Поз.
Артикул
Описание
145
FLANGE HEATING AND BREATHING, 415 5 014668 416 5 000515 417 4 972023
150
GASKET. SEAL DE-AERATION PIPE TO ENGINE
152
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
154
SCREW END PIECE TO EXHAUST PIPE M 10X25
160
BRACKET ENGINE CABLE HARNESS PLUG-CONNECTION,5 452356
162
CLAMP FEED LINE TO THERMOSTAT
165
SCREW COVER PLATE TO BRACKET
165
SCREW , Replaced By: N304017008016
165
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
167
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
167
NUT , Replaced By: N910113006001
167
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
167
NUT , Replaced By: N913004008001
170
HOSE , Replaced By: A3875060235
170
HOSE
173
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
173
CLAMP , Replaced By: N000000000667
175
LINE , Replaced By: A3875000072
175
LINE HEATING,MOUNTED TOGETHER WITH RADIATOR AT RUBBER BUFFER, 415 5 014668 416 5 000515 417 4 972023
177
HOSE FROM HEATING PIPE AT RADIATOR TO CAB HEATING PIPE
179
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
179
CLAMP , Replaced By: N000000000667
185
HOSE , Replaced By: A3635060235
185
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR,5 534803
185
HOSE , Replaced By: A3635060135
185
HOSE , Replaced By: A3635060135
188
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
188
CLAMP , Replaced By: N000000000667
188
CLAMP25-40X13 MM
188
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
190
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK 1155 MM,4 635939
190
BREATHER PIPE VENTILATION, FROM RADIATOR TO EXPANSION TANK 1115 MM,4 635938
192
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
192
HOSE ,4 287374
195
CLAMP , Replaced By: N000000000667
195
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
200
BREATHER PIPE FROM ENGINE TO EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
200
BREATHER PIPE FROM ENGINE TO EXPANSION TANK 15X870 MM
202
HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
203
CLAMP , Replaced By: N000000000667
203
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
210
BRACKET , Replaced By: A3855010220
210
BRACKET RADIATOR AND ENGINE BREATHING,AT ENGINE,4 635938
211
BRACKET FUEL LINE TO BELL HOUSING
211
BRACKET , Replaced By: A6454310740
214
SCREW MANUAL PUMP TO BRACKET AND TO PLATE M 10X40
216
WASHER RADIATOR TO RUBBER MOUNTING
216
WASHER , Replaced By: N000125010532
218
NUT , Replaced By: N910113010000
218
NUT STRAP TO BRACKET
220
CLAMP AT BRACKET
220
CLAMP , Replaced By: N916016011202
222
CLAMP DELIVERY AND SUCTION LINES TO STEERING
222
CLAMP , Replaced By: A6739950001
222
CLAMP , Replaced By: A3609951201
222
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
222
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
228
SCREW PIPE CLAMP
228
SCREW , Replaced By: N304017008021
228
SCREW CAB FLOOR COVERING M 6X25
228
SCREW COVER PLATE TO BRACKET
230
NUT , Replaced By: N913004008001
230
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
230
NUT , Replaced By: N913004006001
230
NUT PUMP TO BRACKET
999
CLAMP , Replaced By: A3609950601
999
BRACKET OIL LINE TO TRANSMISSION,REAR LEFT
999
SHIM RUBBER MOUNTING TO BRACKET
999
SHIM RUBBER MOUNTING TO BRACKET
999
SHIM RADIATOR TO RUBBER MOUNTING,4 428845
