Поз.
Артикул
Описание
5
PANELLING RIGHT FENDER
5
PANELLING LEFT FENDER
5
PANELLING LEFT FENDER,360347120100831
5
PANELLING RIGHT FENDER
5
FRONT FENDER RIGHT
5
FRONT FENDER WITH CUTOUT FOR LEFT TURN SIGNAL
5
PANELLING RIGHT FENDER,360347120100831
5
PANELLING LEFT FENDER,360347120100831
5
FRONT FENDER WITH CUTOUT FOR RIGHT TURN SIGNAL
5
5
5
5
FENDER LEFT
5
FENDER RIGHT
8
SEALING FRAME REPAIR SOLUTION 10 X 15 MM
10
SEALING FRAME REPAIR SOLUTION 10 X 15 MM
10
INTERMEDIATE LAYER BETWEEN FENDER, LEFT ANDBUMPER
10
INTERMEDIATE LAYER BETWEEN FENDER, RIGHT ANDBUMPER
13
LOCK FENDER TO BODY
20
SCREW LEVER TO SHAFT
20
SCREW-AND-WASHER ASSEMBLY MOUNTING, COVER M5X12
20
SCREW. HEXALOBULAR BOLT COVER TO MOUNTING FRAME M5X12
23
WASHER CABLE CONNECTOR TO BRACKET AND TO FRAME,RESP.
25
HEXALOBULAR BOLT BRACKET ON TUBULAR SUPPORTING FRAMEWORK M6X12
25
SCREW-AND-WASHER ASSEMBLY LEFT COVERING M6X17, A 26014720070403
30
BRACKET LEFT FENDER
35
BRACKET RIGHT FENDER
35
BRACKET LEFT FENDER
40
BLIND RIVET. RIVET FAN SHROUD
45
PARTS KIT FRONT FENDER MOUNTING MATERIAL
48
WASHER SHIM
50
PANELING LEFT FRONT WHEEL ARCH
50
TRIM PANEL WHEEL HOUSING LEFT FRONT WHEEL ARCH,360347220100831
50
PANELING RIGHT FRONT WHEEL ARCH
50
50
TRIM PANEL WHEEL HOUSING RIGHT FRONT WHEEL ARCH,360347220100831
50
PANELING RIGHT FRONT WHEEL ARCH
50
50
TRIM PANEL WHEEL HOUSING LEFT FRONT WHEEL ARCH
50
PANELING LEFT FRONT WHEEL ARCH
50
TRIM PANEL WHEEL HOUSING RIGHT FRONT WHEEL ARCH
55
PLASTIC NUT. NUT
60
FASTENER BUTTON. PUSH BUTTON RIGHT PANELLING
65
RIVET
65
RIVET COVERING TO SIDE MEMBER
68
RIVET
70
BRACKET WHEEL SPEED SENSOR AND BRAKE PAD INDICTOR ON FRONT AXLE, A 290167 EXCEPT CODE 805 ALSO INSTALLED IN VEHICLE TO A 290166 WITH CODE 806
100
LOCK NUT BRACKET TO RIGHT FRONT SIDE MEMBER ST 4.8/2.5-5.0 MM
105
TAPPING SCREW STEERING COLUMN MOUNTED SWITCH PLUGCONNECTION 4.8X13
110
SEAL ENGINE COMPARTMENT,RIGHT
110
SEAL ENGINE COMPARTMENT,LEFT
110
SEAL ENGINE COMPARTMENT,RIGHT
110
SEAL ENGINE COMPARTMENT,LEFT
130
130
GRAVEL PROTECTION FILM TO FENDER LEFT,374531620120427
130
GRAVEL PROTECTION FILM TO FENDER RIGHT,374531620120427
130
200
RIVETED NUT
