Поз.
Артикул
Описание
104
CLAMP , Replaced By: N000000000667
104
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
108
LINE , NOT USED
116
CLAMP , Replaced By: N000000000667
116
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
116
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
116
CLAMP25-40X13 MM
116
CLAMP25-40X13 MM
120
HOSE , Replaced By: A3859971582
120
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
124
LINE FROM HOSE TO HOSE 22X1.5 MM,5 360279
128
LINE FROM HOSE TO HOSE 22X1,5 MM,5 360279
132
LINE FROM HOSE TO OIL PUMP,5 171759
132
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP 22X1,5 MM,5 360279
132
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP 22X1,5 MM,5 360280
132
LINE FROM PUMP TO HIGH PRESSURE HOSE,5 402173
140
UNION NUT LINE CONNECTION, Replaced By: N000000006243
144
GLAND , Replaced By: A0019901267
144
SEAL CONE LINE CONNECTION
151
LINE FROM PUMP TO HIGH PRESSURE HOSE,5 171759
151
LINE FROM PUMP TO HIGH PRESSURE HOSE 12X1,5 MM,5 360279
151
LINE , Replaced By: A0005516156
151
TUBE FROM HIGH PRESSURE HOSE TO STEERING
151
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP,5 402173
156
UNION NUT LINE CONNECTION, Replaced By: N000000006239
160
GLAND , Replaced By: A0019901967
160
SEAL CONE LINE CONNECTION
164
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
164
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
164
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
168
LINE FROM HIGH PRESSURE HOSE TO HIGH PRESSURE HOSE 12X1,5 MM,5 360279
172
UNION NUT LINE CONNECTION, Replaced By: N000000006239
176
GLAND , Replaced By: A0019901967
176
SEAL CONE LINE CONNECTION
179
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
179
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
179
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
179
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
179
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
179
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
180
LINE FROM HIGH PRESSURE HOSE TO CONNECTION FITTING 12X1,5 MM,5 360279
184
UNION NUT LINE CONNECTION, Replaced By: N000000006239
188
GLAND , Replaced By: A0019901967
188
SEAL CONE LINE CONNECTION
191
FITTING BRAKE HOSE TO COMPRESSED AIR LINE
191
FITTING , Replaced By: A0029906171
191
FITTING (PARTS KIT),LINE RUPTURE
196
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
216
LINE FROM STEERING TO OIL TANK
232
HOSE , Replaced By: A6999974082
232
HOSE , Replaced By: A3859971682
232
HOSE , NOT USED
236
CLAMP HOSE TO FITTING AND TO OIL TANK
236
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
246
BRACKET , Replaced By: A6564660040
246
BRACKET DELIVERY AND SUCTION LINES TO FRAME
250
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
254
NUT SUPPORT TO SIDE MEMBER
262
SCREW , Replaced By: N304017008034
262
SCREW BRACKET TO CROSS CONNECTION STRUT
262
SCREW BRACKET TO SHOCK ABSORBER BRACKET,5 100023
266
NUT , Replaced By: N913004008001
266
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
266
NUT , Replaced By: N913004006001
266
NUT PUMP TO BRACKET
268
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
286
BRACKET , Replaced By: A6164660040
286
BRACKET , NOT USED
290
BRACKET , Replaced By: A6194660140
290
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, RIGHT,5 360279
302
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
306
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
310
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
314
NUT , Replaced By: N913004006001
314
NUT PUMP TO BRACKET
318
SCREW , Replaced By: N304017008021
318
SCREW PIPE CLAMP
320
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
321
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
999
COTTER PIN DRAG LINK TO LEVER
999
BRACKET PIPE LINE TO SHOCK ABSORBER BRACKET,5 360279
999
BRACKET DELIVERY AND SUCTION LINES TO AIR COMPRESSOR,5 402173
999
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6216190040
999
BOOT STEERING COLUMN PANELLING, BLACK,NO.9051, NO.8316I I I I IIINO.7C52I I I II IINO.7B90 III III NO.9051II I
999
PROTECTIVE CAP
999
FITTING DELIVERY LINE TO PUMP
999
NUT DRAG LINK END M 24X1.5
