Поз.
Артикул
Описание
411
SEAL RING
414
FOLLOWER INJECTION PUMP WITH FOLLOWER FLANGE AND INTERMEDIATE FLANGE TO TIMING CASE
420
INTERMEDIATE GEAR INJECTION PUMP DRIVE TO CYLINDER CRANKCASE
420
INTERMEDIATE GEAR INJECTION PUMP DRIVE TO CYLINDER CRANKCASE
423
PIVOT PIN INJECTION PUMP DRIVE TO CYLINDER CRANKCASE
426
HEXAGON HEAD BOLT BRACKET TO BEARING BRACKET M12X35
429
WASHER INJECTION PUMP DRIVE TO CYLINDER CRANKCASE
432
DRIVE GEAR INJECTION PUMP DRIVE
435
FLANGE INJECTION PUMP DRIVE
438
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
441
WASHER , Replaced By: A4239900040
444
PIVOT PIN INJECTION PUMP DRIVE TO CYLINDER CRANKCASE
447
HEXAGON HEAD BOLT BRACKET TO BEARING BRACKET M12X35
450
WASHER INJECTION PUMP DRIVE TO CYLINDER CRANKCASE
453
INTERMEDIATE PIECE AT INJECTION PUMP
456
INTERMEDIATE PIECE AT INJECTION PUMP
459
SEAL RING INJECTION PUMP LUBRICATION,473001
459
SEAL RING P.T.O. TO TRANSMISSION
462
BRACKET INJECTION PUMP
465
SCREW , Replaced By: N304017006018
465
HEXAGON HEAD BOLT
477
HOSE MAIN LUBRICATING LINE,PUMP,DISTRIBUTOR 10X2 MM, ORDER BY THE METER
480
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
483
HOLLOW SCREW HEATING CONNECTION
486
SEAL RING PRESSURE CONNECTION TO AIR COMPRESSOR
489
LEVER INJECTION PUMP
492
BALL PIVOT
495
SCREW CLAMP MOUNTING M 6X16
495
SCREW , Replaced By: N914146006102
499
HOSE PLASTIC PIPE,K 223529
501
SEAL RING INJECTION PUMP
504
LOOM TIE , UP TO CHASSIS: 108.012 UNTIL PRODUCTION STOP 108.016 042417 108.018,019 043374 109.016 002452
551
HOLLOW SCREW HEATING CONNECTION
554
SEAL RING PRESSURE CONNECTION TO AIR COMPRESSOR
999
PUMP ELEMENT , NOT USED
999
BEARING , Replaced By: A0000741446
999
VALVE , Replaced By: A0000747884
999
GASKET , Replaced By: A0010742680
999
VALVE , Replaced By: A0000747684
999
GASKET
999
STRAINER (FILTER STRAINER PARTS KIT) TO A 025 074 88 02
999
HOUSING PARTS KIT, Replaced By: A0000900807
999
HOUSING , FROM ENGINE 399027 YEAR OF MANUFACTURE 1995
999
VALVE PARTS KIT, FROM ENGINE 399027 YEAR OF MANUFACTURE 1995
999
FUEL PUMP , Replaced By: A0000908850
999
FUEL PUMP (MANUAL FEED PUMP) WITH SEAL RING, FROM ENGINE 399032 YEAR OF MANUFACTURE 1995
999
CLAMPING BRACKET FILTER HOUSING TO PUMP
999
FILTER BOWL , Replaced By: A0000910840
999
VALVE , Replaced By: A0000900810
999
STRAINER , Replaced By: A0000900245
999
SELF-ALIGNING BEARING , Replaced By: A0009810530
999
STUD , Replaced By: A0009909505
999
NUT
999
STUD
999
SPRING , Replaced By: A0000900245
999
SEAL RING
999
GASKET , Replaced By: A0010742280
999
FUEL PUMP
999
FUEL PUMP , Replaced By: A0000902450
999
SEAL RING , Replaced By: A0000742959
999
FUEL PUMP , Replaced By: A0000903150
999
FUEL PUMP , Replaced By: A0000903350
999
FUEL PUMP
999
SEAL RING
999
LOCK , Replaced By: N000471030000
999
INJECTION PUMP , NOT USED
999
INJECTION PUMP
999
INJECTION PUMP , Replaced By: A0100748102
999
INJECTION PUMP
999
INJECTION PUMP
999
INJECTION PUMP , Replaced By: A0100748702
999
INJECTION PUMP
999
INJECTION PUMP , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 496166, Replaced By: A0140743602
999
INJECTION PUMP , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 458609, Replaced By: A0160748902
999
SEAL RING , Replaced By: A0000900245
999
SEAL RING ,473000, Replaced By: A4420740059, +001A4420150060
999
DRIVE GEAR , Replaced By: A4030770712
999
WASHER , Replaced By: A4449905140
999
TIMING CASE , Replaced By: A4470100433
999
CRANKCASE
999
TAPERED ROLLER BEARING , Replaced By: A0019816505
999
HOLLOW SCREW
