Поз.
Артикул
Описание
5
CONNECTOR
10
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
13
BRACKET AT CROSS MEMBER
26
BRACKET COMPRESSED AIR LINE TO BRAKE CYLINDER
27
CLAMP DELIVERY AND SUCTION LINES TO FRAME 12/15
27
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
27
CLAMP
27
CLAMP HOSE TO BRACKET 25/20,5 206397
27
CLAMP , Replaced By: A3829950101
27
CLAMP DE-AERATION LINE
27
CLAMP COMPRESSED AIR LINES TO BRACKET AT SUBSTRUCTURE
29
SCREW CLAMP TO BRACKET M 6X25
29
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
32
WASHER PLUG SOCKET TO BRACKET
35
LOCK WASHER CABLE TO FUSE BOX
38
NUT
41
LOOM TIE LINE TO BRACKET 508 MM
41
LOOM TIE WIRING HARNESS FOR AIR CONDITIONING SYSTEM 205 MM
41
LOOM TIE CABLE TO ALTERNATOR
41
LOOM TIE COMPRESSED AIR LINE MOUNTING 381 MM
41
LOOM TIE LINE MOUNTING
41
LOOM TIE ELECTRIC CABLE MOUNTING
41
LOOM TIE , Replaced By: A3459977390
42
LOOM TIE. CLAMP HOSE TO FLANGE AND TO VALVE
42
CLAMP HOSE TO OIL TANK AND TO SUCTION LINE
42
CLAMP HOSE TO HEATING PIPE
42
LOOM TIE , Replaced By: N916017020000
42
CLAMP , Replaced By: N000000000667
42
CLAMP PRESSURE REGULATOR
42
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
44
WASHER , Replaced By: A3609902340
44
WASHER BRACKET TO LEFT SIDE MEMBER
47
ADAPTER FITTING , Replaced By: A0004296934
51
TOOTHED WASHER SENDER UNIT TO BRACKET
53
NUT BRACKET TO SIDE MEMBER
56
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
56
BRAKE HOSE FROM QUICK-RELEASE VALVE TO COMBINATION CYLINDER,RIGHT
56
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
56
BRAKE HOSE LEFT AND RIGHT FRONT WHEEL BRAKE CYLINDERS
56
BRAKE HOSE , Replaced By: A3844207248
68
ELBOW FITTING DIAPHRAGM CYLINDER,CONNECTION: "1,11"
71
T-FITTING DIAPHRAGM CYLINDER
74
CONNECTION FITTING , Replaced By: A0049971772
77
TEST CONNECTION
77
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
77
TEST CONNECTION TIRE INFLATING CONNECTION KNORR
77
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
78
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
79
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
80
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
80
THRUST RING LOCKING VALVE
80
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
