Поз.
Артикул
Описание
5
CROSS MEMBER FRONT
8
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
8
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
8
SCREW , Replaced By: N308676012026
8
SCREW , Replaced By: N308676014020
11
WASHER
14
NUT , Replaced By: N910113014001
14
NUT BRACKET TO SIDE MEMBER
17
COUPLING PIN FOR COUPLING MOUTH
20
SEALING CORD FOR COUPLING MOUTH
23
LOCKING SPRING TO SECURE COUPLING PIN
26
SCREW , Replaced By: N304017008034
26
SCREW BRACKET TO CROSS CONNECTION STRUT
29
WASHER , Replaced By: N000125008443
29
WASHER EXHAUST MUFFLER TO STRAP
32
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
32
NUT , Replaced By: N913004008001
32
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
35
FRONT SPRING BRACKET FRONT,K 062675
35
FRONT SPRING BRACKET FRONT
41
SCREW CONSOLE AND STRUT TO FRAME
41
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER M 16X55
44
NUT CONSOLE TO SUPPORT
44
NUT , Replaced By: N910113016001
47
FRONT SPRING BRACKET REAR
48
FRONT SPRING BRACKET. REAR SUBFRAME REAR,K 083163
49
RUBBER MOUNTING
50
SCREW APPARATUS SUPPORT TO FRAME
50
SCREW SUPPORT TO SIDE MEMBER M 14X45
50
SCREW , Replaced By: A9429901304
50
SCREW , Replaced By: N308676014012
53
NUT , Replaced By: N910113014000
53
NUT STEERING SUPPORT TO FRAME
56
CROSS MEMBER FRONT SPRING REAR BRACKET NO.2
59
SCREW BEARING BRACKET TO SIDE MEMBER M 14X1.5X28
62
SHIM CROSS MEMBER TO SUPPORT
999
RUBBER MOUNTING , Replaced By: A0003223285
999
RUBBER MOUNTING , Replaced By: A0003223285
