Поз.
Артикул
Описание
108
EXHAUST MUFFLER
110
PROTECTIVE PLATE (HEAT SHIELD),EXHAUST MUFFLER
113
SCREW BRACKET TO SIDE MEMBER
116
WASHER RADIATOR TO RUBBER MOUNTING
116
WASHER , Replaced By: N000125010532
119
NUT , Replaced By: N910113010000
119
NUT STRAP TO BRACKET
130
SUPPORT EXHAUST MUFFLER TO BRACKET
136
SCREW REAR EXHAUST PIPE TO MUFFLER
136
SCREW BRACKET TO SIDE MEMBER
136
SCREW , Replaced By: N304017010002
138
WASHER STRUT TO CROSS MEMBER
138
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
138
WASHER , Replaced By: N007349010007
140
NUT STRAP TO BRACKET
140
NUT , Replaced By: N910113010000
173
REAR EXHAUST PIPE FRONT PART,5 337343
175
REAR EXHAUST PIPE REAR PART,5 337343
177
REAR EXHAUST PIPE REAR PART,5 337343
179
CLAMP BRACKET TO EXHAUST PIPE
181
SCREW , Replaced By: N304014008021
181
HEXAGON HEAD BOLT. SCREW EXHAUST PIPE TO MUFFLER
183
WASHER EXHAUST MUFFLER TO STRAP
183
WASHER , Replaced By: N000125008443
185
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
185
NUT , Replaced By: N913004008001
185
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
187
CLAMP INTERMEDIATE PIPE TO PARTICLE FILTER
189
SCREW END PIECE TO EXHAUST PIPE M 10X25
191
NUT STRAP TO BRACKET
191
NUT , Replaced By: N910113010000
230
BRACKET EXHAUST PIPE TO SIDE MEMBER
230
BRACKET EXHAUST PIPE TO SIDE MEMBER
263
RUBBER BUFFER BRACKET TO SUPPORT
266
BRACKET FUEL LINES TO TRANSMISSION
269
NUT , Replaced By: N910113010000
269
NUT STRAP TO BRACKET
272
CLAMP PROTECTIVE PLATE TO EXHAUST PIPE
275
SCREW REAR EXHAUST PIPE TO MUFFLER
278
NUT STRAP TO BRACKET
278
NUT , Replaced By: N910113010000
284
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
284
SCREW , Replaced By: A0099900101
284
SCREW , Replaced By: N000933008337
287
WASHER , Replaced By: N009021008213
287
WASHER BRACKET TO CAB REAR PANEL
287
WASHER BRACKET TO LEFT SIDE MEMBER
290
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
290
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
290
NUT , Replaced By: N913004008001
999
WASHER HEAT SHIELD TO BRACKET
999
BRACKET HEAT SHIELD
999
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 227991, Replaced By: A6764902640
999
PROTECTIVE PLATE , NOT USED
999
SCREW COVERING TO SUPPORT
999
SCREW PROTECTIVE PLATE TO CLAMP
