Поз.
Артикул
Описание
5
TANK OIL
5
TANK , Replaced By: A0004666202
8
OIL DIPSTICK
8
OIL DIPSTICK
8
OIL DIPSTICK , Replaced By: A0004660867
9
PROTECTIVE CAP
11
FILLER CAP , Replaced By: A0004661268
11
FILLER CAP
11
FILLER CAP
14
SEAL RING
17
BRACKET
20
FILTER
20
FILTER , Replaced By: A0004660604
23
SCREW OIL TANK TO BRACKET
26
NUT AT FILTER BRACKET
26
NUT , Replaced By: N913004006001
29
BRACKET OIL TANK
29
BRACKET OIL TANK,5 593345
32
SCREW LINE MOUNTING M 10X20
32
SCREW , Replaced By: N910105010009
32
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
35
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
35
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
38
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
38
CLAMP , Replaced By: N000000000667
41
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
41
LINE FROM OIL TANK TO HOSE
44
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 701910
44
LINE FROM OIL TANK TO POWER STEERING PUMP AT ENGINE
47
UNION NUT LINE CONNECTION, Replaced By: N000000006243
50
GLAND , Replaced By: A0019901267
56
ELBOW FITTING SUCTION LINE TO OIL PUMP
59
NUT SUCTION LINE TO OIL PUMP
62
THRUST RING SUCTION LINE TO OIL PUMP
65
SEALING CORD SUCTION LINE TO OIL PUMP
71
LINE FROM PUMP TO HIGH PRESSURE HOSE
71
LINE FROM PUMP TO HIGH PRESSURE HOSE, CIRCUIT I
74
UNION NUT LINE CONNECTION, Replaced By: N000000006239
77
GLAND , Replaced By: A0019901967
80
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
80
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
80
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
83
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
83
LINE FROM HIGH PRESSURE HOSE TO STEERING
86
UNION NUT LINE CONNECTION, Replaced By: N000000006239
89
GLAND , Replaced By: A0019901967
92
FITTING DELIVERY LINE TO PUMP
93
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
95
SCREW-IN FITTING RETURN LINE TO STEERING
96
SEAL RING VALVE TO VALVE,K 025179
98
LINE RETURN, FROM STEERING TO OIL TANK
98
LINE RETURN, FROM STEERING TO OIL TANK
101
UNION NUT LINE CONNECTION
104
GLAND LINE CONNECTION
107
HOSE DELIVERY LINE TO STEERING
110
CLAMP HOSE TO FITTING AND TO OIL TANK
110
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
113
BRACKET FUEL LINES TO TRANSMISSION
114
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT,024240
122
SCREW END PIECE TO EXHAUST PIPE M 10X25
125
NUT , Replaced By: N910113010000
128
SCREW , Replaced By: N308676012026
128
SCREW BRACKET TO CROSS MEMBER M 12X1.5X40
131
WASHER
134
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
134
NUT STRAP TO SUPPORT
140
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
140
CLAMP DELIVERY AND SUCTION LINES TO STEERING
140
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
146
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
146
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
152
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
152
SCREW , Replaced By: N000000001422
155
NUT , Replaced By: N913004006001
155
NUT AT FILTER BRACKET
