Поз.
Артикул
Описание
23
COVER OIL COOLER,002102
23
COVER OIL FILTER,OIL COOLER
43
COVER OIL FILTER
43
COVER
45
COVER OIL FILTER
63
THREADED INSERT DE-AERATION LINE TO COOLING WATER LINE
63
THREADED UNION OIL FILTER
63
THREADED INSERT
63
THREADED INSERT
63
THREADED INSERT
69
THREADED INSERT REPAIR SIZE, TO BE ADAPTED DURING ASSEMBLY
81
SCREW PLUGTO 000 553 03 05,000 553 18 05,
81
SCREW PLUG SHIFTING SHAFT DETENT
81
SCREW PLUG , Replaced By: N000908014009
99
SEAL RING VALVE TO VALVE,K 025179
99
SEAL RING FUEL LINE TO FEED PUMP
108
OIL COOLER , ORDER NUMBER: 001 188 89 01/33
108
OIL COOLER , ORDER NUMBER: 001 188 88 01/33
108
OIL COOLER ,907 845891
108
OIL COOLER , Replaced By: A0011881201
108
OIL COOLER
108
OIL COOLER ,121800907 845891
108
OIL COOLER , Replaced By: A0011881101
122
SEAL. GASKET , Replaced By: A3661880880
136
SCREW STOP TO BATTERY CASE
142
HEXALOBULAR BOLT. SCREW SUPPORT TO CYLINDER HEAD
142
HEXAGON HEAD BOLT. SCREW CABLE HARNESS TO BRACKET M8X40
156
SPRING WASHER , Replaced By: N000137008212
156
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
160
SCREW STRAP TO BRACKET
160
SCREW VALVE TO BRACKET M 8X55
160
SCREW , Replaced By: N304017008053
160
SCREW , Replaced By: N304017008043
160
HEXAGON HEAD BOLT. SCREW CLUTCH PRESSURE PLATE TO FLYWHEEL M 8X1,25X60
162
SEAL RING
164
SCREW PLUG , UP TO ENGINE 921 001982 927 000355 928 000589 929 000007
164
SCREW PLUG
164
SCREW PLUG , Replaced By: A4039970230
166
SEAL RING OIL DRAIN 30X36 MM
166
SEAL RING SPEEDOMETER DRIVE
168
FITTING BETWEEN OIL FILTER HEAD AND OIL LINE
168
SCREW FITTING OIL LINE FEED/RETURN
168
SCREW FITTING
174
SEAL RING
176
SPRING WASHER , 401-403 075551 404 000678
178
SPRING BY-PASS VALVE
180
NUT ROD TO TORSION BAR
182
VALVE
184
SCREW PLUG
194
FILTER ELEMENT WITH GASKETS
194
FILTER ELEMENT RANGE OF DELIVERY
194
FILTER ELEMENT , Replaced By: A4011800009
195
SEAL RING FILTER BOWL TO FILTER HEAD
196
FILTER BOWL OIL FILTER BOWL
196
FILTER BOWL , UP TO ENGINE 923826 YEAR OF MANUFACTURE 1988
196
HOUSING , Replaced By: A4011800011
196
OIL TANK , Replaced By: A4011800011
196
OIL TANK , Replaced By: A4031800011
202
SCREW PLUG , Replaced By: A4429970030
202
SCREW PLUG SHIFTING SHAFT DETENT
206
SEAL RING VALVE TO VALVE,K 025179
222
SCREW OIL FILTER HOUSING TO OIL FILTER HEAD, UP TO ENGINE 923826 YEAR OF MANUFACTURE 1988
222
SCREW OIL FILTER BOWL WITH FULL-FLOW FILTER TO OIL FILTER HEAD
222
SCREW OIL FILTER BOWL WITH FULL-FLOW FILTER TO OIL FILTER HEAD
222
SCREW
226
SEAL RING FUEL LINE TO FEED PUMP
226
SEAL RING FROM FUEL TANK TO FUEL TANK
234
SPRING BY-PASS VALVE
236
SEAL RING
238
SCREW PLUG
240
SEAL RING
240
SEAL RING FROM PIPE ELBOW TO AIR COMPRESSOR
240
SEAL RING TO PLUG AIR COMPRESSOR CYLINDER HEAD TO 003 131 48 01
242
SCREW PLUG
242
SCREW PLUG , UP TO ENGINE 921 001982 927 000355 928 000589 929 000007
242
SCREW PLUG , Replaced By: A4039970230
244
SCREW PLUG
252
SEAL RING FUEL LINE TO FEED PUMP
252
SEAL RING FROM FUEL TANK TO FUEL TANK
254
SEAL RING FROM FUEL TANK TO FUEL TANK
254
SCREW PLUG FUEL TANK
254
SCREW PLUG, FILLING OIL DRAIN
254
SCREW PLUG , Replaced By: A1119970330
254
SCREW PLUG , Replaced By: N007604014110
264
SCREW PLUG , Replaced By: N007604014110
264
SCREW PLUG FUEL TANK
264
SEAL RING INJECTION PUMP
264
SEALING RING. SEAL RING ENGINE BREATHING
264
SEAL RING FUEL LINE TO FEED PUMP
282
GASKET , Replaced By: A4421840580
282
GASKET OIL COOLER COVER, 401-403 129660 404 001964 407 017497
286
GASKET OIL FILTER HEAD & OIL COOLER COVER WITH OIL COOLER TO CRANKCASE
314
SPRING WASHER STEERING COLUMN BRACKET TO CAB
320
SCREW SUPPORT WITH EDDY CURRENT BRAKE TO SUPPORT
320
SCREW OIL FILTER TO CYLINDER CRANKCASE
320
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
320
HEXAGON HEAD BOLT P.T.O. TO TRANSMISSION M10X150
320
SCREW , Replaced By: N304017010047
320
SCREW BRACKET TO SIDE MEMBER M10X35
324
SPRING WASHER
324
SPRING WASHER STEERING COLUMN BRACKET TO CAB
328
