Поз.
Артикул
Описание
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 3
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 3,4 743493
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 3,4 7434944 877629
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 3,4 7434944 877629
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 4
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 4
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 4
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 4
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 4
3
FRONT SPRING (PARABOLIC SPRING),NUMBER OF LEAVES: 4
6
BUSHING FRONT
6
BUSHING FRONT
9
SCREW (SPRING BOLT)
9
SCREW (SPRING BOLT)
9
SCREW (SPRING BOLT)
9
SCREW (SPRING BOLT)
9
SCREW (SPRING BOLT)
9
SCREW (SPRING BOLT)
12
NUT , Replaced By: N910113014000
12
NUT STEERING SUPPORT TO FRAME
14
SPRING CLAMP , Replaced By: A6203240633, +001N000963012011
14
SPRING CLAMP FRONT SPRING
14
SPRING CLAMP FRONT SPRING
14
SPRING CLAMP ,4 7434945 193394, Replaced By: A6203240433, +001N000963012011
14
SPRING CLAMP SPRING EYE,FRONT AND REAR,5 1933955 533057
14
SPRING CLAMP ,4 7434945 193394, Replaced By: A6203240433, +001N000963012011
14
SPRING CLAMP FRONT SPRING,5 193395
14
SPRING CLAMP FRONT SPRING,5 193395
16
SHIM SPRING LEAF
16
SHIM SPRING LEAF
16
SHIM SPRING LEAF
18
SCREW PLATFORM MOUNTING
19
SCREW FOR SPRING CLAMPS
19
SCREW FOR SPRING CLAMPS
20
NUT SUPPORT TO SIDE MEMBER
21
SPACER TUBE , Replaced By: A0003212753
21
SPACER TUBE SPRING CLAMP
22
RIVET SPRING CLAMP TO SPRING LEAF
22
RIVET SPRING CLAMP TO SPRING LEAF,5 940410
22
RIVET SPRING CLAMP TO SPRING LEAF,5 940410
22
RIVET SPRING CLAMP TO SPRING LEAF
25
SHOCK ABSORBER , Replaced By: A0063230900
25
SHOCK ABSORBER , Replaced By: A0043239200
25
SHOCK ABSORBER , Replaced By: A0063230900
25
SHOCK ABSORBER FRONT AXLE
25
SHOCK ABSORBER FRONT AXLE
25
SHOCK ABSORBER , Replaced By: A0063230800
25
SHOCK ABSORBER FRONT AXLE
25
SHOCK ABSORBER , Replaced By: A0063230800
25
SHOCK ABSORBER FRONT AXLE
25
SHOCK ABSORBER , ONLY REPLACEABLE BY PAIRS, Replaced By: A0063230900
25
SHOCK ABSORBER , ONLY REPLACEABLE BY PAIRS, Replaced By: A0063230900
29
RUBBER BUFFER , Replaced By: A0003232885
29
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
29
RUBBER BUFFER , Replaced By: A0003233144
29
RUBBER BUFFER SHOCK ABSORBER,BOTTOM TO 003 326 45 00, Replaced By: A0003238085
29
RUBBER MOUNTINGTO 003 326 46 00
29
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
29
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
29
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
29
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
29
RUBBER MOUNTINGTO 002 323 86 00,003 323 03 00,
29
RUBBER BUFFER SHOCK ABSORBER,BOTTOM TO 003 326 45 00, Replaced By: A0003238085
29
RUBBER BUFFER SHOCK ABSORBER,BOTTOM TO 003 326 45 00, Replaced By: A0003238085
29
RUBBER MOUNTINGTO 003 326 46 00
29
RUBBER MOUNTINGTO 003 326 46 00
29
RUBBER MOUNTINGTO 003 326 46 00
33
BUSHING , Replaced By: A0003233150
33
SPACER RINGTO 002 323 86 00,003 323 03 00,
33
BUSHINGTO 004 323 52 00
33
SPACER RINGTO 002 323 86 00,003 323 03 00,
33
SPACER RINGTO 002 323 86 00,003 323 03 00,
33
SPACER RINGTO 002 323 86 00,003 323 03 00,
33
SPACER RINGTO 002 323 86 00,003 323 03 00,
33
SPACER RINGTO 002 323 86 00,003 323 03 00,
33
BUSHINGTO 004 323 52 00
33
BUSHINGTO 004 323 52 00
33
BUSHINGTO 004 323 52 00
34
HELPER SPRING SPRING STOP TO FRAME BOTTOM SIDE
35
BRACKET HELPER SPRING
36
SCREW REAR EXHAUST PIPE TO MUFFLER
36
SCREW END PIECE TO EXHAUST PIPE M 10X25
37
NUT , Replaced By: N910113010000
37
NUT STRAP TO BRACKET
38
SHIM LEFT SHOCK ABSORBER,5 063601
38
SHIM LEFT SHOCK ABSORBER,5 063601
38
SHIM LEFT SHOCK ABSORBER,5 025188
38
SHIM FRONT SPRINGS TO FRONT AXLE
38
SHIM
38
SHIM RIGHT SHOCK ABSORBER,5 063601
38
SHIM RIGHT SHOCK ABSORBER,5 063601
38
SHIM RIGHT SHOCK ABSORBER,5 025188
38
SHIM FRONT SPRINGS TO FRONT AXLE,5 593332
38
SHIM FRONT SPRINGS TO FRONT AXLE,5 507219
38
SHIM
38
SHIM
38
SHIM LEFT SHOCK ABSORBER,5 507220
38
SHIM FRONT SPRINGS TO FRONT AXLE
38
SHIM FRONT SPRINGS TO FRONT AXLE
38
SHIM LEFT SHOCK ABSORBER,5 1847325 321962
38
