Поз.
Артикул
Описание
4
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
4
HOSE , Replaced By: A0009872827
7
SLEEVE LINE CONNECTION
7
BUSHING , Replaced By: N915062009000
10
SEAL CONE LINE CONNECTION
10
GLAND , Replaced By: A0019901967
13
UNION NUT LINE CONNECTION
13
UNION NUT LINE CONNECTION, Replaced By: N000000006239
16
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
19
SLEEVE LINE CONNECTION
19
SLEEVE , Replaced By: N915062006000
21
BANJO UNION HEATING CONNECTION,K 169122
21
BANJO UNION , Replaced By: N915052006005
23
GLAND LINE CONNECTION
26
UNION NUT LINE CONNECTION
30
PLASTIC PIPE RISING PIPE 4X6 MM
30
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
32
SLEEVE LEAK LINE
32
BUSHING , Replaced By: N915062004000
36
BANJO UNION HOSE WIDTH, / I.D., 4/14 MM,K 169123
36
BANJO UNION , Replaced By: N000000000364
36
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
48
CONSOLE CAB
49
RESERVOIR20L,246 MM,12.5 BAR
49
RESERVOIR , Replaced By: A0034321201
49
RESERVOIR , Replaced By: A0014327501
53
O-RING CHECK VALVE TO AIR RESERVOIR
54
THRUST RING CHECK VALVE TO AIR RESERVOIR
54
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
59
VALVE DRAIN, Replaced By: A0004322107
59
VALVE. DRAIN VALVE DRAIN
59
VALVE. DRAIN VALVE DRAIN
59
VALVE DRAIN, Replaced By: A0004322107
59
VALVE DRAIN, Replaced By: A0004322407
63
CROSS FITTING
73
O-RING CHECK VALVE TO AIR RESERVOIR
74
THRUST RING CHECK VALVE TO AIR RESERVOIR
74
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
76
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
76
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
80
O-RING CHECK VALVE TO AIR RESERVOIR
83
THRUST RING CHECK VALVE TO AIR RESERVOIR
83
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
86
NUT CHECK VALVE TO AIR RESERVOIR
89
VALVE PRESSURE LIMIT,K 025180
89
VALVE ,K 025179, Replaced By: A0044297044
89
VALVE , EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 4 903131, Replaced By: A0034295044
96
SEAL RING VALVE TO VALVE,K 025179
99
ADAPTER FITTING RESERVOIR TO SUPPORT
102
O-RING CHECK VALVE TO AIR RESERVOIR
105
THRUST RING CHECK VALVE TO AIR RESERVOIR
105
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
108
NUT CHECK VALVE TO AIR RESERVOIR
130
O-RING CHECK VALVE TO AIR RESERVOIR
131
THRUST RING CHECK VALVE TO AIR RESERVOIR
131
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
133
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
133
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
133
FITTING , Replaced By: A0029971172
136
BRACKET AIR RESERVOIR TO FRAME
137
SCREW PIPE CLAMP
137
SCREW , Replaced By: N304017008021
138
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
138
NUT , Replaced By: N913004008001
143
STRAP AIR RESERVOIR TO BRACKET
145
NUT REINFORCEMENT TO BRACKET
145
NUT , Replaced By: N910113010003
155
VALVE (OVERFLOW VALVE) GRAU,5 116581
155
VALVE (OVERFLOW VALVE) BOSCH,5 116581
155
VALVE (OVERFLOW VALVE) WESTINGHOUSE,5 116581
156
DIAPHRAGM
157
REPAIR KITTO 001 429 52 44
329
SEAL RING FUEL LINE TO FEED PUMP
332
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
398
FITTING HYDRAULIC LINE TO BRACKET,K 130132
400
ELBOW FITTING ,4 412125
402
T-FITTING
407
FITTING DIAPHRAGM CYLINDER,CONNECTION: "1.1", NOT USED
408
FITTING DIAPHRAGM CYLINDER,CONNECTION: "1.2","1.1", NOT USED
408
FITTING , Replaced By: A0049975872
410
LINE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER
410
LINE , Replaced By: A6254293501
410
LINE , Replaced By: A6194290801
410
LINE , Replaced By: A3834290801
410
LINE , Replaced By: A3874299502
410
LINE , Replaced By: A3874299502
415
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
418
FITTING
422
HOSE FROM FITTING TO RIGHT DIAPHRAGM CYLINDER 8 X 14 MM, ORDER BY THE METER4 940458
426
CLAMPTO 005 420 99 18
430
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
430
CLAMP ,K 147121, Replaced By: N000000000319
430
CLAMP , Replaced By: N916016008200
430
CLAMP , Replaced By: A3604300143
999
BLEEDER VALVE , 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
CUPTO 007 420 68 18,WABCO
999
COVERING
999
FITTING DIAPHRAGM CYLINDER,CONNECTION:
999
DIAPHRAGM
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
DIAPHRAGMTO 001 429 48 44
999
LINE FROM FOUR-CIRCUIT PROTECTIVE VALVE TO AIR RESERVOIR 9X12 MM, LENGTH AVAILABLE 3000 MM
