Поз.
Артикул
Описание
5
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
5
LINE FROM OIL TANK TO HOSE
5
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
5
LINE FROM OIL TANK TO HOSE
5
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
5
LINE , Replaced By: A0004291601
5
LINE FROM OIL TANK TO HOSE
8
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
8
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
8
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
8
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
8
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
8
LINE FROM PUMP TO HIGH PRESSURE HOSE
8
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
11
NUT LINE CONNECTION
11
UNION NUT LINE CONNECTION, Replaced By: N000000006243
14
GLAND , Replaced By: A0019901267
14
SEAL CONE LINE CONNECTION
17
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
17
SCREW-IN FITTING SUCTION LINE TO OIL PUMP
18
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
20
FITTING DELIVERY LINE TO PUMP
20
SCREW-IN FITTING OIL LINE CONNECTION
21
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
23
LINE FROM PUMP TO HIGH PRESSURE HOSE
23
LINE FROM PUMP TO HIGH PRESSURE HOSE
23
LINE FROM PUMP TO HIGH PRESSURE HOSE
23
LINE FROM PUMP TO HIGH PRESSURE HOSE
23
LINE FROM PUMP TO HIGH PRESSURE HOSE
23
LINE FROM PUMP TO HIGH PRESSURE HOSE
23
LINE FROM PUMP TO HIGH PRESSURE HOSE
23
LINE FROM PUMP TO HIGH PRESSURE HOSE
23
LINE FROM PUMP TO HIGH PRESSURE HOSE
23
LINE FROM PUMP TO HIGH PRESSURE HOSE
26
LINE FROM HIGH PRESSURE HOSE TO STEERING
26
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING, Replaced By: A0005516156, +002A0019901967, +002N915017012100
26
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
26
LINE FROM HIGH PRESSURE HOSE TO STEERING
26
LINE FROM HIGH PRESSURE HOSE TO STEERING
26
TUBE FROM HIGH PRESSURE HOSE TO STEERING
26
LINE FROM HIGH PRESSURE HOSE TO STEERING
26
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
26
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
26
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
26
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
26
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
29
UNION NUT LINE CONNECTION, Replaced By: N000000006239
29
UNION NUT LINE CONNECTION
32
GLAND , Replaced By: A0019901967
32
SEAL CONE LINE CONNECTION
35
SCREW-IN FITTING OIL LINE CONNECTION
35
SCREW-IN FITTING DELIVERY LINE TO PUMP
38
SCREW-IN FITTING OIL LINE CONNECTION
39
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
40
SEAL RING VALVE TO VALVE,K 025179
41
SCREW-IN FITTING , Replaced By: N003901015005
41
SCREW-IN FITTING , Replaced By: N003901015003
41
SCREW CONNECTION RETURN, FROM STEERING TO OIL TANK
41
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
44
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
44
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
44
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
44
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
44
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
44
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
44
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
44
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
44
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
47
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
50
CLAMP , Replaced By: N000000000667
50
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
53
LINE RETURN, FROM STEERING TO OIL TANK
53
LINE , Replaced By: A0005516256
53
LINE RETURN, FROM STEERING TO OIL TANK
53
LINE RETURN, FROM STEERING TO OIL TANK
53
LINE RETURN, FROM STEERING TO OIL TANK
53
LINE FROM PUMP TO HIGH PRESSURE HOSE
53
LINE RETURN, FROM STEERING TO OIL TANK
53
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
53
LINE RETURN, FROM STEERING TO OIL TANK
53
LINE RETURN, FROM STEERING TO OIL TANK
56
UNION NUT LINE CONNECTION
59
GLAND LINE CONNECTION
62
HOSE DELIVERY LINE TO STEERING
62
HOSE RETURN, FROM STEERING TO OIL TANK
65
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
65
CLAMP , Replaced By: N000000000667
65
CLAMP HOSE TO FITTING AND TO OIL TANK
68
BRACKET DELIVERY AND SUCTION LINES TO FRAME
68
BRACKET DELIVERY AND SUCTION LINES TO FRAME
71
CLAMP DELIVERY AND SUCTION LINES TO FRAME
71
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
71
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
71
CLAMP DELIVERY AND SUCTION LINES TO STEERING
71
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
FITTING SUCTION LINE TO OIL PUMP
999
BRACKET OIL TANK
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE
999
BRACKET FUEL LINES TO TRANSMISSION
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
ANGLE LINE MOUNTING
999
SEALING CORD SUCTION LINE TO OIL PUMP
999
THRUST RING SUCTION LINE TO OIL PUMP
