Поз.
Артикул
Описание
75
PROPELLER SHAFT FROM PROPELLER SHAFT BEARING I TO PROPELLER SHAFT BEARING II 1312 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
78
PROPELLER SHAFT FROM TRANSMISSION TO PROPELLER SHAFT BEARING 872 MM
81
DRIVE FLANGE
84
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
84
UNIVERSAL JOINT CROSS , Replaced By: A9404100031
87
GREASE NIPPLE
90
LOCK AS REQUIRED 2.20 MM
90
LOCK AS REQUIRED 2.00 MM
90
LOCK AS REQUIRED 2.10 MM
96
LOCK WASHERROCKINGER TYP 59 G140,59 G150
99
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
99
NUT , Replaced By: N308673016001
170
PROPELLER SHAFT FROM TRANSMISSION TO REAR AXLE I 1618 MM, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
180
DRIVE FLANGE
186
UNIVERSAL JOINT CROSS , Replaced By: A9404100031
186
UNIVERSAL JOINT CROSS WITH BUSHINGS, IF REQUIRED,ORDER LOCK RINGS ADDITIONALLY
192
GREASE NIPPLE
198
LOCK AS REQUIRED 2.00 MM
198
LOCK AS REQUIRED 2.20 MM
198
LOCK AS REQUIRED 2.10 MM
210
SCREWM 16X16X20X45
210
SCREW , Replaced By: A3959900501
216
LOCK WASHERROCKINGER TYP 59 G140,59 G150
222
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
222
NUT , Replaced By: N308673016001
999
SPACER WASHER PROPELLER SHAFT BEARING
999
SEAL RING PROTECTIVE TUBE 105X17 MM
999
SEAL RING PROTECTIVE TUBE 102.5X22 MM
