Поз.
Артикул
Описание
96
BRACKET FUEL LINES TO TRANSMISSION
96
BRACKET COMPRESSED AIR LINES, Replaced By: A6205240340
98
SCREW , Replaced By: N304017008034
98
SCREW BRACKET TO CROSS CONNECTION STRUT
101
WASHER EXHAUST MUFFLER TO STRAP
101
WASHER , Replaced By: N000125008443
104
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
104
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
104
NUT , Replaced By: N913004008001
721
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 2600 MM
722
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
724
VALVE PRESSURE REGULATOR,4 478330
724
VALVE PRESSURE REGULATOR,4 478330
725
SCREW PLUG CONNECTION "1","2",4 478330
729
BRACKET (REGULATING VALVE),4 478330
730
SCREW REAR AXLE REGULATING SOLENOID VALVE
733
NUT , Replaced By: N913004008001
733
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
733
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
734
SCREW , Replaced By: N304017008034
734
SCREW BRACKET TO CROSS CONNECTION STRUT
738
LINE FROM BRAKE POWER REGULATOR TO REAR BRAKE HOSE 500 MM
739
LINE FROM CONNECTOR TO TEST CONNECTION 2800 MM,4 478330
741
GROMMET LINE MOUNTING 19/13 MM
743
BRACKET LEFT FRONT BRAKE HOSE TO FRONT AXLE
745
SCREW PIPE CLAMP
745
SCREW , Replaced By: N304017008021
747
NUT , Replaced By: N913004008001
747
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
747
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
758
BRAKE HOSE , Replaced By: A0004288935
758
BRAKE HOSE650 MM
758
BRAKE HOSE650 MM
761
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
761
BRACKET. LOCK , Replaced By: A6525040038
764
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
768
CONNECTOR OIL DELIVERY LINE
785
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
788
SCREW PLATE TO BRACKET, Replaced By: N000000001481
788
SCREW PLATE TO BRACKET
788
SCREW PLATE TO BRACKET, Replaced By: N007985006590
791
NUT , Replaced By: N913004006001
791
NUT PUMP TO BRACKET
793
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
802
LINE FROM TEST CONNECTION TO BRAKE POWER REGULATOR,CONNECTION "1",4 478495
804
BRACKET BRAKE POWER REGULATOR
806
SCREW FOR SPRING CLAMPS,5 193394
808
NUT SUPPORT TO SIDE MEMBER
810
BRAKE PRESSURE REGULATOR , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
812
SEAL RING VALVE TO VALVE,K 025179
813
SPRINGTO 000 431 46 12,001 431 12 12
814
VALVE PART
815
SPRING
816
SPRING
817
VALVE CLUTCH SLAVE CYLINDER
817
VALVE , Replaced By: A0004310265
817
VALVE , Replaced By: A3075530107
818
SEAL RING
819
GUIDE BUSHING
820
SPRINGTO 000 431 46 12,001 431 12 12
821
CUP
822
SNAP RINGTO 000 431 46 12,001 431 12 12
823
WOODRUFF KEY
824
SEAL RING , Replaced By: A0129975448
824
SEAL RING
825
NEEDLE BEARINGTO 000 431 46 12,001 431 12 12
826
LOCK RINGTO 000 431 46 12,001 431 12 12
827
AIR CLEANER
828
SPRING WASHER ALTERNATOR CONNECTION D+
829
SPRINGTO 000 431 46 12,001 431 12 12
830
PROTECTIVE CAP
831
PROTECTIVE CAP
833
HOLLOW SCREW HEATING CONNECTION
834
FITTING LINE CONNECTION
834
FITTING LINE CONNECTION, Replaced By: N000000006446
837
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
837
DISTRIBUTOR REAR AXLE,4 478330
838
SCREW , Replaced By: N304017008028
838
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
839
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
839
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
839
NUT , Replaced By: N913004008001
840
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
846
LINE FROM BRAKE POWER REGULATOR TO BRAKE PRESSURE RELIEF 1200 MM
849
BRACKET , THE OLD PART MUST NO LONGER BE INSJTALLED, Replaced By: A3834280140
849
BRACKET BRACKET TO RIGHT SIDE MEMBER
851
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
851
SCREW , Replaced By: N304017008027
853
NUT , Replaced By: N913004008001
853
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
853
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
855
BRAKE HOSE
855
BRAKE HOSE , Replaced By: A0024280535
855
BRAKE HOSE
856
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
