Поз.
Артикул
Описание
160
ANGLE LINE MOUNTING
162
SCREW BRACKET TO CROSS CONNECTION STRUT
162
SCREW , Replaced By: N304017008034
163
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
163
NUT , Replaced By: N913004008001
165
CLAMP ,K 147121, Replaced By: N000000000319
165
CLAMP , Replaced By: N916016008200
166
SCREW SHIFT CASE TO SLOTTED GATE
167
NUT PUMP TO BRACKET
167
NUT , Replaced By: N913004006001
169
LINE FROM VALVE TO BRAKE HOSE 1500 MM
175
GROMMET FUEL LINE THRU FRAME SIDE MEMBER,4 367061
179
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
180
SCREW BRACKET TO CROSS CONNECTION STRUT
180
SCREW , Replaced By: N304017008034
181
SCREW END PIECE TO EXHAUST PIPE M 10X25
182
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
182
NUT , Replaced By: N913004008001
183
NUT STRAP TO BRACKET
183
NUT , Replaced By: N910113010000
184
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
185
LINE FROM TEST CONNECTION TO VALVE 400 MM,4 478330
185
LINE FROM DISTRIBUTOR TO VALVE 3000 MM
186
LINE FROM VALVE TO BRAKE HOSE 1600 MM
188
LINE FROM CONNECTOR TO TEST CONNECTION 3400 MM,4 478330
190
LINE FROM CONNECTOR TO TEST CONNECTION 2800 MM,4 478330
191
GROMMET LINE MOUNTING 19/13 MM
195
BRACKET LEFT FRONT BRAKE HOSE TO FRONT AXLE
196
SCREW , Replaced By: N304017008021
196
SCREW PIPE CLAMP
197
NUT , Replaced By: N913004008001
197
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
200
BRAKE HOSE , Replaced By: A0004288935
200
BRAKE HOSE650 MM
200
BRAKE HOSE650 MM
202
BRACKET. LOCK , Replaced By: A6525040038
202
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
208
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
209
SCREW , Replaced By: N304017008034
209
SCREW BRACKET TO CROSS CONNECTION STRUT
301
LINE FROM TEST CONNECTION TO BRAKE POWER REGULATOR,CONNECTION "1",4 478495
301
LINE
302
TEST CONNECTION FRONT AXLE
306
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
315
LINE FROM BRAKE POWER REGULATOR TO BRAKE PRESSURE RELIEF 1200 MM
318
BRACKET , THE OLD PART MUST NO LONGER BE INSJTALLED, Replaced By: A3834280140
318
BRACKET BRACKET TO RIGHT SIDE MEMBER
319
SCREW , Replaced By: N304017008027
319
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
320
NUT , Replaced By: N913004008001
320
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
321
BRACKET. LOCK , Replaced By: A6525040038
321
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
327
BRAKE HOSE , Replaced By: A0004288935
327
BRAKE HOSE650 MM
327
BRAKE HOSE650 MM
331
TEST CONNECTION FRONT AXLE
332
SCREW , Replaced By: N304017008027
332
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
333
NUT , Replaced By: N913004008001
333
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
336
BRACKET TEST CONNECTION TO REAR AXLE I,4 628861
339
BRACKET SENSOR CABLE TO FRONT AXLE
344
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
346
HOSE BRAKE LINE TO REAR AXLE,4 644238
346
HOSE BRAKE LINE TO REAR AXLE,4 644238
999
REPAIR KITTO 001 429 20 44,BOSCH
999
REPAIR KIT , Replaced By: A0025861443
999
REPAIR KIT , Replaced By: A0034201724
999
FITTING SHUTTLE VALVE,CONNECTION: "20"
