Поз.
Артикул
Описание
10
SIDE MEMBER EXTERIOR,REAR,LEFT
10
SIDE MEMBER EXTERIOR,REAR,LEFT
20
SIDE MEMBER EXTERIOR,REAR,RIGHT
20
SIDE MEMBER EXTERIOR,REAR,RIGHT,357677620100831
30
SIDE MEMBER INTERIOR,REAR,LEFT, NO LONGER AVAILABLE
30
SIDE MEMBER INTERIOR,REAR,LEFT, NO LONGER AVAILABLE
30
SIDE MEMBER INTERIOR,REAR,LEFT
30
SIDE MEMBER INTERIOR,REAR,LEFT
30
SIDE MEMBER INTERIOR,REAR,LEFT
30
SIDE MEMBER INTERIOR,REAR,LEFT, NO LONGER AVAILABLE
40
SIDE MEMBER INTERIOR,REAR,LEFT, NO LONGER AVAILABLE
40
SIDE MEMBER INSIDE REAR RIGHT, 21646320051222
40
SIDE MEMBER INSIDE REAR RIGHT, 48050720090831
60
CROSS MEMBERNO.5
60
CROSS MEMBERNO.5
80
CROSS MEMBER , 20120329
80
CROSS MEMBER , 20120329
100
CROSS MEMBER END CROSSMEMBER INNER
100
CROSS MEMBER END CROSSMEMBER INNER
120
STRIKING PLATE D-PILLAR, BOTTOM LEFT,357677620100831
120
END PIECE D-PILLAR LOWER LEFT
140
END PIECE D-PILLAR, BOTTOM RIGHT
140
STRIKING PLATE D-PILLAR, BOTTOM RIGHT,357677620100831
160
TOWING EYE AT SIDE MEMBER
180
HEXAGON HEAD BOLT. SCREW RUBBER BUFFER TO SUPPORT M 12X90
200
NUT BRACKET TO SIDE MEMBER M12X1.5
220
HEXALOBULAR BOLT BRACKET TO BRACKET M 10X30
240
SEAT CUSHION ON FLOOR
260
COVER AT CROSS MEMBER NO.5
260
COVER AT CROSS MEMBER NO.5,357677520100831
280
GUSSET PLATE AT SIDE MEMBER,OUTSIDE
300
CONSOLE SPARE WHEEL CARRIER
310
BEARING BRACKET WITHOUT REINFORCEMENT PLATE
320
REINFORCEMENT SPARE WHEEL CARRIER
340
PLATE AT REAR CROSS MENBER
360
PLATE MOUNTING, SENSOR
