Поз.
Артикул
Описание
5
BEARING BODY FAN DRIVE
8
SCREW TORSION BAR TO REAR AXLE M 8X70
10
NUT BATTERY CASE
11
WASHER TRAILER PLUG SOCKET TO BRACKET
14
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
17
FAN SHAFT
18
FAN SHAFT ,D 276362
18
FAN SHAFT ,D 180260
20
CYLINDR. ROLLER BEARING FAN DRIVE
21
SPACER TUBE
23
LOCK RING52X2 MM
26
BALL BEARING FAN DRIVE
29
SEAL RING CASE COVER
29
RADIAL SEAL RING , Replaced By: A0019978447
32
PULLEY FAN DRIVE
41
NUT SPRING SEAT AND BEARING BRACKET TO REAR AXLE
44
SCREW PLUG AIR DEHYDRATOR
45
GREASE NIPPLE PROTECTIVE TUBE
47
SEAL RING PNEUMATIC VALVE
50
FAN
53
SCREW LINES TO BRACKET
56
LOCK
59
WASHER2.5 MM
59
WASHER1.5 MM
59
WASHER3.2 MM
62
SCREW BALANCING PLATE TO FAN
62
SCREWM 6X16
62
CYLINDRICAL HEAD SCREW. SCREW BALANCING PLATES TO FAN AND TO PULLEY 6X20 MM
65
WASHER PLUG SOCKET TO BRACKET
68
TOOTHED WASHER MASKED STOP LAMP
71
NUT
74
LEVER
83
SCREW LEFT AND RIGHT CONSOLES TO FRAME M 12X1.5X50
86
TIGHTENER PULLEY FAN DRIVE
92
SPACER WASHER0.50 MM
92
SPACER WASHER AS REQUIRED 0.20 MM
98
GROOVED BALL BEARING
104
SPACER TUBE
110
LOCK RING
116
RADIAL SEAL RING
122
LOCK RING ,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3
130
EXPANSION PLUG
147
GASKET COVER TO TIGHTENER PULLEY,212368
148
SCREWM 6X12
149
WASHER PLUG SOCKET TO BRACKET
150
SCREW PLUG 4/2-WAY VALVE
152
SEAL RING PNEUMATIC VALVE
155
SUPPORT TIGHTENER PULLEY
169
SCREW BRACKET TO FRAME M 10X45
173
WASHER GROUND CABLE
176
LOCK WASHER , Replaced By: N912004010102
179
NUT BRACKET TO SIDE MEMBER
179
NUT BRACKET TO RETARDER
182
NUT FUEL TANK TO SUPPORT
185
V-BELT ALTERNATOR 12.5X1000 MM
188
V-BELT FAN
188
V-BELT FROM VIBRATION DAMPER TO TIGHTENER PULLEY 12.5X1825
188
V-BELT FROM TIGHTENER PULLEY TO FAN PULLEY 12.5X925,B 964497D 159626
188
V-BELT
