Поз.
Артикул
Описание
30
TANK , Replaced By: A3815000849
30
TANK
30
TANK AT CAB REAR PANEL, 415 5 014668 416 5 000515 417 4 972023
32
RADIATOR CAP
36
RADIATOR CAP FILLER NECK
36
RADIATOR CAP FILLER NECK
37
GASKET O.D., 52 MM
38
GASKET O.D., 37 MM
40
BRACKET EXPANSION TANK
40
BRACKET , Replaced By: A6155010020
40
BRACKET EXPANSION TANK, 415 5 014668 416 5 000515 417 4 972023
41
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
42
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
42
SCREW , Replaced By: N304017010028
45
BRACKET EXPANSION TANK
45
BRACKET (STRAP), 415 5 014668 416 5 000515 417 4 972023
47
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
49
SHIM STRAP, 415 5 014668 416 5 000515 417 4 972023
49
SHIM , Replaced By: A3815010495
50
SCREW END PIECE TO EXHAUST PIPE M 10X25
51
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
52
NUT STRAP TO BRACKET
52
NUT , Replaced By: N910113010000
999
NUT , Replaced By: N913004006001
999
NUT PUMP TO BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
WASHER SUPPORTING RAIL TO SUPPORT,5 429712
999
WASHER BRACKET TO RIGHT FENDER, 415 5 014668 416 5 000515 417 4 972023
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET,4 410133
999
BRACKET , Replaced By: A3855010220
999
SUPPORT RADIATOR MOUNTING,4 242404
999
FAN SHROUD , SHORTEN BY 65 MM ON REPALCEMENT DELIVERY UP TO CHASSIS 4 232358, Replaced By: A3835050355
999
SHIM , Replaced By: A3815010295
999
TANK , Replaced By: A3815000749
999
BRACKET , Replaced By: A3815012720
999
HOSE FROM HEATING LINE TO HEATING LINE
999
CLAMP , Replaced By: A3609950601
999
CLAMP , Replaced By: A3609951201
999
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