HEXAGON HEAD BOLT. SCREW SHIFTING TUBE TO SHIFT LEVER M 10X90
328
SCREW OIL FILTER TO CYLINDER CRANKCASE
328
SCREW , Replaced By: N304014010004
328
HEXAGON HEAD BOLT P.T.O. TO TRANSMISSION M10X150
334
SCREW COVER TO TRANSMISSION CASE M 10X175
338
SCREW OIL FILTER TO CYLINDER CRANKCASE
338
HEXAGON HEAD BOLT. SCREW SHIFTING TUBE TO SHIFT LEVER M 10X90
338
HEXAGON HEAD BOLT BRACKET TO BRACKET M10X35
338
HEXAGON HEAD BOLT P.T.O. TO TRANSMISSION M10X150
338
SCREW , Replaced By: N304014010004
338
SCREW , Replaced By: N304017010047
338
SCREW BRACKET TO SIDE MEMBER M10X35
350
UNION NUT
352
SEAL CONE
354
UNION NUT RETURN LINE
356
SEAL CONE
999
OIL FILTER
999
OIL FILTER RANGE OF DELIVERY,025346
999
FILTER ELEMENT
999
COVER OIL FILTER
999
LEVER THREE-WAY FAUCET,025346
999
VALVE
999
SEAL RING , ELIMINATED,NO LONGER REQUIRED
999
STRAINER , Replaced By: A4011840025
999
STRAINER , Replaced By: A4011840025
999
STRAINER , Replaced By: A4031840025
999
VALVE
999
SCREW FILTER BOWL TO FILTER HEAD
999
HOUSING OIL FILTER BOWL
999
HOUSING , Replaced By: A4011800011
999
OIL COOLER , Replaced By: A0011883001
999
OIL COOLER , Replaced By: A0011883101
999
SCREW FLANGE TO PIPE SOCKET
999
SCREW SCREENING PLATE TO CYLINDER HEAD
999
FILTER ELEMENT , Replaced By: A4011840025
999
FILTER ELEMENT , Replaced By: A4011840025
999
FILTER ELEMENT , Replaced By: A4011840025
999
FILTER ELEMENT , Replaced By: A0011843825
999
FILTER ELEMENT
999
FILTER ELEMENT , Replaced By: A4011840025
999
FILTER ELEMENT , Replaced By: A4011840025
999
OIL COOLER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0001886401
999
OIL COOLER , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 121799, Replaced By: A0011883101
999
OIL COOLER , Replaced By: A0011883101
999
OIL COOLER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0011883001
999
OIL COOLER , Replaced By: A0011883101
999
OIL COOLER , Replaced By: A0011884001
999
OIL COOLER , ORDER NUMBER 001 188 30 01/29, Replaced By: A0011883701
999
OIL COOLER , ORDER NUMBER 001 188 37 01/29, Replaced By: A0011888901
999
OIL COOLER , ORDER NUMBER 001 188 40 01/29, Replaced By: A0021882301
999
SEAL RING , Replaced By: A0009976049
999
VALVE , NOT USED
999
FILTER ELEMENT , Replaced By: A0001801809
999
FILTER ELEMENT
999
OIL FILTER , Replaced By: A4031801110
999
OIL FILTER , Replaced By: A4011800210
999
OIL COOLER
999
SCREW , Replaced By: N910105016029
999
SPRING
999
SPRING
999
SCREW INTERMEDIATE PIECE TO CYLINDER CRANKCASE
999
FITTING , Replaced By: A0029977472
999
SCREW PLUG , Replaced By: A4039970230
999
SCREW PLUG , Replaced By: A4429970030
999
FLANGE HEATING CONNECTION LOCK,5 301949
999
OIL FILTER , Replaced By: A0011840408
999
FILTER ELEMENT , Replaced By: A4011800009
999
GASKET
999
COVER , Replaced By: A4031801438
999
OIL FILTER , Replaced By: A0011840408
999
COVER , Replaced By: A0011840408
999
FILTER ELEMENT , Replaced By: A4021800009
999
VALVE , Replaced By: A4031840132
999
GASKET , Replaced By: A4031840380
999
GASKET , Replaced By: A4421880280
999
GASKET , Replaced By: N917003026000
999
SCREW PLUG
999
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
999
PARTITION PANEL ,001964
999
HOUSING , Replaced By: A4041800637
999
COVER OIL FILTER
999
COVER OIL COOLER HOUSING
999
GASKET , EXHAUST STOCK OF OLD PARTS UP TO ENGINE 401-403, 421-423, 441-443 735001 404, 424, 444 051301 407, 447015077, Replaced By: A4441840080
999
GASKET , Replaced By: A4441880080
999
BAFFLE PLATE OIL COOLER HOUSING,001965
999
LINE
999
COVER , Replaced By: A4071800438
999
COVER
999
COVER , Replaced By: A4441801538
999
CLAMPING BRACKET OIL FILTER TO BRACKET,5 218089
999
BRACKET OIL LINES
999
BRACKET OIL LINES
999
COVER
999
HOUSING , Replaced By: A4241800037
999
GASKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A4421312080
999
GASKET TO PLUG AIR COMPRESSOR CONNECTION ON CYLINDER CRANKCASE
999
GASKET , Replaced By: A4421880580
999
BRACKET OIL FEED LINE TO OIL FILTER
999
OIL FILTER COVER
