Поз.
Артикул
Описание
2
COVER
3
SCREW PLUG , 021,023 FROM TRANSMISSION 024425
4
SEAL RINGTO 001 431 72 14
5
SEAL RING
6
HOUSING WITH PRIMARY PUMP
7
SEAL RING
8
SEAL RING
9
SPRING WASHER
10
SCREW
11
GASKET
11
GASKET , Replaced By: A1122711380
12
SPACER WASHER0.1 MM, NO LONGER AVAILABLE
13
THRUST WASHER
14
SCREW
15
SCREW
17
FLANGE
18
GUARD PLATE
19
SEAL RING
20
FLANGE , 015 FROM TRANSMISSION 005208
21
PISTON
22
BOOT
22
BOOT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3162720792
23
BOOT
24
SPRING
25
SPRING RETAINER
26
SNAP RING
27
OUTER DISC 2.0 MM
28
INNER DISC
29
GUARD PLATE 0.6 MM
30
SPRING
31
GUARD PLATE , 015 FROM TRANSMISSION 005208
32
LOCK
33
DRIVE SHAFT
34
GUARD PLATE , NO LONGER AVAILABLE
54
PLANETARY CARRIER FRONT PLANETARY GEAR TRAIN
55
GUARD PLATE , NO LONGER AVAILABLE
56
GUARD PLATE , NO LONGER AVAILABLE
57
PIN
58
SPRING
59
BALL SHIFTING CYLINDER
60
RING , NO LONGER AVAILABLE
61
LOCK RING
62
SEAL RING DRIVE SHAFT
63
GUARD PLATE , NO LONGER AVAILABLE
64
FLANGE , 015 FROM TRANSMISSION 005208
65
PISTON , NO LONGER AVAILABLE
66
BOOT
66
BOOT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3162720792
67
SPRING
68
BOOT
69
SPRING RETAINER
70
SNAP RING
71
NEEDLE BEARING
72
OUTER DISC 2.0 MM
73
OUTER DISC , 012, 014 FROM TRANSMISSION 001945, 015 FROM TRANSMISSION 007429
74
INNER DISC
75
GUARD PLATE 0.6 MM
84
LOCK
93
SCREW BRACKET TO CROSS CONNECTION STRUT
93
SCREW , Replaced By: N304017008034
94
SPRING WASHER GROUND CABLE TO TRANSMISSION
999
BALL SOCKET , 016 UP TO CHASSIS 027622 EXCEPT FOR, SEE FOOTNOTE 3, 018 UP TO CHASSIS
999
BALL SOCKET , 016: FROM CHASSIS 027623 ALSO INSTALLED ON, SEE FOOTNOTE 3, 018: FROM CHASSIS 028986 ALSO INSTALLED ON, SEE FOOTNOTE 4, 019: F ROM CHASSIS 029326
999
SOLENOID
999
SOLENOID , Replaced By: A0003040590
999
SOLENOID
999
NEEDLE
999
NUT RETAINER HEATER CASE TO FIRE WALL
999
NEEDLE BEARING ,011777
999
LOCK ,022986
999
SHIFT VALVE
999
SHIFT VALVE , NO LONGER AVAILABLE
999
BRACKET , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
GASKET , Replaced By: A1152773280
999
SHIFT VALVE
999
VALVE PART
999
GASKET , Replaced By: A1152772980
999
INTERMEDIATE PLATE , TO 115 270 33 07
999
SHIFT VALVE
999
SHIFT VALVE
999
VALVE BODY ASSEMBLY
999
GASKET , Replaced By: A1152772880
999
COVER
999
HOUSING
999
SHIFT VALVE
999
SHIFT VALVE
999
PISTON
999
VALVE PART
999
PISTON
999
GASKET , 016, 018, 019 FROM TRANSMISSION 052411, 057, 058 FROM TRANSMISSION 025503
999
PISTON
999
GASKET
999
SHIFT VALVE
999
PIN40,15
999
SHIFT VALVE
999
GASKET
999
BUSHING
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
PISTON
999
SCREW , TO 115 270 27 11, 115 270 30 11, 115 270 39 11
999
VALVE PART
999
SCREW , TO 115 270 12 11, 115 270 17 11
999
INTERMEDIATE PLATE ,024694
999
LOCKING SHEET ,019885
999
DETENT
999
INTERMEDIATE PLATE ,024694
999
SPACER WASHER
999
GUIDE
999
SEAL RING
999
BRACKET LINE TO REAR TRANSMISSION CASE,313761
999
DRIVE GEAR , FROM TRANSMISSION: 115.000,002,010,015 018035-026754 115.100,102,103,110,112,115 015266-020935 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A1152741030, +001A1152700327
999
DRIVE GEAR ,015265
999
CASE ,026754
999
SEAL RING , Replaced By: A0119976447
999
DISC SUPPORT , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
GUARD PLATE
999
GUARD PLATE
999
DISC SUPPORT ,017085
999
GUARD PLATE , 013131 EXCEPT FOR 010364-010763
999
FLANGE , WITH 108 270 09 01: UP TO TRANSMISSION 033564 NO LONGER AVAILABLE
999
FLANGE
999
BOOT
999
BOOT
999
