Поз.
Артикул
Описание
10
PUMP
20
HEXAGON NUT. NUT ELECTRIC CABLE TO ALTERNATOR
30
HOSE PUMP TO VALVE WITH T-TYPE DISTRIBUTOR
50
HOSE FEED HOSE TO VALVE
60
CLAMP25 MM
60
HOSE CLAMP HOSE ATTACHMENT 27 MM
60
CLAMP14 MM
80
HOSE FLOW PIPE, WINDOW WASHER HEATING
90
HOSE RECIRCULATION, WINDOW WASHER HEATING
100
CLAMP14 MM
110
WIRING HARNESS TO PUMP
120
BRACKET AT BRACKET
130
PIPELINE TO WASHER FLUID HEATER
140
BRACKET HOSE
160
HOSE FROM VALVE TO HEAT EXCHANGER
170
HOSE FROM VALVE TO HEAT EXCHANGER
220
HOSE PIPE LINE TO VALVE
230
HOSE PIPE LINE TO VALVE
240
STOP PLUG BLIND PLUG
240
GROMMET PIPE LINE TO WHEELHOUSE
260
CAP FOR WASHER FLUID HEATER CONNECTION
270
HOSE TO WASHER FLUID HEATER
290
HOSE INTERMEDIATE PIECE TO T-PIECE
295
HOSE RETURN LINE, REAR CENTER
300
CLAMP. LOOM TIE
310
HOSE RETURN LINE, REAR
320
HOSE RETURN LINE, EXTERIOR REAR
330
CLAMP25 MM
330
HOSE CLAMP HOSE ATTACHMENT 27 MM
335
HOSE REAR RETURN LINE, 3/2 DIRECTIONAL CONTROL VALVE
340
HOSE NEGATIVE CASTER REAR
350
VALVE (WATER VALVE), ELECTROMAGNETIC WITH RECIRCULATION PUMP, BACK
360
BRACKET TIMING VALVE
370
BOLT HOSE TO FRAME-TYPE INTEGRAL SUPPORT M6X12
380
SUPPORT BUFFER AT BRACKET
390
RUBBER BUFFER WATER VALVE TO BRACKET
400
RUBBER BUFFER BETWEEN BRACKET AND DOUBLE WATER VALVE
420
PIPELINE
425
O-RING REAR AIR CONDITIONING PIPE SYSTEM 15.5X2.62
425
O-RING REAR AIR CONDITIONING PIPE SYSTEM 12.5X2.62
430
HEXALOBULAR BOLT BRACKET TO BRACKET M5X20
440
PIPELINE TO REAR AIR CONDITIONING PIPE SYSTEM
450
HEX NUT GUIDE AT REAR FENDER
460
PIPELINE STATIONARY HEATER SUPPLY
470
GROMMET RETURN LINE
480
NUT COVERING TO CAB FIRE WALL
490
PIPELINE RETURN
510
FUNNEL FROM STATIONARY HEATER TO T-PIECE
520
HOSE RETURN FROM HEATER
900
PIN BUSHING HOUSING OUTBOARD TEMPERATURE FEELER 2-PIN CODE A,B4,126373
901
CONTACT BUSHING WITH SINGLE-WIRE SEAL 0.5MM2,126373
903
RECEPTACLE HOUSING RIGHT POWER WINDOW MOTOR 2-PIN SLK2.8,M10/2
904
CONTACT SPRING. PLUG SOCKET0,5-1,0
904
GASKET
905
RECEPTACLE HOUSING RIGHT POWER WINDOW MOTOR 2-PIN SLK2.8,M10/2
906
PIN BUSHING HOUSING LAMP UNIT, FRONT RIGHT (BLACK) 3-PIN,SLK2.8,E2
906
SEAL. GASKET YELLOW,V 215932
908
HOUSING. PLUG PLUG, CONNECTOR, DIFFUSOR HEATER
909
CONTACT PIN WITH SINGLE-WIRE SEAL 0.75-1.0MM2 MLK1.2
910
CONTACT SPRING. PLUG SOCKET0,5-1,0
910
GASKETTO 001 545 24 81, A 218853 ALSO INSTALLED ON A 103237 - A 218851 WITH CODE 030 F 190066 ALSO INSTALLED ON F 159752 - F 190064 WITH CODE 030 EXCEPT FOR A 219847