SHIM LEFT SHOCK ABSORBER,5 1847325 321962
38
SHIM FRONT SPRINGS TO FRONT AXLE
38
SHIM FRONT SPRINGS TO FRONT AXLE,5 507219
38
SHIM FRONT SPRINGS TO FRONT AXLE,5 507219
38
SHIM FRONT SPRINGS TO FRONT AXLE,5 593332
38
SHIM RIGHT SHOCK ABSORBER,5 507220
38
SHIM FRONT SPRINGS TO FRONT AXLE,5 593332
38
SHIM FRONT SPRINGS TO FRONT AXLE,5 507219
38
SHIM FRONT SPRINGS TO FRONT AXLE,5 507219
38
SHIM LEFT AND RIGHT,5 447734
38
SHIM LEFT AND RIGHT,5 447734
38
SHIM LEFT AND RIGHT,5 447733
38
SHIM FRONT SPRINGS TO FRONT AXLE
40
SHIM FRONT SPRINGS TO FRONT AXLE
40
SHIM FRONT SPRINGS TO FRONT AXLE
40
SHIM FRONT SPRINGS TO FRONT AXLE
46
PLATE FRONT SPRINGS TO FRONT AXLE,K 156938
46
PLATE FRONT SPRINGS TO FRONT AXLE
46
PLATE , Replaced By: A6553310026
46
PLATE , Replaced By: A6553310026
46
PLATE FRONT SPRINGS TO FRONT AXLE
46
PLATE FRONT SPRINGS TO FRONT AXLE
46
PLATE FRONT SPRINGS TO FRONT AXLE
46
PLATE FRONT SPRINGS TO FRONT AXLE
46
PLATE FRONT SPRINGS TO FRONT AXLE
46
PLATE , Replaced By: A6203310026
46
PLATE FRONT SPRINGS TO FRONT AXLE
46
PLATE FRONT SPRINGS TO FRONT AXLE
46
PLATE FRONT SPRINGS TO FRONT AXLE
46
PLATE , Replaced By: A6483310026
46
PLATE FRONT SPRINGS TO FRONT AXLE
46
SPACER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 389516, Replaced By: A6483310026
49
SHIM FRONT SPRINGS TO FRONT AXLE
49
SHIM BETWEEN SPRING AND SHIM,RIGHT, NOT APPLICABLE TO 620.086,096,466, 621.086,096,097,466, 623.068,073,473
51
RUBBER BUFFER SPRING STOP
51
RUBBER BUFFER SPRING STOP
51
RUBBER BUFFER SPRING STOP
51
RUBBER BUFFER SPRING STOP
51
RUBBER BUFFER SPRING STOP
51
RUBBER BUFFER SPRING STOP
51
RUBBER BUFFER , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 389516, Replaced By: A6553310044
59
BRACKET FRONT AXLE I SHOCK ABSORBER,RIGHT BOTTOM, TO BE ADAPTED DURING ASSEMBLY
59
BRACKET RIGHT SHOCK ABSORBER
59
BRACKET RIGHT SHOCK ABSORBER
59
BRACKET LEFT SHOCK ABSORBER,4 877630
59
BRACKET FRONT AXLE I SHOCK ABSORBER,LEFT BOTTOM, TO BE ADAPTED DURING ASSEMBLY
59
BRACKET LEFT SHOCK ABSORBER,4 877630
64
BEARING TORSION BAR,LEFT,4 8776305 184731
64
BEARING TORSION BAR,LEFT,4 8776305 184731
64
BEARING TORSION BAR,SHOCK ABSORBER,LEFT,5 0251895 184731
64
BEARING TORSION BAR,LEFT,5 0636025 184731
64
BEARING TORSION BAR,LEFT,5 0636025 184731
64
BEARING TORSION BAR,LEFT,5 0636025 184731
64
BEARING TORSION BAR,LEFT,5 0636025 184731
64
BEARING TORSION BAR,SHOCK ABSORBER,LEFT,5 0251895 184731
64
BEARING TORSION BAR,RIGHT,4 8776305 184731
64
BEARING TORSION BAR,RIGHT,4 8776305 184731
64
BEARING TORSION BAR,SHOCK ABSORBER,RIGHT,5 0251895 184731
64
BEARING TORSION BAR,RIGHT,5 063602
64
BEARING TORSION BAR,RIGHT,5 0636025 184731
64
BEARING TORSION BAR,RIGHT,5 0636025 184731
64
BEARING TORSION BAR,RIGHT,5 0636025 184731
64
BEARING TORSION BAR,SHOCK ABSORBER,RIGHT,5 0251895 184731
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 245 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 245 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 245 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 245 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
69
U-BOLT , Replaced By: A3363310025
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 290 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 245 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 275 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 410 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 335/225 MM,5 0636025 184731
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 335/225 MM,5 0636025 184731
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 430 MM
69
U-BOLT , Replaced By: A3873310825
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 335/270 MM,5 0636025 184731
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 335/270 MM,5 0636025 184731
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 350/240 MM,5 184731
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 350/285 MM,5 184731
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 212 MM,5 0251885 184732
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 410 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
69
U-BOLT FRONT SPRINGS TO FRONT AXLE 230 MM
