Поз.
Артикул
Описание
11
P.T.O.N352/2B
11
P.T.O.N 352/2B
14
HOUSING P.T.O. TO A 352 260 12 05
14
HOUSING , Replaced By: A0002643328
23
HOUSING , Replaced By: A0002642028
23
HOUSING P.T.O.
23
HOUSING P.T.O. TO A 352 260 12 05
26
DOWEL PIN
32
GASKET TRANSMISSION CASE
32
GASKET , Replaced By: A0012641580
38
STUD BOLT P.T.O. TO TRANSMISSION M12X105
38
STUD BOLT P.T.O. TO TRANSMISSION M12X125
44
STUD P.T.O.
47
LOCK WASHER OIL PUMP TO TRANSMISSION CASE
50
WASHER COVER TO P.T.O. CASE
53
NUT COVER TO FLANGE
53
NUT
56
SEAL RING P.T.O. SHIFT LEVER
59
SHIFT LEVER
62
SLIDE P.T.O. SHIFT LEVER
71
DRIVE SHAFT P.T.O.
71
DRIVE SHAFT P.T.O. Z22,TO A 352 260 12 05
74
SPRING
77
BALL
80
COLLAR , Replaced By: A0002630823
80
SLIDING COLLAR , Replaced By: A0002630623
89
CAGETO (N 353/1B)
89
NEEDLE BEARING DRIVE SHAFT
89
NEEDLE BEARING P.T.O.
92
THRUST WASHER DIFFERENTIAL PINION
95
NEEDLE BEARING REAR DRIVE SHAFT
98
DRIVE SHAFT P.T.O.
101
NEEDLE BEARING OUTPUT SHAFT
104
LOCK RING. RETAINING RING OIL PUMP TO TRANSMISSION CASE
107
GEAR OUTPUT SHAFT
107
GEAR P.T.O.
110
BALL BEARING , Replaced By: A0029812301
110
BALL BEARING , Replaced By: A0089814225
110
BALL BEARING , Replaced By: A0019811525
110
BALL BEARING DRIVE SHAFT,183596
110
BALL BEARING DRIVE SHAFT,183596
110
CYLINDR. ROLLER BEARING DRIVE SHAFT
119
SNAP RING DRIVE SHAFT
122
INTERMEDIATE FLANGE OUTPUT FLANGE
128
RETAINING RING. LOCK RING BEARING TO DRIVE SHAFT
131
SEAL RING REAR P.T.O.
131
SEAL RING , Replaced By: A0089973747
134
SNAP RING
140
COUPLING FLANGE90 MM
143
SHIM FLANGE TO TRANSMISSION CASE COVER
146
SEALING CORD , Replaced By: A0119979145
146
SEAL RING FLANGE TO TRANSMISSION CASE COVER
149
SPRING WASHER CAB FLOOR
152
SHIM AS REQUIRED 1.00 MM, PIECES ARE NEEDED IF A POWER TAKE OFF N352/1B AND N352/2B IS FITTED
152
WASHER SPEEDOMETER DRIVE 0.60 MM
152
SCREW BRACKET TO FRAME
155
BEARING CAP
158
SHIFT LEVER LATERAL P.T.O
161
SCREW SUPPORT TO FENDER
161
SCREW , Replaced By: N304017008018
164
SPRING WASHER , Replaced By: N000137008212
164
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
167
NUT
173
SHAFT (SHIFTING SHAFT)
176
GREASE NIPPLE
176
GREASE NIPPLE , Replaced By: N071412008102
179
YOKE OPERATING ROD
182
PIN , Replaced By: N918001008002
182
PINM 8 X 16
185
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
194
GASKET
194
GASKET , Replaced By: A0002642980
194
GASKET CASE,REAR
260
SHIFT LEVER
260
SHIFT LEVER LATERAL P.T.O TO N 70/1A (N352/1B)
260
SHIFT LEVER LATERAL P.T.O TO N 70/1A (N352/1B)
260
SHIFT LEVER
263
SCREWM 8X40
263
SCREW SUPPORT TO FENDER
263
SCREW , Replaced By: N304017008018
266
SPRING WASHER , Replaced By: N000137008212
266
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
269
NUT , Replaced By: N913004008001
269
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