856
BRACKET. LOCK , Replaced By: A6525040038
858
TEST CONNECTION FRONT AXLE
860
BRACKET TEST CONNECTION
862
SCREW BRACKET TO CROSS CONNECTION STRUT
862
SCREW , Replaced By: N304017008034
863
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
863
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
863
NUT , Replaced By: N913004008001
865
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
865
SCREW , Replaced By: N304017008027
866
NUT , Replaced By: N913004008001
866
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
866
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
GLAND LINE CONNECTION
999
FITTING AT LEFT SIDE MEMBER,4 347260
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING PNEUMATIC VALVE
999
SEAL RING LEFT SPRING-LOAD ACCUMULATOR
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RING SOLENOID VALVE A 18X24
999
SEAL RING LINE CONNECTION
999
SCREW CLAMP TO BRACKET, Replaced By: N007985006581
999
SCREW CLAMP TO BRACKET
999
SNAP RING GEAR INDICATOR TO INSTRUMENT PANEL
999
SNAP RINGTO 000 431 94 14,000 431 96 14
999
INSULATING HOSE BLACK 10 MM, ORDER BY THE METER
999
INSULATING HOSE PRESSURE REGULATOR,ANTI-FREEZE DEVICE, ORDER BY THE METER
999
HOSE LEAK LINE, ORDER BY THE METER
999
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
999
HOLLOW SCREW RELAY VALVE,CONNECTION "2",LEFT
999
NUT CHECK VALVE TO AIR RESERVOIR
999
FITTING , Replaced By: A0029971172
999
FITTING , Replaced By: A0019972372
999
FITTING , Replaced By: A0009907771
999
FITTING BETWEEN THE LINES
999
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW SUPPORT TO FENDER
999
SCREW BRACKET TO SIDE MEMBER
999
NUT , Replaced By: N304032005005
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
999
NUT COMPRESSED AIR LINE TO LEFT SIDE MEMBER
999
NUT STRAP TO BRACKET
999
NUT BRACKET TO SIDE MEMBER
999
LOCK WASHER BRACKET TO STEERING COLUMN END
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
NUT , Replaced By: N910113006001
999
NUT , Replaced By: N910113010000
999
NUT , Replaced By: N910113014001
999
HOLLOW SCREW , Replaced By: N915036012101
999
UNION NUT LINE CONNECTION
999
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
999
HOLLOW SCREW LINE CONNECTION
999
HOLLOW SCREW LINE TO OIL RADIATOR
999
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
999
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
999
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
999
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
999
FITTING
999
SLEEVE LEAK LINE
999
SLEEVE LINE CONNECTION
999
CLAMP ,K 147121, Replaced By: N000000000319
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
LOCK RING22X1.2,TO 001 431 71 14
999
LOCK RINGTO 000 431 94 14,000 431 96 14
999
LOCK RINGTO 000 431 94 14,000 431 96 14
999
SCREW PLUG , Replaced By: N000908012009
999
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
999
SCREW CROSS MEMBER TO FRAME
999
SCREW CLUTCH TO FLYWHEEL
999
SCREW BRAKE BOOSTER ASSEMBLY TO APPARATUS SUPPORT M 10X40,4 338291
999
SCREW , Replaced By: N304017006020
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: N304017008018
999
SCREW EXHAUST PIPE TO BRACKET
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017010002
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
NUT BALL PIVOT TO LEVER
999
SCREW SPRING CLAMP
999
SCREW CONSOLE TO SIDE MEMBER
999
SCREW EXHAUST PIPE TO BRACKET 14X1.5X50
999
SCREW , Replaced By: N308676014020
999
SCREW PEDAL TO CAB FLOOR
999
SCREW HAND BRAKE VALVE TO CAB
999
SCREW ACCELERATOR PEDAL TO CAB M 6X25
999
SCREW ACCELERATOR PEDAL TO CAB M 6X20
999
GROOVED NAIL3X4,TO 000 431 94 14,000 431 96 14
999
GLAND , Replaced By: A0019901667
999
COTTER PIN , 344.030,032,033,040,041,057,058 UP TO IDENT NO. 415524, FROM IDENT NO. SEE SPARE PARTS LIST 732.7
999
SCREW SHIFT CASE TO SLOTTED GATE
999
SCREW CLAMP TO BRACKET
999
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
999
CLAMP DELIVERY AND SUCTION LINES TO STEERING
999
BRACKET COMPRESSED AIR LINE TO CONTROL ARM,5 927466
999
BRACKET COMPRESSED AIR LINES
