Поз.
Артикул
Описание
5
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
17
PLASTIC PIPE AERATION, ORDER BY THE METER
20
INSULATING HOSE
20
INSULATING HOSE
35
FITTING RETURN
38
NUT. UNION NUT RETURN
41
HOSE , ORDER BY THE METER
41
HOSE , Replaced By: A3769978182
42
HOSE FEED LINE AND RETURN LINE
43
SLEEVE FEED
44
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
44
CLAMP , Replaced By: N916017011001
45
CLAMP FUEL LEAK LINE,FUEL FILTER
45
CLAMP LINE MOUNTING
47
BANJO UNION CONNECTION OF FUEL LINES
50
HOLLOW SCREW
53
SEAL RING INJECTION PUMP
56
BRACKET COMPRESSED AIR LINE TO SIDE MEMBER
59
SCREW PLUG SOCKET TO FRAME
62
NUT BRACKET TO SIDE MEMBER
65
CLAMP FROM EXPANSION TANK TO HEATING PIPE, NOT USED
65
CLAMP FUEL LINES TO BRACKET
71
HEXAGON HEAD BOLT COVERING TO CAB
83
NUT , Replaced By: N913004006001
86
LOOM TIE LINE MOUNTING
86
LOOM TIE ELECTRIC CABLE MOUNTING
86
LOOM TIE
87
WASHER BRACKET TO LEFT SIDE MEMBER
