Поз.
Артикул
Описание
6
CROSS MEMBERNO.4A
6
CROSS MEMBERNO.4A
6
CROSS MEMBERNO.4A
6
CROSS MEMBERNO.4A
6
CROSS MEMBERNO.4A
9
CROSS MEMBERNO.5A
9
CROSS MEMBERNO.5A
15
STRUT LEFT AND RIGHT
15
STRUT LEFT AND RIGHT
15
STRUT LEFT AND RIGHT
15
STRUT LEFT AND RIGHT
15
STRUT LEFT AND RIGHT
15
STRUT LEFT AND RIGHT
15
STRUT LEFT AND RIGHT
24
STIFFENING CROSS MEMBER TO FRAME
27
STIFFENING CROSS MEMBER TO SIDE MEMBERS
30
RIVET FRAME TRUSS TO SIDE MEMBER
33
SCREW , Replaced By: N308676012012
33
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
33
SCREW BRACKET TO FRAME
33
SCREW REINFORCEMENTS TO CROSS MEMBER AND SIDE MEMBERS M 12X50
36
SCREW FRONT SPRING REAR BRACKET TO CROSS MEMBER
36
SCREW , Replaced By: N308676014020
36
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
36
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
39
SCREW , Replaced By: N308676016004
39
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
39
SCREW , Replaced By: N308676016014
39
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
39
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER
39
SCREWM 16X16X32X50
39
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER
42
SCREW TRAILER COUPLING TO REAR CROSS MEMBER
42
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER M 16X55
42
SCREW CONSOLE AND STRUT TO FRAME
42
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER M 16X44,5 219681
45
NUT , Replaced By: N910113012003
45
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
45
NUT END PIECE TO EXHAUST PIPE
48
NUT , Replaced By: N910113014000
48
NUT STEERING SUPPORT TO FRAME
48
NUT , Replaced By: N910113014001
48
NUT BRACKET TO SIDE MEMBER
51
NUT , Replaced By: N910113016001
51
NUT CONSOLE TO SUPPORT
54
CROSS MEMBERNO.6
54
CROSS MEMBERNO.6
57
SCREW , Replaced By: N308676012026
57
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
60
NUT SUPPORT TO SIDE MEMBER
63
CROSS MEMBER (REAR CROSS MEMBER), TO BE ADAPTED DURING ASSEMBLY
66
CROSS MEMBER (REAR CROSS MEMBER)
69
CROSS MEMBER (REAR CROSS MEMBER)
69
CROSS MEMBER (REAR CROSS MEMBER)
75
GUSSET PLATE REAR CROSS MEMBER TO LEFT SIDE MEMBER
75
GUSSET PLATE REAR CROSS MEMBER TO RIGHT SIDE MEMBER
75
GUSSET PLATE LEFT BOTTOM, AND RIGHT TOP
75
GUSSET PLATE LEFT TOP AND RIGHT BOTTOM
78
CROSS MEMBER
78
CROSS MEMBER (REAR CROSS MEMBER)
81
STRUT REAR CROSS MEMBER
81
STRUT REAR CROSS MEMBER
84
ANGLE REINFORCEMENT TO REAR CROSS MEMBER
87
SCREW GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS M 14X1.5X150
87
SCREW BRACKET TO CAB CONSOLE,K 035197
87
SCREW , Replaced By: N308676014008
87
SCREW MOUNTING TO CONSOLE M 14X35
87
SCREW GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS M 16X1.5X150
87
SCREW STRUT TO CROSS MEMBER
87
SCREW REINFORCEMENTS TO CROSS MEMBER AND SIDE MEMBERS M 12X50
90
WASHER
93
NUT , Replaced By: N910113014001
93
NUT BRACKET TO SIDE MEMBER
93
NUT , Replaced By: N910113014000
93
NUT STEERING SUPPORT TO FRAME
93
NUT END PIECE TO EXHAUST PIPE
