Поз.
Артикул
Описание
10
SHIFT LEVER
10
SHIFT LEVER
20
KNOB (SHIFT LEVER HANDLE), TO BE ADAPTED DURING ASSEMBLY
25
COVER 6-SPEED,SHIFT LEVER KNOB
25
COVER FIVE-SPEED, SHIFT LEVER KNOB
25
COVER , Replaced By: A6202680557
35
NUT PUSH ROD
35
NUT , Replaced By: N308675010000
40
BOOT GEARSHIFT LEVER LOWER PART, 184087, 309.030-035,051-059 192298, 309.050 182066, 309.1
45
BOOT , Replaced By: A3562680197
45
BOOT (POWER CYLINDER),POWER STEERING
50
BRACKET COVER TO BEARING BRACKET
55
GASKET
60
JOINT BEARING SHIFT LEVER
65
SPACER RING
70
LOCK RING BEARING BRACKET,4 972621
75
LOCK RING
80
SCREW PIPE CLAMP
80
SCREW , Replaced By: N304017008021
85
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
95
LEVER INTERMEDIATE LEVER
100
NEEDLE BEARING
100
NEEDLE BEARING
105
SCREW SHIFTING ROD TO TRANSMISSION
110
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
115
NUT , Replaced By: N304032008006
120
SHIFTING ROD FRONT
125
SHIFTING ROD FRONT
130
PIN LEVER TO SHIFTING ROD,047858
130
PIN LEVER TO BRACKET
135
SEAL RING LEVER BEARING
140
SPRING WASHER LEVER TO BRACKET
145
LOCK STOP TO BEARING BRACKET
145
LOCK RING , Replaced By: A0079942041
150
COTTER PIN4X25 MM
155
CONNECTOR FLANGE TO SHIFTING TUBE
160
WOODRUFF KEY FLANGE TO SHIFTING TUBE
165
LOCK WASHER FITTING TO BRACKET
170
NUT STRAP TO SUPPORT
175
JOINT SHIFTING ROD TO SHIFTING ROD
175
JOINT SHIFTING ROD TO SHIFTING ROD
180
SCREW SHIFTING TUBE TO TRANSMISSION
185
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
190
NUT , Replaced By: N304032008006
195
SHIFTING ROD ABOVE FRONT AXLE
200
SHIFTING ROD ABOVE REAR AXLE
205
SHIFTING ROD REAR
205
SHIFTING ROD REAR
205
SHIFTING ROD REAR
215
SPACER WASHER3 MM
215
SPACER WASHER5 MM
215
SPACER WASHER2 MM
230
SCREW BRACKET TO SIDE MEMBER, 815770
230
SCREWM 8X40
240
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
245
NUT , Replaced By: N304032008006
250
CONNECTOR FRONT SHIFTING ROD TO REAR SHIFTING ROD
255
SCREW SHIFTING ROD TO TRANSMISSION
260
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
265
LOCK FRONT SHIFTING ROD TO REAR SHIFTING ROD
270
NUT , Replaced By: N304032008006
275
SCREW SHIFTING TUBE TO TRANSMISSION
280
LOCK FRONT SHIFTING ROD TO REAR SHIFTING ROD
