Поз.
Артикул
Описание
113
BOOT FROM AIR CLEANER TO INTAKE PIPE
119
STRAINER BOOT
122
CLAMP BOOT TO AIR DUCT AND TO AIR CLEANER
128
SCREW , Replaced By: N304017008027
128
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
134
WASHER , Replaced By: N000125008443
134
WASHER EXHAUST MUFFLER TO STRAP
137
NUT , Replaced By: N913004008001
137
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
137
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
146
BRACKET BOOT
146
BRACKET BOOT
149
SCREW BOOT TO BRACKET
152
BRACKET BOOT
155
SCREW , Replaced By: N304017008016
155
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
158
NUT , Replaced By: N913004008001
158
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
158
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
164
SUPPORT BOOT
170
SCREW BRACKET TO SUPPORT
173
SCREW , Replaced By: N304017010002
173
SCREW BRACKET TO SIDE MEMBER
173
SCREW EXHAUST PIPE TO BRACKET
176
WASHER RADIATOR TO RUBBER MOUNTING
176
WASHER , Replaced By: N007349010007
176
WASHER STRUT TO CROSS MEMBER
182
NUT STRAP TO BRACKET
999
SCREW , Replaced By: N308676014020
