Поз.
Артикул
Описание
5
11
BUSHING
11
BUSHING
14
20
41
44
47
65
SPACER REAR SPRING TO REAR AXLE
71
SPRING BOLTM 12X240,B 969045
73
NUT LEAF SPRING
77
SCREW FRONT EXHAUST PIPE TO EXHAUST MANIFOLD, INAPPLICABLE TO SUPERCHARGING SYSTEM
78
NUT BRACKET TO FRAME
80
SPACER TUBE SPRING CLAMP TO SPRING LEAF
84
PLATE TORSION BAR TO REAR AXLE, 752309
86
JOINT BEARING TORSION BAR TO LINK,5 903513
86
JOINT BEARING TORSION BAR TO LINK,5 903513
88
LOCK RING FLANGE TO P.T.O.
90
GREASE NIPPLE
90
GREASE NIPPLE
91
U-BOLT , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE ONLY REPLACEABLE BY PAIRS5 999999K 000001 - K 028584, Replaced By: A6793510725, +001A6793250031
91
U-BOLT REAR SPRING TO REAR AXLE 400 MM
93
WASHER FRONT SPRINGS TO FRONT AXLE
95
NUT STEERING SUPPORT TO FRAME
110
SHACKLE REAR-SPRING REAR BRACKET
113
SHACKLE PIN REAR SPRING TO REAR SPRING FRONT BRACKET
113
SHACKLE PIN REAR SPRING TO SPRING SHACKLE, 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
113
SHACKLE PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3923257130
116
GREASE NIPPLE PROTECTIVE TUBE
119
WASHER AS REQUIRED 4.2 MM
119
WASHER SHACKLE PIN, AS REQUIRED 4.0 MM
119
WASHER FRONT SPRING TO SPRING SHACKLE & SPRING BRACKETS
119
WASHER AS REQUIRED 4.0 MM
122
SEAL RING SPRING SHACKLE TO SPRING REAR BRACKET
125
BOLT SPRING SHACKLE TO SPRING REAR BRACKET
128
WASHER GROUND CABLE
131
NUT , Replaced By: N910113010000
999
SPRING CLAMP HELPER SPRING, NOT USED
999
SPACER
999
SPRING LEAFNO.1,TO 384 320 70 08
999
SPRING LEAFNO.3,TO 384 320 70 08
999
SPRING LEAFNO.5,TO 384 320 70 08
999
SPRING LEAF HELPER SPRING NO.3,TO 384 320 70 08
999
REAR SPRING WITH HELPER SPRING,1B 897069
999
SPRING LEAF HELPER SPRING NO.1,TO 384 320 70 08
999
SPRING LEAF HELPER SPRING NO.2,TO 384 320 70 08, NOT USED
999
SPRING LEAF HELPER SPRING NO.4,TO 384 320 70 08, NOT USED
999
SPRING LEAF HELPER SPRING NO.5,TO 384 320 70 08
999
SPRING LEAF HELPER SPRING NO.6,TO 384 320 70 08
999
SPRING LEAF HELPER SPRING NO.7,TO 384 320 70 08
999
SPRING LEAFNO.2,TO 384 320 70 08
999
SPRING LEAFNO.4,TO O84 320 70 08
999
SPRING LEAFNO.6,TO 384 320 70 08
999
SPRING LEAFNO.7,TO 384 320 70 08
999
SPRING LEAFNO.8,TO 384 320 70 08
999
REAR SPRING WITH HELPER SPRING, NOT USED
999
SPRING LEAFNO.2,TO 392 320 70 08, NOT USED
999
SPRING LEAFNO.4,TO 392 320 70 08, NOT USED
999
SPRING LEAFNO.6,TO 392 320 70 08, NOT USED
999
SPRING LEAFNO.7,TO 392 320 70 08, NOT USED
999
SPRING LEAF , NOT USED
999
SPRING LEAF , NOT USED
999
SPRING LEAF HELPER SPRING NO.1,TO 392 320 70 08, NOT USED
999
SPRING LEAF HELPER SPRING NO.2,TO 392 320 70 08, NOT USED
999
SPRING LEAF HELPER SPRING NO.4,TO 392 320 70 08, NOT USED
999
SPRING LEAF HELPER SPRING NO.5,TO A 392 320 70 08, NOT USED
999
SPRING LEAF HELPER SPRING NO.6,TO A 392 320 70 08, NOT USED
