Поз.
Артикул
Описание
5
5
5
ELECTRICAL WIRING HARNESS VOITH RETARDER VOITH 120 -INDIA
5
5
CABLE HARNESS VOITH RETARDER VOITH 123
5
5
5
5
5
5
5
5
8
CABLE HARNESS FROM ELECTRICAL APPARATUS COMPARTMENT TO CHARGING CONTROL
8
CABLE HARNESS (POWER UNIT),CIRCUIT:
8
8
8
8
11
11
CABLE HARNESS ,D 437353
11
11
CABLE HARNESS FROM FUSE BOX TO SWITCH 500 MM
11
CABLE HARNESS
11
11
CABLE HARNESS BATTERY CUT-OFF 500 MM
11
CABLE HARNESS ALTERNATOR-TO-STARTING-MOTOR CABLE
11
14
CABLE HARNESS FROM ELECTRICAL APPARATUS COMPARTMENT PLUG-CONNECTION TO DOOR CONTROL
15
CABLE HARNESS CONNECTOR BETWEEN ELECTR.COMPARTMENT AND ENGINE START/STOP SWITCH
15
CABLE HARNESS CONNECTOR BETWEEN ELECTR.COMPARTMENT AND ENGINE START/STOP SWITCH
15
CABLE HARNESS FROM FUSE BOX TO SWITCH 300 MM
16
CABLE HARNESS ALTERNATOR
16
ELECTRICAL WIRING HARNESS ALTERNATOR-TO-STARTING-MOTOR CABLE
16
CABLE HARNESS ALTERNATOR
16
ELECTRICAL WIRING HARNESS ALTERNATOR
18
CABLE HARNESS INSTRUMENT PANEL
18
18
CABLE HARNESS INSTRUMENT PANEL
18
CABLE HARNESS INSTRUMENT PANEL
18
18
MAIN WIRING HARNESS INSTRUMENT PANEL
18
MAIN WIRING HARNESS INSTRUMENT PANEL
18
PART NAME MISSING CABLE HARNESS INSTRUMENT PANEL EURO 5, WHEN ORDERING, SPECIFY THE VARIANT NUMBER XVK.. ...... FROM VEDOC
18
19
CABLE HARNESS (MAIN CABLE HARNESS) ELECTRICAL COMPARTMENT
19
19
CABLE HARNESS (MAIN CABLE HARNESS) ELECTRICAL COMPARTMENT
19
19
19
CABLE HARNESS ELECTRICAL COMPARTMENT
19
19
19
CABLE HARNESS ELECTRICAL COMPARTMENT
19
MAIN WIRING HARNESS (MAIN CABLE HARNESS) ELECTRICAL COMPARTMENT
19
CABLE HARNESS (MAIN CABLE HARNESS) ELECTRICAL COMPARTMENT
19
MAIN WIRING HARNESS (MAIN CABLE HARNESS) ELECTRICAL COMPARTMENT
19
CABLE HARNESS ELECTRICAL COMPARTMENT
19
PART NAME MISSING (MAIN CABLE HARNESS) ELECTRICAL COMPARTMENT EURO 5, WHEN ORDERING, SPECIFY THE VARIANT NUMBER XVK.. ...... FROM VEDOC
19
CABLE HARNESS (MAIN CABLE HARNESS) ELECTRICAL COMPARTMENT
19
CABLE HARNESS (MAIN CABLE HARNESS) ELECTRICAL COMPARTMENT
19
CABLE HARNESS ELECTRICAL COMPARTMENT
19
CABLE HARNESS (MAIN CABLE HARNESS) ELECTRICAL COMPARTMENT
19
19
CABLE HARNESS ELECTRICAL COMPARTMENT
306
SWITCH , PLEASE REFER TO SERVICE INFORMATION NO.: 04/03., Replaced By: A6965450009, +001A3845427319, +002A3845457726
309
SWITCH STOP LIGHT
309
SWITCH STOP LIGHT SWITCH,D 383712 PLEASE REFER TO SERVICE INFORMATION NO.: 04/03.