999
FITTING LINE CONNECTION, Replaced By: N000000006446
999
SEAL RINGWABCO
999
FITTING , Replaced By: N915059006000
999
LOOM TIE LINE MOUNTING 280 MM
999
LOOM TIE LINE MOUNTING
999
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
999
BRAKE HOSE
999
BRAKE HOSE , Replaced By: A0004288935
999
VALVE (REDUCTION VALVE)
999
VALVE
999
REPAIR KIT VALVE KIT WABCO,5 148812
999
REPAIR KIT , Replaced By: A0025862843
999
REPAIR KIT , Replaced By: A0004302108
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18, UP TO SCHAEFER CHARACTERISTIC NO.489
999
REPAIR KITTO 000 431 56 14,001 431 13 14,WABCO
999
REPAIR KIT REDUCTION VALVE
999
REPAIR KIT
999
REPAIR KITKNORR
999
REPAIR KIT SLAVE CYLINDER TO 006 420 15 18
999
REPAIR KIT , Replaced By: A0004201071
999
REPAIR KIT , Replaced By: A0004301109
999
REPAIR KIT COMPRESSED AIR CYLINDER TO 000 431 68 14
999
REPAIR KITGRAU,5 148812
999
REPAIR KIT , Replaced By: A0034303881
999
REPAIR KIT COMPRESSED AIR CYLINDER TO 001 431 08 14,002 430 10 30
999
REPAIR KITTO 001 431 12 06, KNORR 3200
999
ELBOW FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "1", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
FITTING (PARTS KIT),LINE RUPTURE
999
SPRING
999
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
999
FITTING DELIVERY LINE TO PUMP
999
SEAL RING
999
REPAIR KITTO 001 431 65 14,000 431 24 14
999
REPAIR KIT FOUR-CIRCUIT PROTECTIVE VALVE GRAU,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
REPAIR KITTO 000 430 66 81,000 430 67 81, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
999
GROMMET OIL DELIVERY LINE THRU FENDER SUPPORT
999
SEAL RINGTO 000 439 95 14,4 847617
999
SEAL RINGTO 000 431 95 14,4 847617
999
SEAL RINGTO 000 439 95 14,4 847617
999
SEAL RINGTO 000 431 95 14,4 847617
999
WHEEL BRAKE CYLINDER , WITH 8-MM,OR 10-MM,MOUNTING SCREWS, Replaced By: A0074202018
999
WHEEL BRAKE CYLINDER SLAVE CYLINDER, NOT FOR USE WITH MERCEDES-BENZ CAB
999
SEAL RINGTO 000 431 24 14
999
FITTING , Replaced By: A0029906171
999
SEAL RINGTO 000 431 77 14,KNORR
999
SEAL RING22.3X2.4 MM,GRAU
999
SEAL RINGTO 000 429 28 95,GRAU
999
SEAL RING 25.3X2.4 MM,TO 001 431 68 06, 002 431 02 06
999
SEAL RING FRONT BOTTOM 31X1.5
999
SEAL RINGTO 000 431 95 14,4 847617
999
WHEEL BRAKE CYLINDER , WITH OFFSET BLEEDER CONNECTION WITH 8-MM,OR 10-MM,MOUNTING SCREWS EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 847617, Replaced By: A0044206818
999
NEEDLE BEARINGTO 000 431 46 12,001 431 12 12
999
SEAL RINGTO 000 431 21 14,BOSCH, WITH BOSCH CHARACTERISTIC NUMBER 723
999
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
999
SEAL RINGTO 001 431 68 06,19.3X2.4 MM,GRAU37001, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SEAL RING
999
THREADED UNION PRESSURE REGULATOR,CONNECTION "3",5 148813 ORDER BY THE METER
999
SEAL RINGTO 000 431 46 13,4 478330
999
VALVE CLUTCH SLAVE CYLINDER
999
CLAMP BRAKE LINE MOUNTING
999
PROTECTIVE CAP , Replaced By: A0004210887
999
WASHER BRACKET TO TRANSMISSION
999
GROMMET FUEL LINE THRU FRAME SIDE MEMBER
999
LINE FROM CONNECTOR TO BRAKE HOSE AT REAR AXLE 800 MM,4 478330
999
