Поз.
Артикул
Описание
999
GASKET HEATING PIPE TO ENGINE
999
CLAMP , Replaced By: N000000000670
999
CLAMP , Replaced By: N000000000667
999
CLAMP , Replaced By: N916017011001
999
NUT , Replaced By: N913004006001
999
NUT PUMP TO BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW COVER PLATE TO COVER PLATE M 6 X 12
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER , Replaced By: N009021006208
999
SCREW , Replaced By: N000000001146
999
SCREW PLUG WATER DRAIN
999
SEAL RING FUEL LINE TO FEED PUMP
999
SCREW , Replaced By: A4609900601
999
SCREW , Replaced By: N304017008016
999
SCREW COVER PLATE TO BRACKET
999
SCREW , Replaced By: N304017006018
999
SCREW COVER PLATE TO BRACKET
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125008443
999
SCREW CLAMP MOUNTING M 6X16
999
CLAMP
999
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
999
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
999
HOSE FROM WATER PUMP TO EXPANSION TANK
999
PIPE ELBOW , Replaced By: A6555011556
999
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR
999
BRACKET HEATING PIPE
999
HOSE FROM ENGINE CONNECTION FLANGE TO HEATING PIPE AT RADIATOR
999
HOSE , Replaced By: A6205012882
999
HOSE (DE-AERATION LINE) FROM RADIATOR TO EXPANSION TANK
999
HOSE
999
HOSE , Replaced By: A6585010082
999
BREATHER PIPE (DE-AERATION LINE) FROM RADIATOR TO EXPANSION TANK
999
CONNECTOR AT WATER PUMP
999
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR
999
FLANGE DE-AERATION,5 301948
999
LINE FROM WATER PUMP TO EXPANSION TANK
999
FLANGE (DE-AERATION LINE) FROM EXPANSION TANK TO ENGINE,5 301949
999
SCREW EXHAUST PIPE TO BRACKET
999
BRACKET HEATING PIPE TO FAN SHROUD BRACKET
999
CLAMP FEED LINE TO THERMOSTAT
999
HOSE
999
HOSE OVERFLOW, EXPANSION TANK
999
HOSE , Replaced By: A0219977682
999
SCREW PLUG , Replaced By: N007604014101
999
CLAMP , Replaced By: N916017011000
999
RADIATOR
999
RADIATOR CAP FILLER NECK
999
RADIATOR CAP CENTRAL
999
RADIATOR , Replaced By: A0005019101
999
RADIATOR CAP FILLER NECK
999
RADIATOR CAP CENTRAL
999
GASKET O.D., 37 MM
999
GASKET O.D., 52 MM
999
DRAIN PIPE EXPANSION TANK
999
TANK ON RADIATOR
