Поз.
Артикул
Описание
7
AIR CLEANERMANN & HUMMEL
11
FILTER ELEMENT AIR CLEANER
13
FILTER ELEMENT
23
NUT
23
NUT
23
NUT
27
GASKET AIR CLEANER BOWL MANN & HUMMEL
47
SCREW CONSOLE TO FRAME
47
SCREW , Replaced By: N308676016020
56
WASHER , Replaced By: N000125017016
56
WASHER BRACKET TO FRAME
62
NUT COMBINATION CYLINDER TO BEARING BRACKET
62
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
68
MUFFLER (INTAKE MUFFLER)
71
RUBBER MOUNTING BRACKET TO BEARING BRACKET
74
BRACKET INTAKE MUFFLER
77
SCREW CLAMP TO BRACKET AND TO PIPE
80
WASHER EXHAUST MUFFLER TO STRAP
80
WASHER , Replaced By: N000125008443
83
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
83
NUT , Replaced By: N913004008001
83
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
86
RUBBER MOUNTING INTAKE MUFFLER TO BRACKET
89
SPACER TUBE PUMP TO FRAME SIDE MEMBER 12X21 MM
92
HEXALOBULAR BOLT. SCREW MANUAL PUMP BRACKET TO FENDER BRACKET
92
SCREW , Replaced By: N304017008040
92
SCREW BRACKET TO SIDE MEMBER
92
SCREW. HEXAGON HEAD BOLT , Replaced By: N910143008005
95
WASHER , Replaced By: N000125008443
95
WASHER EXHAUST MUFFLER TO STRAP
98
RETAINER INTAKE MUFFLER TO BRACKET
101
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
101
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
101
NUT , Replaced By: N913004008001
104
SCREW EXHAUST PIPE TO BRACKET
107
NUT STRAP TO BRACKET
107
NUT , Replaced By: N910113010000
122
AIR INTAKE PIPE
125
BUFFER REFRIGERANT LINE TO CAB
128
WASHER BRACKET TO CAB REAR PANEL
128
WASHER , Replaced By: N009021008213
128
WASHER BRACKET TO LEFT SIDE MEMBER
134
PLUG AIR INTAKE PIPE
137
BOOT AIR INTAKE
143
CLAMP BOOT TO AIR CLEANER,K 034532
143
CLAMP BOOT TO INTAKE PIPE
146
SCREW BOOT TO AIR DUCT AND TO AIR CLEANER
149
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
153
HOSE TO OIL BATH AIR CLEANER
158
CLAMP FROM AIR CLEANER TO HOT AIR INTAKE PIPE
209
HOSE FROM MUFFLER TO ENGINE
214
CLAMP HOSE TO RADIATOR,PIPE ELBOW,AND WATER PUMP 82 - 105 X 15.8 MM
214
CLAMP , Replaced By: A0059972990
214
CLAMP , Replaced By: N000000000675
