Поз.
Артикул
Описание
5
ALTERNATOR USED WITHOUT POWER STEERING AND AIR CONDITIONER 80 A, BOSCH,602.940 277088
5
ALTERNATOR , Replaced By: A0071545202
5
ALTERNATOR NOT USED WITH POWER STEERING 55 A, BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATOR USED WITH AIR CONDITIONER AND/OR POWER STEERING 80 A, BOSCH,602.940 277088 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
ALTERNATOR USED WITH AIR CONDITIONER, OR WITH POWER STEERING 55 A, BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
10
BOLT. SCREWTO 008 154 80 02
10
SCREW , Replaced By: A0019901021
10
SCREW , Replaced By: A0019901021
15
SCREW , Replaced By: A0009908330
15
SCREW , Replaced By: A0019902920
15
BOLT. SCREW COVER PLATE TO DRIVE BEARING TO 007 154 30 02, 007 154 31 02
15
SCREW COVER PLATE TO DRIVE BEARING M4X20
20
BALL BEARING , Replaced By: A0079812425
20
BALL BEARING , Replaced By: A0079818925
20
GROOVED BALL BEARING
20
BALL BEARING DRIVE END BEARING BOSCH
25
BALL BEARINGTO 008 154 80 02
25
BALL BEARING , Replaced By: A0079814325
25
BALL BEARING , Replaced By: A0079815525
25
BALL BEARING , Replaced By: A0079819025
25
GROOVED BALL BEARING SLIP RING SIDE TO 005 154 11 02
30
SEAL RINGTO 005 154 34 02
35
RECTIFIER , Replaced By: A0011543116
35
RECTIFIER , Replaced By: A0001548216
35
RECTIFIERTO 007 154 68 02,008 154 26 02
35
RECTIFIERTO 007 154 33 02/ 52 02/ 60 02
40
COMBINATION BOLT
40
SCREW-AND-WASHER ASSEMBLY. COMBINATION BOLT
40
SCREW T-FITTING TO BRACKET M4X25
45
CONDENSER THREE-PHASE ALTERNATOR INTERFERENCE SUPPRESSION
50
SCREW
55
SPRING WASHER HEATER PLUG CABLE HARNESS
55
SPRING WASHER ALTERNATOR CONNECTION D+
65
REGULATOR AND CUT-OUTTO 007 154 60 02, 008 154 26 02
70
CARBON BRUSH SETTO 009 154 07 02
75
SCREW REGULATOR MOUNTING TO 009 154 07 02
80
SPRINGTO 007 154 58 02
80
SPRING
90
FAN
90
FANTO 007 154 60 02
95
PULLEYTO A 009 154 44 02, BOSCH
95
PULLEY , Replaced By: A6041550015
95
PULLEY , Replaced By: A0011551215
95
PULLEYTO 007 154 61 02,008 154 26 02/ 90 02
100
WASHER
110
NUT PULLEY TO ALTERNATOR
400
ALTERNATOR ,602.940 277089, Replaced By: A0091543002
400
ALTERNATOR , Replaced By: A0101544702
410
SCREW COVER PLATE TO DRIVE BEARING M4X20
415
BALL BEARING , Replaced By: A0079818925
415
BALL BEARING DRIVE END BEARING BOSCH
420
BALL BEARING , Replaced By: A0079817325
420
BALL BEARING SLIP RING SIDE BOSCH
425
RING SLIP RING SIDE
430
REGULATOR AND CUT-OUTTO 008 154 52 02
435
SCREW-AND-WASHER ASSEMBLY. COMBINATION BOLT
450
COVER FOR ALTERNATOR: 70A/90A, BOSCH
450
COVER , Replaced By: A0001543404
455
SCREW COVER BOSCH
460
SCREW HOUSING M5X47, BOSCH
500
PULLEY , Replaced By: A6041550015
500
PULLEYTO A 009 154 44 02, BOSCH
510
NUT PULLEY TO ALTERNATOR
