Поз.
Артикул
Описание
2
FITTING AIR COMPRESSOR,CONNECTION: "10"
4
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
6
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
8
NUT LINE CONNECTION
8
UNION NUT LINE CONNECTION, Replaced By: N000000006243
10
SEAL CONE LINE CONNECTION
10
GLAND , Replaced By: A0019901267
12
HOSE AIR COMPRESSOR CONNECTION 240 MM, ORDER BY THE METER
14
CLAMP25-40X13 MM
14
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
18
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
18
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
20
UNION NUT BUTT SCREW CONNECTION
22
GLAND LINE CONNECTION
24
THRUST RING BUTT SCREW CONNECTION
26
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
26
SEAL RING , Replaced By: N007603012121
28
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
30
BULKHEAD FITTING THROUGH SIDE MEMBER, BUTT CONNECTION
32
NUT CHECK VALVE TO AIR RESERVOIR
35
CLAMP DELIVERY AND SUCTION LINES TO STEERING
35
CLAMP , Replaced By: A6739950001
37
BRACKET AIR COMPRESSOR LINE
38
SCREW CLAMP MOUNTING M 6X16
38
SCREW , Replaced By: N000000001146
42
NUT PUMP TO BRACKET
42
NUT , Replaced By: N913004006001
46
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
178
PRESSURE REGULATOR , Replaced By: A0024314906
182
REPAIR KITTO 002 431 15 06,WABCO, 975 300 750 0,5 161700
182
REPAIR KIT , Replaced By: A0004301107
188
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
188
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
188
NUT , Replaced By: N913004008001
190
HOSE PRESSURE REGULATOR,CONNECTION: "30", ORDER BY THE METER
190
INSULATING HOSE PRESSURE REGULATOR,CONNECTION "3", ORDER BY THE METER5 148812
192
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
192
CLAMP , Replaced By: N000000000667
192
HOSE CLAMP LINE MOUNTING
192
CLAMP , Replaced By: A0059970190
194
LOOM TIE LINE MOUNTING 280 MM
200
ELBOW FITTING ANTI-FREEZE DEVICE,CONNECTION: "10", BUTT CONNECTION
202
FITTING AIR RESERVOIR,CONNECTION: "13"
203
NUT CHECK VALVE TO AIR RESERVOIR
204
O-RING CHECK VALVE TO AIR RESERVOIR
206
THRUST RING CHECK VALVE TO AIR RESERVOIR
206
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
GUIDE , Replaced By: N071752014000
999
SEAL RINGKNORR
999
SEAL RINGKNORR
999
CUPTO 008 420 97 18, 008 420 90 18, BOSCH
999
PROTECTIVE CAPTO 008 420 62 18,KNORR
999
ADAPTER FITTING LINE CONNECTION TO ENGINE
999
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
999
MUFFLER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847992, Replaced By: A6174310073
999
REPAIR KITTO 000 429 26 95,KNORR
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KIT TRISTOP CYLINDER TO 008 420 95 18, 008 420 97 18, BOSCH
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE WABCO
999
REPAIR KIT SEAL RING BOSCH,209
999
DIAPHRAGM , Replaced By: A0004314128
999
DIAPHRAGM , Replaced By: A0004314128
999
VALVEWABCO
999
DIAPHRAGMTO 008 420 61 18,009 420 22 18
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
CONNECTOR REPAIR SIZE
999
BUSHING , Replaced By: N915062009000
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK ELECTRIC CABLE THRU CAB FLOOR
999
SCREW. UNION SCREW LINE CONNECTION
999
HANDLEKNORR
999
PLUGTO 009 420 22 18,008 420 20 18
999
PLUG
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
PRESSURE REGULATOR , Replaced By: A0024314906
999
PROTECTIVE CAPKNORR
999
PRESSURE REGULATOR ,5 148812, Replaced By: A0024314306
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
ELBOW FITTING AIR RESERVOIR,CONNECTION: "13", PLUG CONNECTION
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
PRESSURE REGULATORWABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 181111 10/50 616.121,122,131,1325 208196 20/60 616.121,122,131,1325 297633 616.024,026,027,028,065
999
ELBOW FITTING ,5 433281
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 433280
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,000 2
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
REPAIR KIT SPRING LOAD ACCUMULATOR CYLINDER TO 008 420 20 18,KNORR
999
SEAL RINGKNORR
999
ADHESIVE FOIL GUIDE SIGN
999
BRAKE HOSE , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847992, Replaced By: A6174310073
999
FITTING , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 847992, Replaced By: A6174310073
999
BRACKET FRAME MOUNTED CABLE HARNESS TO RIGHT SIDE MEMBER
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
WASHER STRAP TO SUPPORT
999
CLAMPING SLEEVEKNORR
999
CONNECTION FITTING ENGINE AIR COMPRESSOR,CONNECTION: "15"
999
BULKHEAD FITTING THROUGH SIDE MEMBER
999
FITTING AIR DEHYDRATOR,CONNECTION: "10",5 350368
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
999
WASHER , Replaced By: N009021005205
999
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
999
YOKETO 008 420 95 18,008 420 97 18,BOSCH
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N910113010000
999
UNION NUT LINE CONNECTION
999
HOLLOW SCREW HEATING CONNECTION
999
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
999
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
