Поз.
Артикул
Описание
5
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
5
HOSE , Replaced By: A0009872827
8
FITTING , Replaced By: A0029906171
8
FITTING (PARTS KIT),LINE RUPTURE
15
UNION NUT LINE CONNECTION, Replaced By: N000000006239
15
UNION NUT LINE CONNECTION
20
GLAND , Replaced By: A0019901967
20
SEAL CONE LINE CONNECTION
25
SLEEVE LINE CONNECTION
28
ELBOW FITTING LINE MOUNTING
55
SUPPORT TWO-CIRCUIT BRAKE LINE COUPLING, Replaced By: A3874321016
55
SUPPORT TWO-CIRCUIT BRAKE LINE COUPLING
60
PUMP SUPPORT TO SIDE MEMBER,5 425246
60
ANGLE , Replaced By: A6214320017
60
ANGLE , Replaced By: A6214320117
60
ANGLE FROM T-FITTING TO DIFFERENTIAL LOCK VALVE
60
ANGLE FROM T-FITTING TO DIFFERENTIAL LOCK VALVE
60
ANGLE LEFT
60
ANGLE RIGHT
70
SCREW PIPE CLAMP
70
SCREW , Replaced By: N308676014020
70
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
70
SCREW , Replaced By: N304017008021
75
WASHER , Replaced By: N000125008443
75
WASHER EXHAUST MUFFLER TO STRAP
77
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
77
NUT , Replaced By: N913004008001
78
NUT , Replaced By: N910113014001
78
NUT BRACKET TO SIDE MEMBER
79
BRACKET SUPPORT TO SIDE MEMBER,5 425245
80
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
80
NUT , Replaced By: N913004008001
80
NUT BRACKET TO SIDE MEMBER
80
NUT , Replaced By: N910113014001
81
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
81
SCREW , Replaced By: N308676014020
82
NUT , Replaced By: N910113014001
82
NUT BRACKET TO SIDE MEMBER
83
BRACKET AT SIDE MEMBER,5 425245
84
SCREW BRACKET TO SPRING BRACKET AND TO CROSS MEMBER,5 953233K 027550
85
NUT BRACKET TO SIDE MEMBER,K 035196
85
NUT , Replaced By: N308673014001
88
SUPPORT BRAKE LINE COUPLINGS
90
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
95
NUT , Replaced By: N910113010000
95
NUT STRAP TO BRACKET
100
FITTING BRAKE LINE COUPLING TO BRACKET
105
ELBOW FITTING DELIVERY LINE TO PUMP
110
NUT BRACKET TO SIDE MEMBER
115
TEST CONNECTION
115
TEST CONNECTION , Replaced By: A0004312931
120
FITTING BRAKE LINE COUPLING TO BRACKET
122
ELBOW FITTING ,5 433281
122
ELBOW FITTING DELIVERY LINE TO PUMP
125
NUT BRACKET TO SIDE MEMBER
125
NUT CHECK VALVE TO AIR RESERVOIR
130
TEST CONNECTION , Replaced By: A0004312931
130
TEST CONNECTION
132
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
134
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
142
BRAKE VALVEKNORR, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
142
BRAKE VALVEGRAU, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
142
BRAKE VALVE (TRAILER CONTROL VALVE) BOSCH, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
142
BRAKE VALVEGRAU, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
142
BRAKE VALVE (TRAILER CONTROL VALVE) "GRAU", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
142
BRAKE VALVEWABCO, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING
142
BRAKE VALVE , IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING, Replaced By: A0024314005
144
VALVE SEATTO 001 431 74 05,GRAU 355 029 001
146
VALVE SEATTO GRAU
150
GASKET34X2X6 MM,GRAU
155
SEAL RING64.77X2.62,TO GRAU
160
SEAL RING18X2.5,TO GRAU
165
SEAL RING44.2X3,TO GRAU
170
SEAL RING30X2,TO GRAU
175
SEAL RING7X1.5,TO GRAU
180
SEAL RING22.3X2.4 MM,GRAU
180
SEAL RING21.3X2.4 TO 001 431 74 05,
185
SEAL RING90X3,TO GRAU
190
SEAL RING100X3,TO GRAU
195
SEAL RING39.2X3 TO 001 431 74 05,
195
SEAL RINGTO GRAU
200
SEAL RING9X1.5,TO GRAU
205
SEAL RING23.47X2.62,TO GRAU
211
GASKET KIT SEAL RING TO 002 431 01 05,BOSCH 061 215
212
REPAIR KITTO 003 431 00 05,GRAU 355 064 001
212
REPAIR KIT PISTON TO 002 431 01 05,BOSCH 061 019
212
REPAIR KITTO 003 431 02 05,KNORR,I/87610
225
BRACKET , Replaced By: A6204300510
225
BRACKET TRAILER CONTROL VALVE
235
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
235
NUT , Replaced By: N913004008001
240
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
240
SCREW , Replaced By: N304017008018
240
SCREW SUPPORT TO FENDER
240
SCREW , Replaced By: N304017008027
245
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
245
NUT , Replaced By: N913004008001
266
SCREW , Replaced By: N304017008027
266
SCREW , Replaced By: N304017008018
266
SCREW SUPPORT TO FENDER
266
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
267
NUT , Replaced By: N913004008001
267
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
REPAIR KIT TRAILER CONTROL VALVE "WABCO"
999
REPAIR KIT TRAILER CONTROL VALVE "GRAU"
999
REPAIR KIT , Replaced By: A0014309760
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
VALVE PARKING BRAKE VALVE BOSCH
999
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0034313405
999
BRAKE VALVE , Replaced By: A0024314805
999
FITTING AIR RESERVOIR,CONNECTION: "13"
999
VALVE PARKING BRAKE VALVE KNORR
999
BRAKE VALVE (TRAILER CONTROL VALVE) KNORR, IN CASE OF NOISE MEASUREMENTS,PLEASE REFER TO WORKING INSTRUCTION PRIOR TO ORDERING PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REPAIR KIT , Replaced By: A0004301109
999
BRAKE VALVE (TRAILER CONTROL VALVE) "BOSCH"
999
REPAIR KITTO KNORR
999
BRACKET , Replaced By: A3604293140
999
BRACKET , Replaced By: A3464290840
999
BRACKET CABLE HARNESS MOUNTING
999
SCREW , Replaced By: N304017008023
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
SCREW CABLE HARNESS MOUNTING
