Поз.
Артикул
Описание
352
BRACKET AIR RESERVOIR,K 049747
360
BRACKET AIR RESERVOIR
360
BRACKET AIR RESERVOIR
360
BRACKET AIR RESERVOIR,K 049747
364
HEXAGON HEAD BOLT. SCREW VIBRATION ABSORBER TO BRACKET M 10X65
364
SCREW , Replaced By: N910105010012
368
CONSOLE AIR RESERVOIR TO APPARATUS SUPPORT
376
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
376
SCREW , Replaced By: N304017008016
384
WASHER RADIATOR TO RUBBER MOUNTING
384
WASHER RADIATOR TO RUBBER MOUNTING
384
WASHER , Replaced By: N000125010532
392
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
392
NUT , Replaced By: N913004008001
416
RESERVOIR10L,206 MM,8.5 BAR
456
VALVE. DRAIN VALVE DRAIN
456
VALVE DRAIN, Replaced By: A0004322107
462
BRACKET AIR RESERVOIR
462
BRACKET CLUTCH BOOSTER AIR RESERVOIR
462
BRACKET CLUTCH BOOSTER AIR RESERVOIR
462
BRACKET CLUTCH BOOSTER AIR RESERVOIR
462
BRACKET AIR RESERVOIR TO CROSS MEMBER
462
BRACKET AIR RESERVOIR TO CROSS MEMBER
474
SCREW PIPE CLAMP
474
SCREW BRACKET TO CROSS CONNECTION STRUT
474
SCREW BRACKET TO CROSS MEMBER
474
SCREW PIPE CLAMP
474
SCREW , Replaced By: N304017008021
474
SCREW BRACKET TO CROSS CONNECTION STRUT
474
SCREW , Replaced By: N304017008034
476
WASHER BRACKET TO LEFT SIDE MEMBER
476
WASHER EXHAUST MUFFLER TO STRAP
476
WASHER , Replaced By: N000125008443
482
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
482
NUT STRAP TO BRACKET
482
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
482
NUT , Replaced By: N910113010000
482
NUT , Replaced By: N913004008001
488
STRAP CLUTCH BOOSTER AIR RESERVOIR 520 MM
488
STRAP AIR RESERVOIR TO BRACKET
488
STRAP AIR RESERVOIR TO BRACKET
488
STRAP CLUTCH BOOSTER AIR RESERVOIR 520 MM
496
NUT STRAP TO BRACKET
496
NUT , Replaced By: N910113010000
504
RESERVOIR5.6L,114,3 MM,10 BAR
512
FITTING AIR RESERVOIR,CONNECTION: "15",5 433281
520
SCREW. UNION SCREW LINE CONNECTION
528
SCREW PLUG , Replaced By: N000908022011
528
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
528
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
536
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
536
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
584
BRACKET APPARATUS SUPPORT TO FRAME
592
SCREW BRACKET TO SPRING BRACKET AND TO CROSS MEMBER,5 953233K 027550
592
SCREW MOUNTING TO CONSOLE
600
NUT , Replaced By: N910113014001
600
NUT BRACKET TO SIDE MEMBER
608
BRACKET BRAKE LINE COUPLINGS
616
BRACKET LEFT, SIMPLE PART-PLEASE HAVE SHOP MADE
616
BRACKET RIGHT, SIMPLE PART-PLEASE HAVE SHOP MADE
624
SCREW END PIECE TO EXHAUST PIPE M 10X25
632
NUT , Replaced By: N910113010000
632
NUT STRAP TO BRACKET
999
T-FITTING
999
GROMMET FOR PASSAGE OF LINE
999
BRACKET COMPRESSED AIR LINES, SIMPLE PART-PLEASE HAVE SHOP MADE
999
STRAP AIR RESERVOIR
999
BASE AIR RESERVOIR STRAP
999
BRACKET AIR RESERVOIR,5 765578
