Mercedes N304017006016 - Винт M 6 X 16 8.8

S 280 220.163

62 FRONT END, FRONT WALL - 060 FRONT STIFFENING AND RADIATOR SUPPORT

Поз.
Артикул
Описание
10
A2206401560
REAR PANEL
40
A2206460034
COVER SKI-BAG
50
A2206400020
RAIL TOP
60
N910143006000
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
70
A2206400120
RAIL BOTTOM
80
N910143006000
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
90
A2206400019
STIFFENING ON REAR PANEL
100
N913023008003
NUT HORN TO BRACKET M8
100
N000000003175
NUT BRACKET TO BATTERY IMPLEMENT CARRIER M8
110
N910143008020
SCREW SPEED SENSOR TO REAR AXLE
120
A2206470074
BULKHEAD ON REAR WHEELHOUSE
130
N304017006016
SCREW PUMP TO BRACKET
140
A2206100014
CROSS MEMBER REAR, Replaced By: A2206100214
140
A2206100214
CROSS MEMBER REAR
150
A2206400571
PANELLING (REAR BODY PANEL),BOTTOM
200
A0009917632
BLIND RIVET REPAIR SOLUTION 6,4 X 12MM / 1-3,5MM, NO LONGER AVAILABLE RIVET ONLY VALID FOR BR222. REPAIR INFORMATION SEE WIS. ADDITIONAL INFORMATION ON TECHNICAL MARKET SUPPORT
