Поз.
Артикул
Описание
10
VALVE P.T.O.
21
REPAIR KITTO 001 997 34 36,002 997 58 36,
21
REPAIR KIT , Replaced By: A0012608357
32
TS DOUBLE FITTING SOLENOID VALVE
32
FITTING , Replaced By: A0029906071
43
SEAL RING LINE CONNECTION
54
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
54
SCREW PLUG , Replaced By: N000908012009
65
HOLLOW SCREW HEATING CONNECTION
76
VALVE (SOLENOID VALVE) WABCO
76
VALVE (SOLENOID VALVE) HERION
76
VALVE , Replaced By: A0029975836
76
VALVE , Replaced By: A0039971836
76
VALVE , Replaced By: A0039971736
87
VALVE (SOLENOID VALVE) HERION
98
BRACKET 3/2-WAY SOLENOID VALVE
109
SCREW , Replaced By: N304017006012
109
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
120
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
131
NUT PUMP TO BRACKET
131
NUT , Replaced By: N913004006001
142
SCREW , Replaced By: N304017008043
142
SCREW VALVE TO BRACKET M 8X55
153
SCREW DISTRIBUTOR TO CAB
164
PLASTIC PIPE RISING PIPE 4X6 MM
164
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
175
UNION NUT
186
SEAL CONE
186
GLAND , Replaced By: A0019901667
197
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
197
BANJO UNION , Replaced By: N915052004006
208
SLEEVE LEAK LINE
219
SEAL RING LINE CONNECTION
241
HOLLOW SCREW HEATING CONNECTION
252
REINFORCEMENT DISTRIBUTOR TO CAB
263
SCREW DISTRIBUTOR TO CAB
274
LOOM TIE LINE MOUNTING 280 MM
274
LOOM TIE LINE MOUNTING
999
VALVE , Replaced By: A0002607957
999
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
999
VALVE DISC , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
MAGNET , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
REPAIR KITHERION,94171034/0711/24V,94172034/0711
999
BUSHING , Replaced By: N915062004000
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
PROTECTIVE CAPWABCO
999
REPAIR KIT , Replaced By: A0024302260
999
REPAIR KITTO 001 997 18 36,001 997 19 36
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
SPRING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A0005862626
999
BRACKET , Replaced By: A3834340040
999
HOLLOW SCREW LINE CONNECTION
