Mercedes
BUS
OH 1625 L
382.074
31 FRAME
001 ENGINE SUPPORT,TRANSMISSION,PEDAL,CONTROL,FRAME,SUSPENSION,BRAKE, STEERING,EXHAU IL.2

Mercedes N000933008288 -

OH 1625 L 382.074

31 FRAME - 001 ENGINE SUPPORT,TRANSMISSION,PEDAL,CONTROL,FRAME,SUSPENSION,BRAKE, STEERING,EXHAU IL.2

Поз.
Артикул
Описание
73
A6642057506
FAN POWER SAVER
73
A0032050506
FAN WITH POWER SAVER FAN
73
A0022058606
FAN , Replaced By: A0032050506
73
A0022056306
FAN POWER SAVER FAN, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
75
A3642007123
FAN
77
A3222050204
HUB POWER SAVER FAN
79
N913002016002
NUT BEARING BRACKET TO SIDE MEMBER
81
N000933008288
SCREW LINES TO BRACKET
82
N913004008005
NUT BRACKET TO SIDE MEMBER
83
A3129940330
LOCK
85
A3012050005
BEARING BODY FAN DRIVE
90
N007603010110
SEAL RING PNEUMATIC VALVE
95
N007604010102
SCREW PLUG 4/2-WAY VALVE
100
A3642057102
FAN SHAFT
100
A3642057002
FAN SHAFT ,D 180260
105
A3642057053
SPACER TUBE
110
N000472052000
LOCK RING52X2 MM
115
A0019978447
SEAL RING CASE COVER
120
A3642057010
PULLEY FAN DRIVE
125
N912004016101
LOCK WASHERROCKINGER TYP 59 G140,59 G150
130
N000936016003
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
135
N005412600304
CYLINDR. ROLLER BEARING FAN DRIVE
140
A3449817025
BALL BEARING FAN DRIVE
143
A6642057004
HUB FAN,D 180260
146
A4752057706
FAN
149
N000933010174
SCREW , Replaced By: N304017010040
152
N009021010102
WASHER A. WASHER BRACKET TO LEFT SIDE MEMBER
155
N913004010011
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
999
N000127006203
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
999
A4752057106
FAN
999
A4752057006
FAN FAN
999
A3645057740
BRACKET , NOT USED
999
A3645057442
MOUNTING PLATE , NOT USED
999
A3645057440
BRACKET , NOT USED
999
A3645057242
MOUNTING PLATE , NOT USED
999
A3645057240
BRACKET , NOT USED
999
A3642007323
FAN ,C 065991
999
A3642007023
FAN ,364.20 052764, 364.28 054098, 364.29 054116C 065990, Replaced By: A3642007323
999
A0002055906
FAN POWER SAVER
