Поз.
Артикул
Описание
182
NUT STRAP TO BRACKET
182
NUT , Replaced By: N913004008001
182
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
182
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
182
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
182
NUT , Replaced By: N910113014001
182
NUT SUPPORT TO SIDE MEMBER
182
NUT BRACKET TO SIDE MEMBER
182
NUT , Replaced By: N910113010000
193
WASHER , Replaced By: N009021008213
193
WASHER BRACKET TO LEFT SIDE MEMBER
193
WASHER 3/2-WAY VALVE TO BRACKET
193
WASHER 3/2-WAY VALVE TO BRACKET
362
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
367
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
367
TEST CONNECTION
367
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
367
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
370
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
373
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
376
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
379
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
382
T-FITTING RELAY VALVE,CONNECTION "2"
383
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
385
NUT CHECK VALVE TO AIR RESERVOIR
386
O-RING CHECK VALVE TO AIR RESERVOIR
387
THRUST RING CHECK VALVE TO AIR RESERVOIR
387
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
391
VALVE LOAD/NO-LOAD, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
392
REPAIR KIT LOAD/NO-LOAD VALVE
413
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
413
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
416
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
431
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
434
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
437
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
440
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
443
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
443
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
446
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
449
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
449
SCREW PLUG , Replaced By: N000908012009
452
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
452
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
455
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
458
VALVE (3/2-WAY SOLENOID VALVE) "WABCO"
458
VALVE (3/2-WAY SOLENOID VALVE) "WABCO"
458
VALVE (3/2-WAY SOLENOID VALVE) "WABCO"
458
VALVE (3/2-WAY SOLENOID VALVE) "WABCO"
458
VALVE (3/2-WAY SOLENOID VALVE) "WABCO"
467
SEAL RING25X1.5 MM
467
SEAL RING25X1.5 MM
470
SEAL RING5.5X1.5 MM
470
SEAL RING5.5X1.5 MM
472
PROTECTIVE CAPWABCO
474
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
498
HOLLOW SCREW HEATING CONNECTION
498
HOLLOW SCREW HEATING CONNECTION
498
HOLLOW SCREW HEATING CONNECTION
501
SEAL RING LINE CONNECTION
501
SEAL RING LINE CONNECTION
501
SEAL RING LINE CONNECTION
501
SEAL RING LINE CONNECTION
501
HOLLOW SCREW LINE CONNECTION
504
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
504
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
507
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "40"
510
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
510
SCREW PLUG , Replaced By: N000908012009
549
VALVE , Replaced By: A0044294944
549
VALVE (SHUTTLE VALVE)
552
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
555
THRUST RING CHECK VALVE TO AIR RESERVOIR
555
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
558
O-RING CHECK VALVE TO AIR RESERVOIR
561
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
564
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
597
BRACKET NO-LOAD/LOAD VALVE
600
BRACKET , Replaced By: A3765010920
600
BRACKET BRACKET TO CROSS MEMBER
600
BRACKET , Replaced By: A6205243040
609
SCREW , Replaced By: N304017008034
609
SCREW BRACKET TO CROSS CONNECTION STRUT
609
SCREW BRACKET TO CROSS CONNECTION STRUT
609
SCREW BRACKET TO CROSS CONNECTION STRUT
609
SCREW BRACKET TO CROSS CONNECTION STRUT
612
WASHER EXHAUST MUFFLER TO STRAP
612
WASHER EXHAUST MUFFLER TO STRAP
612
WASHER BRACKET TO LEFT SIDE MEMBER
612
WASHER , Replaced By: N009021008213
612
WASHER , Replaced By: N000125008443
615
NUT , Replaced By: N913004008001
615
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
615
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
FITTING , Replaced By: A0009905070
999
BRACKET LOAD/NO-LOAD VALVE
999
BRACKET RIGHT SIDE MEMBER
999
BRACKET LEFT SIDE MEMBER
999
PROTECTIVE PLATE FRONT AXLE TWO-WAY VALVE
999
PROTECTIVE PLATE , Replaced By: A6244210120
999
BRACKET SENSOR CABLE
999
BRACKET RELAY VALVE, NOT USED
999
LINE FROM 3/2-WAY VALVE TO DISTRIBUTOR
999
PIPE SOCKET COMPRESSED AIR PIPING TO 3/2-WAY VALVE
999
FITTING RELAY VALVE,CONNECTION "20",LEFT
999
CONTROL UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO.5 186367 IN CASE OF "C" ELECTRONICS WITH ASR, EXCHANGE 006 545 27 32 FOR 013 545 05 32, Replaced By: A0045458432
999
VALVE
999
CONTROL UNIT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 042987, Replaced By: A0035452832
999
T-FITTING LEFT AND RIGHT BRAKE HOSES
999
T-FITTING AIR RESERVOIR,CONNECTION: "31"
999
CONTROL UNIT , Replaced By: A0025454932
999
CROSS FITTING AIR RESERVOIRS I AND II,4 821954 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
ABS ELECTRONICS , Replaced By: A0004461114
999
VALVE PART , Replaced By: A0029971236
999
ADAPTER FITTING , Replaced By: A0004296934
999
ADAPTER FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "22"
999
ADAPTER FITTING , Replaced By: A0069970072
999
LINE FROM FOUR-CIRCUIT PROTECTIVE VALVE TO AIR RESERVOIR 9X12 MM, LENGTH AVAILABLE 3000 MM