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 900 MM
999
LINE FROM TEST CONNECTION TO LEFT FRONT WHEEL BRAKE HOSE 1300 MM
999
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
999
LINE FROM TEST CONNECTION TO BRAKE POWER REGULATOR 4000 MM,4 478329
999
LINE FROM DISTRIBUTOR TO VALVE 4200 MM,4 478330
999
BRACKET , Replaced By: A3604292940
999
BRACKET , Replaced By: A3604292940
999
ROD ,4 478504, Replaced By: N900331008427, +001A0004310667, +001A0004310867, +001N000934008010, +001N000934008035
999
ROD , 10/20 FROM CHASSIS 4 399152, 50/60 FROM CHASSIS 4 416113, Replaced By: N900331008427, +001A0004310667, +001N000934008010, +001N000934008035
999
WASHER , Replaced By: A4219905440
999
SPACER TUBE TEST CONNECTION TO BRACKET, 10/20 UP TO IDENT NO. 4 399151,50/60 UP TO IDENT NO. 4 416112
999
CLAMP FEED LINE TO THERMOSTAT
999
SPACER TUBE VALVE TO CROSS MEMBER
999
BRACKET DELIVERY AND SUCTION LINES
999
BRACKET TEST CONNECTION,4 645186
999
BRACKET OPERATING ROD,4 1880904 478329
999
BRACKET , Replaced By: A3834300039
999
SUPPORT , 385.068,069,FOR USE WITH MERCEDES-BENZ CAB4 444415, Replaced By: A3854260240, +001A3854310853, +001N000931010379, +001N913004010008
999
ANGLE , Replaced By: A3604280243
999
BRACKET RIGHT FRONT BRAKE HOSE TO FRONT AXLE
999
BRACKET REDUCTION VALVE,4 433389
999
BRACKET , Replaced By: A3812711640
999
BRACKET BRAKE POWER REGULATOR, FROM CHASSIS 4 358799 AS WELL AS APPLICABLE FROM CHASSIS 4 344455-4 358798 ON VEHICLES WITH TRAILING AXLE FIT TO BE RAISED
999
BRACKET (REGULATING VALVE),4 478330
999
BRACKET METAL SPRING BELLOWS
999
WASHER , Replaced By: A3859900540
999
WASHER PROTECTIVE PLATE TO EXHAUST PIPE
999
CLAMP BRAKE LINE TO REAR AXLE,4 644238
999
GROMMET BATTERY CABLE THRU SIDE MEMBER
999
BRACKET BUMPER,RIGHT, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
BRACKET PRESSURE GAUGE LINE TO BRACKET,4 895864
999
ADHESIVE FOIL GUIDE SIGN
999
WASHER BUMPER BRACKET TO COUPLING MOUTH
999
BRACKET , NOT USED
999
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
COTTER PIN CYLINDER TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
WASHER , Replaced By: N000125010532
999
WASHER RADIATOR TO RUBBER MOUNTING
999
LOCK WASHER , Replaced By: N912004010102
999
NUT , Replaced By: N304035008001
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
999
SCREW REAR AXLE REGULATING SOLENOID VALVE
999
SCREW BRACKET TO BELL HOUSING
999
SCREW , Replaced By: N304017006026
999
SCREW , Replaced By: N304017006020
999
SCREW , Replaced By: N304017008042
999
SCREW , Replaced By: N304017008016
999
SCREW BRACKET TO RIGHT SIDE MEMBER
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
SCREW , Replaced By: N304017008016
999
SCREW EXHAUST PIPE TO BRACKET
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SCREW , Replaced By: N304017010002
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
NUT INTERMEDIATE SPEED STOP
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SCREW BRACKET TO TRANSMISSION CASE
999
SCREW , Replaced By: N308676012012
999
SCREW , Replaced By: N308676012013
999
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X40
