Поз.
Артикул
Описание
86
HOSE RELEASE BEARING LUBRICATION
86
HOSE RELEASE BEARING LUBRICATION
89
UNION SCREW RELEASE BEARING LUBRICATION
92
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
95
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
98
NUT BRACKET TO SIDE MEMBER
101
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
104
GREASE NIPPLE RELEASE COLLAR LUBRICATION
107
CAP RELEASE BEARING LUBRICATION
110
PROTECTIVE PLATE BELL HOUSING,5 332727 SEAL DURING ASSEMBLY
113
SCREW END COVER TO BELL HOUSING M6X1X12 MM
116
SPRING WASHER PROTECTIVE PLATE TO BELL HOUSING
119
SLAVE CYLINDER , Replaced By: A3842957307, +001A3842907939
119
SLAVE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. D 187336, Replaced By: A0012959407
119
SLAVE CYLINDER CLUTCH ACTUATION
119
SLAVE CYLINDER CLUTCH ACTUATION
119
SLAVE CYLINDER , Replaced By: A3842957107
119
SLAVE CYLINDER CLUTCH
119
SLAVE CYLINDER CLUTCH ACTUATION
119
SLAVE CYLINDER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 669429, Replaced By: A0022950407
122
BOOT
122
BOOT , Replaced By: A0005863129
122
BOOT
122
BOOTTO 345 295 70 07
125
ROD TO 384 295 71 07,002 295 04 07,94 07
125
ROD TO 384 295 73 07
125
ROD
128
VALVE CLUTCH SLAVE CYLINDER
128
VALVE BREATHER
128
BLEEDER VALVE , Replaced By: A0004310265
131
PROTECTIVE CAP ,5 962906
131
PROTECTIVE CAP , Replaced By: A0004217187
131
PROTECTIVE CAPTO001 295 91 07
131
PROTECTIVE CAPTO001 295 91 07
134
REPAIR KIT , Replaced By: A0002901311
134
REPAIR KIT CLUTCH SLAVE CYLINDER TO 384 295 73 07
134
REPAIR KIT CLUTCH SLAVE CYLINDER
134
REPAIR KIT , Replaced By: A0002901611
134
SLAVE CYLINDER REPAIR KIT
134
REPAIR KIT CLUTCH SLAVE CYLINDER
137
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
140
LOCK WASHER FUSE
143
CIRCLIP POWER CYLINDER TO THROTTLE VALVE LEVER
999
LOCK
999
BOOT
999
ROD , NOT USED
999
BALL SOCKET
999
WASHER , Replaced By: N009021005205
999
BALL SOCKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. D 187336, Replaced By: A6829910022
