Поз.
Артикул
Описание
110
BRACKET
113
BRACKET
116
SCREW INTERMEDIATE AND CONTROL LEVERS ON BRACKET
119
LEVER CONTROL LEVER
122
SHIM. FITTED WASHER CONTROL LEVER TO BRACKET
125
LOCKING WASHER. LOCK PLATE CLUTCH PEDAL RESET
128
LEVER INTERMEDIATE LEVER
131
SCREW INTERMEDIATE AND CONTROL LEVERS ON BRACKET
134
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
137
SENDER UNIT (PEDAL VALUE SENSOR)
140
VALVE
143
BRACKET CONTROL VALVE
143
BRACKET CONTROL VALVE
146
WASHER COMPRESSED AIR LINE TO BRACKET
146
SPRING WASHER , Replaced By: N000137008212
146
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
149
NUT BALL PIVOT TO LEVER
149
NUT
149
NUT , Replaced By: N304032008006
152
LEVER (REVERSING LEVER)
155
LEVER (DRAG LINK)
158
LOCK PLATE ROLLER TO LEVER
164
LOCK PLATE ROLLER TO LEVER
167
SCREW , Replaced By: N304017006016
167
SCREW PUMP TO BRACKET
173
ROD FROM REVERSING LEVER TO CONTROL LEVER
176
SPACER TUBE MUFFLER TO BRACKET
176
SPACER TUBE BRACKET TO CONSOLE,LEFT
179
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
179
NUT , Replaced By: N913023006001
999
PAD , 000 112328 003 056792 007 046654 083 000998 086 000712 093 000557 102,103 091560 105 115062 183 001323 190 001262
999
ROLLER , NOT USED
999
SPRING , NOT USED