999
SPRINGTO 000 429 16 31,4 940458
999
SPRINGTO 000 429 16 31,4 940458
999
SEAL RINGTO 000 429 16 31,4 940458
999
ADAPTER FITTING , Replaced By: A0004296934
999
ADAPTER FITTING PASSAGE OF LINE THRU SIDE MEMBER,5 395033
999
REPAIR KIT DIAPHRAGM CYLINDER
999
VALVE , TO BE EXHAUSTED UP TO CHASSIS 4 261995, Replaced By: A0004308681
999
BRAKE VALVE SEAL RING TO 001 431 18 05,4 412020
999
VALVE , TO BE EXHAUSTED UP TO CHASSIS 4 230076, Replaced By: A0004308581
999
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034301781
999
GASKET34X2X6 MM,GRAU
999
VALVE SEATTO GRAU
999
TEST CONNECTION AUXILIARY BRAKE AND SUPPLY,5 116582
999
CROSS FITTING AIR RESERVOIR,CONNECTION: 22
999
CROSS FITTING AIR RESERVOIRS I AND II,4 821954 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
T-FITTING
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
T-FITTING 3/2-WAY VALVE, CONNECTIONS "P1,R2",4 307219
999
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
999
F-FITTING INSIDE AIR RESERVOIR,4 2931664 338291
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
GROMMET HAND BRAKE VALVE BLEEDING,4 665938
999
HANDLETO 000 429 16 31,4 940458
999
BRAKE VALVE TRAILER CONTROL VALVE BOSCH,4 375193 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
BRAKE VALVE , Replaced By: A0014313705
999
BRAKE VALVE TRAILER CONTROL VALVE WABCO,4 375193
999
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313505
999
REPAIR KITBOSCH
999
REPAIR KIT , Replaced By: A0024306581
999
REPAIR KITTO 001 431 34 05,4 375193
999
REPAIR KIT , Replaced By: A0004304606
999
T-FITTING EXTENSIBLE BRAKE VALVE, 4 691696
999
T-FITTING RIGHT SPRING LOAD ACCUMULATOR BRAKE CYLINDER,CONNECTION "1"
999
SEAL CONE
999
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
999
ELBOW FITTING DELIVERY LINE TO PUMP
999
T-FITTING SUPPLY LINE FOR TRANSMISSION
999
T-FITTING , Replaced By: A0029909070
999
FITTING , Replaced By: N915059004000
999
LOOM TIE LINE MOUNTING 280 MM
999
VALVE (OVERFLOW VALVE) BOSCH
999
VALVE TRAILER BRAKE
999
VALVE (OVERFLOW VALVE) GRAU
999
REPAIR KIT SPRING LOAD ACCUMULATOR PART WABCO,K 262627
999
REPAIR KIT VALVE KIT TO 001 431 37 05,4 375193
999
REPAIR KITTO 001 431 37 05,4 375193
999
REPAIR KIT , Replaced By: A0024301560
999
T-FITTING HOSE WIDTH, 9 MM,TO M 22
999
FITTING DELIVERY LINE TO PUMP
999
FITTING RELAY VALVE,CONNECTION: "40",5 359430
999
VALVE (OVERFLOW VALVE) KNORR
999
SEAL RING7X1.5,TO GRAU
999
SEAL RING21.3X2.4 TO 001 431 74 05,
999
SEAL RING18X2.5,TO GRAU
999
SEAL RING39.2X3 TO 001 431 74 05,
999
SEAL RING90X3,TO GRAU
999
SEAL RING64.77X2.62,TO GRAU
999
SEAL RING44.2X3,TO GRAU
999
SEAL RING100X3,TO GRAU
999
WHEEL BRAKE CYLINDER TRISTOP CYLINDER WABCO 16/24,K 186393
999
WHEEL BRAKE CYLINDER ,5 592211
999
SEAL RINGTO 000 429 16 31,4 940458
999
SHIM EXTENSIBLE BRAKE VALVE TO CAB,4 3141804 665938
999
GROMMET SENSOR CABLE PROTECTION
999
SHIM EXTENSIBLE BRAKE VALVE TO CAB,4 665938
999
ANGLE , Replaced By: A6214320117
999
ADHESIVE FOIL GUIDE SIGN
999
GUIDE SIGN LOAD-DEPENDING BRAKE,4 369378
999
GUIDE SIGN LOAD-DEPENDING BRAKE
999
ANGLE RIGHT
999
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30"
999
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
999
WASHER , Replaced By: N000125015019
999
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
999
SCREW PLUG , Replaced By: N000908022011
999
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
GLAND , Replaced By: A0019901667
999
FITTING , Replaced By: A0019903170
999
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RING LINE CONNECTION
999
HOSE HAND BRAKE VALVE BLEEDING 100 MM, ORDER BY THE METER
999
FITTING DIAPHRAGM CYLINDER,CONNECTION:
999
FITTING , Replaced By: A0009970171
999
FITTING , Replaced By: A0029979572
999
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
NUT BRACKET TO SIDE MEMBER
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N910113010000
999
UNION NUT
999
HOLLOW SCREW FUEL LINE TO FEED PUMP
999
HOLLOW SCREW , Replaced By: N915036010108
999
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
999
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
999
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
999
SEAL RING , Replaced By: N007603012121
999
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