SEAL RING
999
BOOT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3162720792
999
PISTON , WITH 108 270 13 01: FROM TRANSMISSION 000001
999
BOOT
999
SEAL RING , 053009
999
PIN
999
PISTON , WITH 108 270 09 01: UP TO TRANSMISSION 033564
999
BOOT
999
BOOT
999
SEAL RING , Replaced By: A3162720455
999
OUTER DISC , Replaced By: A1092722026
999
PLANET GEAR
999
BOOT
999
SEAL RING
999
PISTON
999
ANNULUS , NO LONGER AVAILABLE INDIVIDUALLY
999
SPACER WASHER 0.5 MM,AS REQUIRED
999
SPACER WASHER AS REQUIRED 0.2 MM
999
SPACER WASHER 0.5 MM,AS REQUIRED
999
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.20 MM
999
SPACER WASHER AS REQUIRED 0.5 MM
999
SPACER WASHER AS REQUIRED 0.2 MM
999
FLANGE , WITH 108 270 13 01: FROM TRANSMISSION 011097
999
BRAKE BAND
999
BRAKE BAND
999
TRANSMISSION CASE , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365, Replaced By: A1152705911, +001A1092700689, +001A1092701189
999
BRAKE BAND , Replaced By: A1152707362
999
DRIVE SHAFT , 053009
999
TRANSMISSION CASE , FROM TRANSMISSION: 115.000,002,010,015 031535 115.100,102,103,110,112,115 024366, Replaced By: A1152707711, +001A1152700457
999
BRAKE BAND , Replaced By: A1152707062
999
PLANETARY CARRIER , 053009
999
DRIVE SHAFT ,031316
999
PISTON
999
DRIVE SHAFT ,031316
999
DRIVE SHAFT ,029735043589 NO LONGER AVAILABLE
999
PISTON ,019885
999
DRIVE SHAFT ,031315
999
DRIVE SHAFT , Replaced By: A1152705425, +001A0029942641
999
DRIVE SHAFT , FROM TRANSMISSION: 115.000,002,010,015 015645-043913 115.100,102,103,110,112,115 013132-031415, Replaced By: A1152705925, +001A1152721155
999
FLANGE , 017665-023454 ALSO INSTALLED ON 015709-017194 NO LONGER AVAILABLE
999
VALVE BODY ASSEMBLY
999
DRIVE SHAFT ,022985
999
DRIVE SHAFT ,009363
999
VALVE BODY ASSEMBLY
999
FLANGE , 014863 EXCEPT FOR 013132-014433, Replaced By: A1152704120, +001A1092720326, +002A1092722326
999
TRANSMISSION CASE ,019885
999
PLANETARY CARRIER , FROM TRANSMISSION: 115.000,002,010,015 015645-043913 115.100,102,103,110,112,115 013132-031415, Replaced By: A1152705643, +001A1152721155
999
PLANETARY CARRIER ,009364
999
PLANETARY CARRIER , 013131 EXCEPT FOR 010364-010763
999
GASKET KIT
999
BUSHING
999
GASKET KIT ,019885
999
VALVE BODY ASSEMBLY
999
BUSHING , UP TO TRANSMISSION 000,002,010,015 012077 100,102,103,110,112,115 009785, Replaced By: A1152702150, +001A1152704120, +001A1152721407, +001A1092720326, +002A1092722326
999
GOVERNOR ,024694
999
FLANGE , 017664 EXCEPT FOR 015709-017194, Replaced By: A1152704120, +001A1092720326, +002A1092722326
999
VALVE ,019885
999
VALVE , FROM TRANSMISSION: 115.000,002,010,015 024695-031534 115.100,102,103,110,112,115 019886-024365
999
BUSHING , UP TO TRANSMISSION 000,002,010,015 012077 100,102,103,110,112,115 009785, Replaced By: A1152702150, +001A1152704120, +001A1152721407, +001A1092720326, +002A1092722326
999
VALVE ,024694
999
GUIDE TUBE , AGAINST SQUEALING OF TRANSMISSION
999
TRANSMISSION CASE ,019885
999
THRUST PIN
999
BRACKET
999
SPEEDOMETER DRIVE ,026754, Replaced By: A1152700327, +001A1152700342
999
REGULATOR VALVE
999
FILTER ,025623
999
GASKET KIT , Replaced By: A1152702201
999
FILTER PRESSURE RELIEF VALVE, 016, 018, 019 FROM TRANSMISSION 045659, 057, 058 FROM TRANSMISSION 015959
999
GASKET KIT , Replaced By: A1152702001
999
OIL PAN
999
KNOB
999
BUSHING , UP TO CHASSIS: 000,002,010 056141 015 060261 100,102,103,110,112 139360 115 065085 FROM CHASSIS: 000,002,010 095002 015 115531 100,102,103,110,112 244263 115 122228
999
NUT
