Поз.
Артикул
Описание
201
BRACKET INTERMEDIATE AXLE
201
BRACKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 616806, Replaced By: A4420700140
219
LEVER , UP TO ENGINE 616806 EXCEPT FOR 616100, Replaced By: A4420700122, +001A4420700140
219
LEVER (DOUBLE LEVER), FROM ENGINE 616807,ALSO INSTALLED ON 616100
225
BUSHING MOUNTING
231
BALL PIVOT LEVER
231
BALL PIVOT , Replaced By: A3129910120
237
GREASE NIPPLE
243
WASHER
249
LOCK RINGTO 000 553 37 01,000 553 39 01,
255
PULL ROD AT CONTROL LEVER, TO BE ADAPTED DURING ASSEMBLY
261
BALL SOCKET ,266368
267
NUT L.H. THREAD
267
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
267
NUT , Replaced By: N913023006001
273
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
304
BEARING BRACKET
310
BUSHING MOUNTING
319
HEXAGON HEAD BOLT. SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
319
SCREW , Replaced By: N304017008027
322
SPRING WASHER , Replaced By: N000137008212
322
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
331
SHAFT (INTERMEDIATE SHAFT)
337
BALL PIVOT LEVER
337
BALL PIVOT , Replaced By: A3129910120
345
LEVER (LOCKING LEVER)
349
BUSHING MOUNTING
355
BALL PIVOT
361
LEVER ,253411
367
BALL PIVOT , Replaced By: A3129910120
367
BALL PIVOT LEVER
373
HEXALOBULAR BOLT. SCREW LINE MOUNTING M 6X30
373
SCREW , Replaced By: N000000001479
379
NUT , Replaced By: N913023006001
379
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
381
PIN , Replaced By: A4421440574
381
PIN CYLINDER TO BRACKET
383
SPRING WASHER , Replaced By: N000137008212
383
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
385
NUT PIVOT PIN TO BEARING BRACKET
387
WASHER INTERMEDIATE SPEED STOP
387
WASHER EXHAUST MUFFLER TO STRAP
389
NUT , Replaced By: N913004008001
390
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
390
CYLINDER INTERMEDIATE SPEED STOP
390
CYLINDER
390
CYLINDER , Replaced By: A0004304926
391
REPAIR KIT
391
REPAIR KIT SHIFTING CYLINDER TO KNORR, SZ 1130 I/74963,000 430 3026
391
REPAIR KITTO 000 430 48 26,KNORR
392
NUT , Replaced By: N304035008001
392
NUT
395
BALL SOCKET
396
CIRCLIP ,B 884219
401
ROD
406
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
411
NUT , Replaced By: N913023006001
411
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
416
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
421
BEARING BRACKET
426
BUSHING MOUNTING
431
SCREW LEFT AND RIGHT CONSOLES TO CAB
431
SCREW , Replaced By: N308676012015
431
HEXAGON HEAD BOLT. SCREW BRACKET TO CROSS MEMBER
436
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
436
SPRING WASHER CAB FLOOR
441
PIN (INTERMEDIATE SHAFT)
446
BALL PIVOT LEVER
446
BALL PIVOT , Replaced By: A3129910120
451
WASHER BEARING BRACKET TO BRACKET
456
LOCK RINGTO 000 553 37 01,000 553 39 01,
460
SPRING RELEASE SPRING, UP TO CHASSIS 556499 EXCEPT FOR 553795,555902,556120
462
BRACKET RELEASE SPRING
464
SCREW , Replaced By: N304017008018
464
SCREW SUPPORT TO FENDER
466
SPRING WASHER , Replaced By: N000137008212
466
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
701
CYLINDER SHUT-OFF CYLINDER
708
REPAIR KIT
722
THREADED UNION OPERATING ROD
722
THREADED UNION , Replaced By: A4470720082
729
ROD ACCELERATOR PEDAL TO LEVER
743
NUT
743
NUT , Replaced By: N304035008001
757
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
857
BRACKET
864
SCREW , Replaced By: N304017008034
864
SCREW BRACKET TO CROSS CONNECTION STRUT
871
NUT FROM CONTROL LEVER TO INTERMEDIATE SHAFT AT ENGINE
878
SCREW SUPPORTING ARM TO HOUSING M 16X35
878
SCREW , Replaced By: N304017016004