312
NUT SWITCH
315
SWITCH BLOCK EXHAUST BRAKE FOOT-OPERATED SWITCH
315
SWITCH , Replaced By: A0045450314, +001A0005465435
318
SPRING WASHER AT CAB FLOOR
321
NUT SUCTION LINE TO OIL PUMP
322
BRACKET LINE MOUNTING
324
BRACKET BATTERY CABLE
325
BRACKET AT CROSS MEMBER
325
BRACKET , Replaced By: A3812950440
327
BRACKET LEFT SIDE MEMBER,D 030553
328
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
328
SCREW BRACKET AND CLAMP M6X20
329
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
329
SCREW BATTERY CABLE TO BRACKET M6X45
330
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
330
NUT BRACKET TO FIRE WALL
331
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
334
SCREW , Replaced By: N910143008000
347
WASHER , Replaced By: A3609902340
347
WASHER BRACKET TO LEFT SIDE MEMBER
349
BRACKET FUEL LINE TO FRAME
351
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
351
NUT HORN TO BRACKET M8
352
LOOM TIE LINE TO BRACKET 508 MM
352
LOOM TIE COMPRESSED AIR LINE MOUNTING 381 MM
352
LOOM TIE LINE MOUNTING
352
LOOM TIE COMPRESSED AIR LINE MOUNTING 105 MM
352
LOOM TIE ELECTRIC CABLE MOUNTING
352
CABLE TIE. LOOM TIE CABLE TO ALTERNATOR
352
LOOM TIE CABLE TO ALTERNATOR
352
LOOM TIE
352
LOOM TIE BATTERY MOUNTING,D 211563
355
CLAMP COMPRESSED AIR LINE
356
HEXAGON HEAD BOLT
357
NUT BATTERY CASE
359
BRACKET ELECTRIC CABLE MOUNTING
360
BRACKET FUEL LINE TO SIDE MEMBER
361
361
SCREW , Replaced By: N910143008000
361
SCREW SPEED SENSOR TO REAR AXLE
363
BRACKET WIRING HARNESS FOR AIR CONDITIONING SYSTEM
364
SCREW , Replaced By: N000000001479
364
SCREW BRACKET TO CAB REAR PANEL M 8X20
364
SCREW CLAMP MOUNTING M 6X16
364
SCREW BATTERY CABLE TO BRACKET M6X45
364
SCREW BUMPER TO REAR CROSS MEMBER M 8X50
364
SCREW SHIFT LEVER TO BRACKET M8X30
364
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
364
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
367
CLAMP , Replaced By: A3829950701
367
CLAMP20-30
367
CLAMP COMPRESSED AIR LINES TO BRACKET AT SUBSTRUCTURE
367
CLAMP
367
CLAMP COMPRESSED AIR LINE TO ENGINE CROSS MEMBER,D 216117
367
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
367
CLAMP DE-AERATION LINE
367
CLAMP HOSE TO BRACKET 25/20,5 206397
367
CLAMP CONNECTING HOSES TO BRACKET
367
CLAMP LINES TO BRACKET
370
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
370
NUT HORN TO BRACKET M8
370
NUT BRACKET TO FIRE WALL
373
CABLE CONNECTOR CABLE CONNECTOR
376
SCREW MOUNTING CABLE CONNECTOR
376
379
NUT RELAY TO BRACKET M5
382
WASHER FUSE TO FUSE BOX
385
CLAMP
385
CLAMP STAY TO BRACKET
385
CLAMP , Replaced By: A3829950701
385
CLAMP SUCTION LINE TO CROSS MEMBER
388
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
388
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
388
SCREW , Replaced By: N910143008002
394
PLUG HOUSING HEATER FLANGE CONNECTOR COVER
397
GASKET
397
GASKET. BLIND PLUG
397
PLUG
400
HOUSING ENGINE HOOD SWITCH ANTI-THEFT ALARM SYSTEM 2-PIN MLK1.2,S62
403
SEAL. GASKET YELLOW,V 215932
403
PLUG SOCKET(0.22 - 0.5) TO A3825405807
999
PLUG SOCKET
999
PLATE
