT,2 068749
999
LEVER RIGHT,2 068749
999
ANGLE LINE MOUNTING
999
BRACKET DISTRIBUTOR
999
BRACKET DISTRIBUTOR
999
CONSOLE
999
CONSOLE
999
ROD ,4 399152, 10/20, 4 416113, 50/60, Replaced By: N900331008426, +001A0004310867, +001N000934008010, +001N000934008035
999
BRACKET , 752204
999
BRACKET , UP TO CHASSIS 721608 EXCEPTO FOR:500001-599999
999
GUIDE SIGN , 752204
999
REPAIR KIT , Replaced By: A3604200241
999
T-FITTING AT DISTRIBUTOR,4 481288
999
NUT ,796991, 10/20, 790759, 50/60 360.0 UP TO IDENT NO. 4 337020, FROM IDENT NO. 4 337021,SEE MICROFICHE 103
999
WASHER WATER SEPARATOR
999
CLAMP LINE MOUNTING
999
NUT FROM BRAKE SHAFT TO BRAKE LEVER
999
GROMMET LINE MOUNTING 19/13 MM
999
ADHESIVE FOIL GUIDE SIGN
999
REPAIR KIT BRAKE SHOE BEARING
999
REPAIR KIT , Replaced By: A3954200041
999
SCREW ,374026
999
SCREW LICENSE PLATE TO BRACKET,4 300861
999
SCREW PROTECTION PLATE TO BRACKET
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
COTTER PIN VIBRATION ABSORBER TO BRACKET,5 117575
999
COTTER PIN CYLINDER TO BRACKET
999
COTTER PINTO 345 431 70 16, USED WITH HYDRAULIC BRAKE,345.000-008,021,024,025,033 UP TO IDENT NO. FB588185
999
COTTER PINROCKINGER TYP 260 G140
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
WASHER , Replaced By: N000433010510
999
WASHER VIBRATION ABSORBER TO BRACKET
999
WASHER , Replaced By: N000433013010
999
WASHER PULL ROD TO BRAKE INTERMEDIATE LEVER
999
LOCK RING SHACKLE TO BEARING BRACKET,965965
999
LOCK RING
999
SCREW PLUG , Replaced By: N000908012009
999
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
999
SCREW , Replaced By: N304017006027
999
SCREW CONNECTOR
999
SCREW , Replaced By: N000933008134
999
SCREW SUPPORT WITH EDDY CURRENT BRAKE TO SUPPORT
999
SCREW STRAP TO BRACKET
999
SCREW BRACKET TO BELL HOUSING
