Поз.
Артикул
Описание
198
HOUSING BELL HOUSING WITH BUSHINGS,5 285576
198
HOUSING BELL HOUSING WITH BUSHINGS
198
HOUSING , Replaced By: A4032505405, +001A6202500155
198
HOUSING ,5 285575, Replaced By: A6212500305, +001A6202500155
202
BUSHING RELEASE SHAFT,BOTTOM
206
BUSHING RELEASE SHAFT,BOTTOM 24X27 MM
210
BUSHING RELEASE SHAFT,TOP
210
BUSHING ,5 285575, Replaced By: A6202510050, +001A6202500155, +001A0099971547
214
BUSHING RELEASE SHAFT,TOP 35X39 MM
218
SEAL RING RELEASE SHAFT,TOP
222
SEAL RING RELEASE SHAFT,TOP 40X52X7 MM
222
SEAL RING RELEASE SHAFT,BOTTOM 40X52X11 MM
226
COVER PLATE RELEASE SHAFT,TOP
230
SHAFT (PARTS KIT),RELEASE SHAFT
230
SHAFT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 285575, Replaced By: A3852500014
230
REPAIR KIT , Replaced By: A3892500014
234
WASHER AS REQUIRED 1.20 MM
234
WASHER AS REQUIRED 0.90 MM
234
WASHER AS REQUIRED 1.00 MM
234
WASHER AS REQUIRED 0.80 MM
234
WASHER AS REQUIRED 1.10 MM
234
WASHER AS REQUIRED 1.3 MM
238
SEAL RING BOTTOM
242
SPACER WASHER RELEASE SHAFT,BOTTOM
246
LOCK RING RELEASE SHAFT,BOTTOM
250
RELEASE LEVER CLUTCH ACTUATION
254
LOCK WASHER FITTING TO BRACKET
258
SCREW RELEASE LEVER TO SHAFT
258
SCREW , Replaced By: N000933012102
258
SCREW , Replaced By: N304017012018
262
PLUG BELL HOUSING
262
PLUG BELL HOUSING
264
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
265
WASHER RADIATOR TO RUBBER MOUNTING
265
WASHER , Replaced By: N000125010532
266
SCREW RADIATOR M 10X45
270
RELEASE BEARING CLUTCH
274
SPRING RELEASE BEARING TO RELEASE LEVER
282
HOSE RELEASE COLLAR LUBRICATION 220 MM
284
GREASE NIPPLE (PARTS KIT) RELEASE BEARING LUBRICATION
286
SCREW-IN FITTING RELEASE COLLAR LUBRICATION
287
UNION SCREW RELEASE COLLAR LUBRICATION
290
DOUBLE TAPER RING RELEASE COLLAR LUBRICATION
302
GREASE NIPPLE RELEASE COLLAR LUBRICATION
302
INTERMEDIATE PIECE ,5 190179, Replaced By: A6209970088, +001A6209880135
306
GREASE CUP ,5 190179, Replaced By: A6209880135, +001A6209970088
306
CAP RELEASE BEARING LUBRICATION
308
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
310
NUT , Replaced By: N308675014000
310
NUT , Replaced By: N308675014002
310
NUT RELEASE BEARING LUBRICATION
312
LEVER (PARTS KIT),CLUTCH ACTUATION
314
ROD END CLUTCH ACTUATION
318
PIN CLUTCH ACTUATION
322
SEAL RING CLUTCH ACTUATION
322
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019972141
326
LOCK RINGTO 000 553 37 01,000 553 39 01,
330
COVER RELEASE SHAFT,TOP
330
WASHER , Replaced By: A6202540176
330
WASHER LEVER TO RELEASE SHAFT,5 285575
334
SEAL RING LEVER TO RELEASE SHAFT,5 285575
338
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
342
SCREW MOUNTING AND RAIL TO LEAF SPRING
346
BRACKET CLUTCH ACTUATION
350
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
354
SCREW BRACKET TO SIDE MEMBER
354
SCREW , Replaced By: N304017010002
358
SLAVE CYLINDER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0012956707
358
SLAVE CYLINDER CLUTCH ACTUATION WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
358
SLAVE CYLINDER CLUTCH ACTUATION KONGSBERG
358
SLAVE CYLINDER CLUTCH ACTUATION KNORR
360
BOOTWABCO
362
BOOTWABCO
364
REPAIR KIT , NOT USED
365
REPAIR KIT CLUTCH SLAVE CYLINDER TO 001 295 31 07,WABCO 970 051 113 0
365
SEAL RING. REPAIR KIT CLUTCH SLAVE CYLINDER WABCO
366
SPRING WASHER STEERING COLUMN BRACKET TO CAB
370
SCREW CLUTCH BOOSTER TO BELL HOUSING M 10X30,5 962907
370
SCREW , Replaced By: N914146010114
371
COVER PLATE , THE OLD PART MUST NO LONGER BE INSTALLED THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3972510083, +002A0002510183
372
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
372
SCREW , Replaced By: N304017008016
373
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
374
SCREW SUPPORTING ARM TO CYLINDER CRANKCASE M 18X60
374
SCREW , Replaced By: N308676018010
378
LOCK WASHER BELL HOUSING TO TRANSMISSION
999
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
999
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002523919, +002A0002523975
999
RIVET , Replaced By: A0002523775
999
RIVET , Replaced By: A0002524675
999
LEAF SPRING
999
RIVET LEAF SPRING TO CLUTCH DISC
999
RIVET , Replaced By: A0002524875
999
RIVET LINING WITH CLUTCH DISC
999
CLUTCH BOOSTER. REPAIR KIT CLUTCH SLAVE CYLINDER KONGSBERG
999
BOOTKONGSBERG
999
BOOTKONGSBERG
999
CLUTCH LINING
999
CLUTCH LINING , Replaced By: A0012528310
999
CLUTCH LINING , Replaced By: A0022520010
999
SLAVE CYLINDER , Replaced By: A0012953107
999
CLUTCH LINING ASBESTOS-FREE
999
LEVER , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE5 388425, Replaced By: A6242950028, +001A6242950140
