Поз.
Артикул
Описание
20
SCREW CONNECTOR TO EXHAUST MANIFOLD
24
NUT CONNECTOR TO EXHAUST MANIFOLD
36
FLEXIBLE METAL TUBE FRONT EXHAUST PIPE FRONT PART TO REAR PART
38
COLLAR FRONT EXHAUST PIPE FRONT PART TO REAR PART
41
CLAMP FLEXIBLE METAL TUBE TO EXHAUST PIPE
44
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
47
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
74
BRACKET RIGHT EXHAUST PIPE
74
BRACKET LEFT EXHAUST PIPE
74
BRACKET RIGHT EXHAUST PIPE,5 129244
74
BRACKET LEFT EXHAUST PIPE,5 129244
77
SCREW REAR EXHAUST PIPE TO MUFFLER
80
NUT STRAP TO BRACKET
80
NUT , Replaced By: N910113010000
83
CLAMP AT CROSS MEMBER
83
CLAMP EXHAUST PIPE TO BRACKET
86
SCREW BRACKET TO SIDE MEMBER
86
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
86
SCREW , Replaced By: N304017008027
89
NUT STRAP TO BRACKET
89
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
89
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
89
NUT , Replaced By: N913004008001
95
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
95
CLAMP , Replaced By: N071555094502
98
SCREW BRACKET TO SIDE MEMBER
98
SCREW , Replaced By: N304017010002
101
NUT STRAP TO BRACKET
101
NUT , Replaced By: N910113010000
999
SCREW CONNECTING PIPE TO EXHAUST MANIFOLD M 12X45
